Summary of Contents for Electric Mobility Rascal 600F
- Page 1 Rascal 600F / 600T Scooter Owners Manual & Service Record Rascal 600F Rascal 600T Electric Mobility Euro Limited, Canal Way, Ilminster, Somerset TA19 9DL Telephone: 01460 258100 www.electricmobility.co.uk Issue 1: 06/08...
- Page 2 Rascal 600F Rascal 600T Electric Mobility Euro Ltd has designed this pair of powerful, durable scooters for a frequent outdoor use. So long as they are maintained and operated in accordance with this manual they should last for many years, and provide you with freedom and independence.
-
Page 3: Table Of Contents
Contents Dealer information Features and layout Safety Information EMI Intended use Controls – Dashboard Controls – Driving controls Freewheel Device Brakes Seat and armrest adjustment Swivel seat Tiller adjustment Clock Seat height adjustment Driving the vehicle Driving the vehicle – Hazards Transporting your scooter Dismantling your scooter Battery charging... -
Page 4: Dealer Information
Telephone: Email: For product information see serial number plate located on the underside of the scooter frame (front and rear). Manufacturer Electric Mobility Euro Limited Canal Way, Ilminster, Somerset TA19 9DL Company Registration in England No. 2419231 Features and Layout Photo shows 600F model scooter. -
Page 5: Safety Information Emi
Intended use of the vehicle This vehicle is designed for use by adults with a disability (up to the maximum recommended weight) who require a robust comfortable pavement scooter that is ideal for shopping and other visits. The scooter is intended for use in shopping areas and trips on reasonably paved areas. It is also capable of manoeuvring on uneven surfaces and on grassy areas unless they are slippery. - Page 6 Safety Information General Warnings Warning ! The operation of scooters can endanger the life of the driver or third parties. Any driver should always be fully capable of operating this vehicle safely. Warning ! Sitting for long periods may increase the chance of thromboses or pressure sores. Users prone to such conditions are advised to take medical advice.
-
Page 7: Controls - Dashboard
Warning ! Leaning Over. Do not lean sideways as this could cause the scooter to topple. Warning ! Escalators. Never drive this scooter onto an escalator as this could cause toppling and severe injury. Warning ! Roads. The 600 series scooters are not for use on roads, apart from crossing roads at designated places. Warning ! This vehicle is not suitable for use as a seat for an occupant when in a motor vehicle. -
Page 8: Controls - Driving Controls
Horn: Press the button on the bottom left hand or bottom right side and the horn will sound. Release and the horn will cease. Indicators: Even when the ignition key switch is off, the indicator left or right can be selected using the rocker switch above the key switch. -
Page 9: Brakes
Brakes There are 2 braking systems. The first works with the accelerator. When the accelerator is released the scooter will automatically brake and bring the scooter to a stop. When the scooter stops the primary brake will engage. This will stop the vehicle rolling forward or backward. When you start the handbrake will automatically disengage. If the battery should go flat the brakes automatically engage. -
Page 10: Tiller Adjustment
Tiller Head Adjustment The tiller head angle adjustment allows the handlebar/dashboard assembly to be rotated to provide a comfortable riding position. To adjust the tiller head lift to an upright position. By adjusting the screw below the tiller head the angle of the tiller head can be changed. -
Page 11: Seat Height Adjustment
Seat Post Height Adjustment The seat height can be adjusted as follows: 1. Remove the seat by pulling the seat swivel lever and lifting the seat off the seat post. 2. Unscrew the nut and bolt and remove from the tube. Try and avoid touching the top of the post as it has serrations which could cut your hand. -
Page 12: Driving The Vehicle
Driving the Vehicle Warning! Read this before driving the vehicle! Whether or not this is your first mobility vehicle, please read these guidelines as all vehicles differ. Failure to do this may cause damage to yourself, a third party or the vehicle. Before you set out, do check the weather forecast. -
Page 13: Driving The Vehicle - Hazards
Driving the vehicle - hazards Warning! Before driving the scooter you should be aware that, under certain circumstances it could become unstable and tip over. As a Class B Scooter, the maximum safe slope it can negotiate in any direction is defined in the technical specification. Your scooter has been designed to operate on paved, even surfaces and should not be used on rough terrain. -
Page 14: Transporting Your Scooter
