Summary of Contents for ECS H67H2-M v 1.1

  • Page 1 Инструкция для ECS H67H2-M v 1.1 Перейти в карточку товара 8 800 775 98 98...
  • Page 2 Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 1.0A Disclaimer The information in this document is subject to change without notice.

  • Page 3: Declaration Of Conformity

    Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interfer- ence that may cause undesired operation. Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference- causing Equipment Regulations.

  • Page 4: Table Of Contents

    T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the Motherboard Introduction...................1 Feature....................2 Specifications................4 Motherboard Components............6 9 9 9 9 9 Chapter 2 Installing the Motherboard Safety Precautions................9 Choosing a Computer Case.............9 Installing the Motherboard in a Case..........9...
  • Page 5 Security Menu.................54 Save & Exit Menu..............55 Updating the BIOS..............56 Chapter 4 57 57 57 57 57 Using the Motherboard Software About the Software DVD-ROM/CD-ROM........57 Auto-installing under Windows XP/Vista/7........57 ..Running Setup..............58 Manual Installation................60 Utility Software Reference..............60 61 61 61 61 61 Chapter 5 ®...

  • Page 6: Introducing The Motherboard

    Chapter 1 Introducing the Motherboard Introduction Thank you for choosing the H67H2-M motherboard. This motherboard is a high performance, enhanced function motherboard designed to support the latest socket ® LGA1155 Intel Generation Core i7, i5, i3, Pentium & Celeron processors for high-end business or personal desktop markets.

  • Page 7: Feature

    Feature Processor The motherboard uses an LGA1155 type of socket that carries the following features: • Accommodates latest socket LGA1155 Intel ® Generation Core i5, i3, Pentium & Celeron processors • Supports “Hyper-Threading” technology CPU • One PCI Express x16 Gen2 port supporting up to 5 GB/s direction peak bandwidth “Hyper-Threading”...

  • Page 8: Bios Firmware

    Giga LAN • Supports PCI Express • Integrated 10/100/1000 transceiver • Wake-on-LAN and remote wake-up support Expansion Options The motherboard comes with the following expansion options: • One PCI Express x16 slot for Graphic Interface • Two PCI Express slots •...

  • Page 9: Specifications

    Specifications ® • latest socket LGA1155 Intel Generation Core i7, i5, i3, Pentium & Celeron processors • Supports “Hyper-Threading” technology CPU Chipset • Intel H67 Chipset Extra Chips • ITE IT8893 PCI Bridge supports one PCI slot expansion • Etron USB 3.0 Controller supports two USB 3.0 ports at the back panel (Compatible with USB 2.0) Memory •...
  • Page 10 • Supports Graphic Over-Clocking • Supports Multi-Monitor technology • Supports Intel Turbo Boost • Supports ECS M.I.B III Utility -CPU Voltage Adjustable -Memory Voltage Adjustable -IMC Voltage Adjustable -Graphic Voltage Adjustable Form Factor • Micro ATX Size, 244mm x 244mm...

  • Page 11: Motherboard Components

    Motherboard Components Introducing the Motherboard...
  • Page 12 Table of Motherboard Components LABEL COMPONENTS ® latest LGA1155 socket for Intel Generation Core 1. CPU Socket i7, i5, i3, Pentium & Celeron processors 2. CPU_FAN CPU cooling fan connector 3. DDR3_1~4 240-pin DDR3 SDRAM slots 4. PWR_FAN Power cooling fan connector 5.
  • Page 13 Memo Introducing the Motherboard...

  • Page 14: Installing The Motherboard

    Chapter 2 Installing the Motherboard Safety Precautions • Follow these safety precautions when installing the motherboard • Wear a grounding strap attached to a grounded device to avoid dam- age from static electricity • Discharge static electricity by touching the metal case of a safely grounded object before working on the motherboard •...

  • Page 15: Checking Jumper Settings

    Do not over-tighten the screws as this can stress the motherboard. Checking Jumper Settings This section explains how to set jumpers for correct configuration of the motherboard. Setting Jumpers Use the motherboard jumpers to set system configuration options. Jumpers with more than one pin are numbered.