Transporting your Scooter Warning! Dismantling the scooter involves lifting and handling heavy parts. Weights are given in the Technical Specification; consider if you need help in handling parts before you try to lift them. The 600T and F models can be transported in vans or estate cars using ramps. By lowering the tiller and removing the seat the height can be reduced to make entry into the boot of most large estate cars possible. -
Page 15: Battery Charging
Battery Charging Warning! When charging batteries NEVER smoke, or do this in a place where there are naked flames such as gas-fired heaters as, under exceptional circumstances, batteries may give off gases which could ignite and explode. Warning! When charging batteries NEVER connect or disconnect the charger while it is still connected to the mains. -
Page 16: Troubleshooting Guide
Troubleshooting Guide This table is a guide to fault finding. The fault may be a simple fix. If you have any doubts phone your dealer. Symptom Solution • Scooter does not move. when power is • Freewheel is engaged. switched on. Check: Does the battery level •... -
Page 17: User Maintenance
User Maintenance It is important for safety that you carry out the following checks before use. Visually check the machine for damage. Visually check the tyres for damage and check if they need inflating. Check the steering moves freely. Check that the Tiller adjustment lever is secure and locked. Check that the Seat is located correctly and locked. -
Page 18: Frequently Asked Questions
Frequently Asked Questions I want to transport my vehicle in a car. There are various techniques to loading the vehicle into an estate car. It depends on what type of vehicle you own. Make sure your dealer has demonstrated the easiest way of doing this. Can I fit weatherproofing such as a canopy ? Yes, but remember if you alter the vehicle in any way it will void your guarantee. -
Page 19: Servicing And Maintenance
Servicing and Maintenance This vehicle is designed for minimum maintenance. However it is recommended that an approved Electric Mobility Dealer services your vehicle at least once a year. If the vehicle is used constantly we rec- ommend a twice-yearly maintenance. Ensure the engineer stamps this Handbook on completion for all servicing carried out on this vehicle. -
Page 20: Guarantee & Warranty
If a defective part appears within the stated limited warranty period and the purchaser has given Electric Mobility Euro Limited immediate notice the Company will repair the part or at its option replace the part with a similar part. No allowance will be made for repairs to any equipment without the expressed written or verbal approval of Electric Mobility Euro Limited. -
Page 21: Technical Specification
Technical Specification - Rascal 600T Scooter Wheelchair type Class Class A, B or C Class B Department of Transport Class Class 1 2 or 3 Class 2 Overall dimensions fully assembled length x width x height mm (in) 1170 (46) x 635 (25) x 980 (38.6) Dimensions seat removed tiller folded length x width x height mm (in) 1170 (46) x 635 (25) x 600 (23.6) - Page 22 Technical Specification - Rascal 600F Scooter Wheelchair type Class Class A, B or C Class B Department of Transport Class Class 1 2 or 3 Class 2 Overall dimensions fully assembled length x width x height mm (in) 1238 (48.75) x 635 (25) x 980 (38.6)
-
Page 23: Returns - Dealer Information
Factory Returns Procedures If a part or the entire product is to be returned, call Electric Mobility Customer Service Centre to obtain a Return Authorisation Number that must be placed on the return package or crate. This number is used to identify the customer, the part and the type of repair. -
Page 24: Service Log
Service Log Notice for the Service Engineer. Please make sure this part is stamped and dated after each service. Dealer stamp - 1st Service Dealer stamp - 2nd Service Dealer stamp - 3rd Service Dealer stamp - 4th Service Dealer stamp - 5th Service Dealer stamp - 6th Service Dealer stamp - 7th Service Dealer stamp - 8th Service... -
Page 25: Brochure Request
Brochure Request Do you have a friend or colleague that would be interested in an Electric Mobility product? If so cut out this coupon and send it to the address shown on the back of the manual. My Dealer’s Company name is: Please can I have a free no-obligation home demonstration. - Page 26 Electric Mobility Euro Ltd., FREEPOST (SWBI 1045), Ilminster, Somerset, TA19 9ZA Electric Mobility Euro Ltd., FREEPOST (SWBI 1045), Ilminster, Somerset, TA19 9ZA...
- Page 27 Notes...
- Page 28 Rascal 600F / 600T Scooters Manufactured by Electric Mobility Euro Limited, Canal Way, Ilminster, Somerset TA19 9DL Telephone: 01460 258100 www.electricmobility.co.uk E. and O.E. Issue 1: 06/08...