  • Page 16: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled. Jumper Settings Type Jumper Description Setting (default) 1-2: NORMAL 2-3: CLEAR CLR_CMOS 3-pin Clear CMOS Before clearing the CLR_CMOS CMOS, make sure to turn off the system.

  • Page 17: Installing Hardware

    Installing Hardware Installing the Processor Caution: When installing a CPU heatsink and cooling fan make sure that you DO NOT scratch the motherboard or any of the surface-mount resis- tors with the clip of the cooling fan. If the clip of the cooling fan scrapes across the motherboard, you may cause serious damage to the motherboard or its components.

  • Page 18: Cpu Installation Procedure

    CPU Installation Procedure The following illustration shows CPU installation components. A. Opening of the Load Plate · Put your thumb on the tail of the load plate and press the tail down. · Rotate the load plate to fully open position.

  • Page 19: Installing Memory Modules

    1. To achieve better airflow rates and heat dissipation, we suggest that you use a high quality fan with 3800 rpm at least. CPU fan and heatsink installation procedures may vary with the type of CPU fan/ heatsink supplied. The form and size of fan/heatsink may also vary. 2.

  • Page 20: Installation Procedure

    1. For best performance and compatibility, we recommend that users give priority to the white DIMMs (DDR3_2/DDR3_4) when installing DIMMs. 2. We suggest users not to mix memory type. It is recommended to use the same brand and type memory on this motherboard. Do not remove any memory module from its antistatic packaging until you are ready to install it on the motherboard.

  • Page 21: Expansion Slots

    Expansion Slots Installing Add-on Cards The slots on this motherboard are designed to hold expansion cards and connect them to the system bus. Expansion slots are a means of adding or enhancing the motherboard’s features and capabilities. With these efficient facilities, you can in- crease the motherboard’s capabilities by adding hardware that performs tasks that are not part of the basic system.
  • Page 22 Follow these instructions to install an add-on card: Remove a blanking plate from the system case corresponding to the slot you are going to use. Install the edge connector of the add-on card into the expansion slot. Ensure that the edge connector is correctly seated in the slot. Secure the metal bracket of the card to the system case with a screw.

  • Page 23: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the motherboard’s optional devices: F_AUDIO: Front Panel Audio header This header allows the user to install auxiliary front-oriented microphone and line- out ports for easier access. Signal Name Signal Name PORT 1L AUD_GND PORT 1R...
  • Page 24 SATA3~5: Serial ATA connectors These connectors are used to support the Serial ATA 3Gb/s devices, simpler disk drive cabling and easier PC assembly. It eliminates limitations of the current Parallel ATA interface. But maintians register compatibility and sofeware compatibility with Prallel ATA.
  • Page 25 SPDIFO: SPDIF out header This is an optional header that provides an SPDIFO (Sony/Philips Digital Interface) output to digital multimedia device through optical fiber or coaxial connector. Signal Name SPDIFOUT CASE: Chassis Intrusion Detect Header This detects if the chassis cover has been removed. This function needs a chassis equipped with instrusion detection switch and needs to be enabled in BIOS.

  • Page 26: Installing A Sata Hard Drive

    Installing a SATA Hard Drive This section describes how to install a SATA Hard Drive. About SATA Connectors Your motherboard features five SATA connectors supporting a total of five drives. SATA refers to Serial ATA (Advanced Technology Attachment) is the standard inter- face for the IDE hard drives which are currently used in most PCs.

  • Page 27: Connecting I/O Devices

    Connecting I/O Devices The backplane of the motherboard has the following I/O ports: VGA Port Connect your monitor to the VGA port. DVI Port Connect the DVI port to the monitor. CLR_CMOS_BTN Use the CLR_CMOS button to clear CMOS. Display Port Connect the Display port to the monitor.

  • Page 28: Connecting Case Components

    Connecting Case Components After you have installed the motherboard into a case, you can begin connecting the motherboard components. Refer to the following: Connect the CPU cooling fan cable to CPU_FAN. Connect the standard power supply connector to ATX_POWER. Connect the case switches and indicator LEDs to the F_PANEL. Connect the system cooling fan connector to SYS_FAN.
  • Page 29 Connecting 8/4-pin power cable Users please note that the 8-pin and 4-pin power cables can both be con- nected to the ATX12V connector. When installing 8-pin power cable, the latches of power cable and the ATX12V connector match perfectly. 8-pin power cable When installing 4-pin power cable, the latch falls on the left side of the ATX12V connec- tor.
  • Page 30 ATX_POWER: ATX 24-pin Power Connector Signal Name Signal Name +3.3V +3.3V +3.3V -12V Ground Ground PS_ON Ground Ground Ground Ground Ground PWRGD +5VSB +12V +12V +3.3V Ground ATX12V: ATX 12V Power Connector Signal Name Signal Name Ground +12V Ground +12V Ground +12V Ground...

  • Page 31: Front Panel Header

    Front Panel Header The front panel header (F_PANEL) provides a standard set of switch and LED headers commonly found on ATX or Micro ATX cases. Refer to the table below for informa- tion: Signal Function Signal Function HD_LED_P Hard disk LED(+) 2 FP PWR/SLP *MSG LED(+) HD_LED_N Hard disk LED(- ) FP PWR/SLP *MSG LED(-)

  • Page 32: Using Bios

    Chapter 3 Using BIOS About the Setup Utility The computer uses the latest “American Megatrends Inc.” BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configuration status and provides you with options to set system parameters.

  • Page 33: Resetting The Default Cmos Values

    Press the delete key to access BIOS Setup Utility. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit Choose the system default BIOS Information language System Language [English] System Data [ Wed 11/10//2010] :Select Screen System Time...

  • Page 34: Bios Navigation Key

    In this manual, default values are enclosed in parenthesis. Submenu items are denoted by a triangle The default BIOS setting for this motherboard apply for most conditions with optimum performance. We do not suggest users change the default values in the BIOS setup and take no responsibility to any damage caused by changing the BIOS settings.

  • Page 35: Advanced Menu

    Legacy OpROM Support Option ROM Launch PXE OpROM [Disabled] Launch Storage OpROM [Enabled] LAN Configuration :Select Screen ECS eJIFFY Function :Select Item PC Health Status Enter : Select Power Management Setup +/- : Change Opt. ACPI Settings F1: General Help...

  • Page 36: Lan Configuration

    ESC: Exit Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc. ECS eJIFFY Function (Disabled) Version 2.02.1205. Copyright (C) 2012, American Megatrends, Inc. This item enables or disables ECS eJIFFY Function. Press <Esc> to return to the Advanced Menu page. Using BIOS...

  • Page 37: Pc Health Status

    PC Health Status On motherboards support hardware monitoring, this item lets you monitor the paeameters for critical voltages, temperatures and fan speeds. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit PC Health Status Smart Fan Function System Temperature...
  • Page 38 SMART Fan start PWM value (180) This item is used to set the start PWM value of the smart fan. SMART Fan start TEMP(-) (30) This item is used to set the start temperature of the smart fan. DeltaT (+3) This item specifies the range that controls CPU temperature and keeps it from going so high or so low when smart fan works.

  • Page 39: Power Management Setup

    Power Management Setup This page sets up some parameters for system power management operation. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit Power Management Setup About Resume by PCI/PCI-E/Lan Resume By PCI/PCI-E/Lan PME [Disabled] Resume By USB (S3)

  • Page 40: Acpi Configuration

    ACPI Configuration The item in the menu shows the highest ACPI sleep state when the system enters suspend. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit ACPI Settings Select the highest ACPI sleep state the system will enter ACPI Sleep State...
  • Page 41 Inter(R) Core(TM) i5-2400 CPU @ 3.10 GHz This is display-only field and diaplays the information of the CPU installed in your computer. EMT64 (Supported) This item shows the computer supports EMT64. Processor Speed (3100MHz) This item shows the current processor speed. Processor Stepping (206a6) This item shows the processor stepping version.

  • Page 42: Sata Configuration

    SATA Configuration Use this item to show the mode of serial SATA configuration options. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit (1) IDE Mode. (2) AHCI Mode. SATA Configuration (3) RAID Mode.

  • Page 43: Usb Configuration

    USB Configuration Scroll to this item and press <Enter> to view the following screen: Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit USB Configuration Enabled/Disabled All USB Devices All USB Devices [Enabled] USB 3.0 Controller...

  • Page 44: Super Io Configuration

    Super IO Configuration Scroll to this item and press <Enter> to view the following screen: Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit Enable or Disable output Temp. to Super IO Configuration 80-Port Super IO Chip...

  • Page 45: Trusted Computing

    Trusted Computing Scroll to this item and press <Enter> to view the following screen: Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit Enables or Disables TPM TPM Configuration support.

  • Page 46: Chipset Menu

    Chipset Menu The chipset menu items allow you to change the settings for the North chipset, South chipset and other system. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit North Bridge Parameters North Bridge South Bridge...
  • Page 47 Intel integrated Graphics and one or two PCI-Express graphics devices under Windows 7. Step 1. Insert ECS drives DVD to run Auto setup or browse the DVD to install Intel chipset drivers, VGA and sound drivers.(If you want know the detail information, please refer to chapter 4.)
  • Page 48 Step 2. Install all the drivers of PCI-Express graphic cards. Click the Browse CD item, then appears the following screen. Select the driver you want to install(e.g NVIDIA GeForce 8400 GS(Microsoft Corporation-WDDM v1.1)) and double click Step 3. Enable IGD Multi-Monitor from BIOS. In the following BIOS screen, please set IGD Multi-Monitor to [Enabled].
  • Page 49 Step 4. Change the appearance of your displays under Windows 7. 1. Enter the Control Panel menu, select the Display in the All Control Panel Items and click the Screen Resolution, then appears the following screen. Show the path of the setting location Display devices Search Control Panel Control Panel...
  • Page 50 Search Control Panel Control Panel All Control Panel Items Display Screen Resolution Change the apprearance of your displays Detect Identify Display: 4. AL1717 Resolution: 1920 x 1200 (recommended) Orientation: Landscape Multiple displays: Disconnect this display You must select Apply before making additional changes. Make this my main display Advance settings Make text and other items larger or smaller...
  • Page 51 South Bridge Scroll to this item and press <Enter> to view the following screen: Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit South Bridge Specify what state to go to when power is re-applied after Restore AC Power Loss [Power Off]...
  • Page 52 ME Subsystem Scroll to this item and press <Enter> to view the following screen: Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit Intel ME Subsystem Configuration ME Subsystem Help ME Version 7.

  • Page 53: M.i.b.iii(Mb Intelligent Bios Iii) Menu

    M.I.B III (MB Intelligent BIOS III) Menu This page enables you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have installed in your system. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.

  • Page 54: Cpu Configuration

    Current ICC Profiles Index (N/A) This item shows current ICC profiles index. ICC Enable (Disabled) This item allows you to enable or disable current ICC. Press <Esc> to return to the M.I.B III menu page. Performance Tunning Scroll to this item and press <Enter> to view the following screen: Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
  • Page 55 IA Core Current (Normal) Use this item to control CPU Current Limit. This is for Turbo mode. Power Limit 1 Value(Watt) (95) Use this item to control the limit of the TDP. This is for Turbo mode. Power Limit 2 Switch (Enabled) Use this item to control the Power Limit 2.
  • Page 56 Memory Timing Configuration This item shows the information of Memory Timing Configuration. CAS#Latency(tcl) (9) This item determines the operation of DDR SDRAM memory CAS(colulmn address strobe). It is recommanded that you leave this item at the default value. The 2T setting requires faster memory that specifically supports this mode.
  • Page 57 Intel(R) Core(TM) i5-2400 CPU @ 3.10 GHz This is display-only field and displays the information of the CPU installed in your computer. Processor Speed (3100MHz) This item shows the CPU speed. Total Memory (2048MB(DDR3 1333)) This item shows the total momery of DDR3. CPU Current Voltage (0.984V) This item diplays the CPU current voltage.

  • Page 58: Boot Menu

    Boot Menu This page enables you to set the keyboard NumLock state. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit Select the keyboard NumLock Boot Configuration state Bootup NumLock State [On] Quiet Boot [Enabled]...

  • Page 59: Security Menu

    Security Menu This page enables you to set setup administrator and password. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit Set Setup Administrator If ONLY the Administrator’s password is set, Password then this only limits access to Setup and is only asked for when entering Setup.

  • Page 60: Save & Exit Menu

    Save & Exit Menu This page enables you to exit system setup after saving or without saving the changes. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset M.I.B III Boot Security Save & Exit Exit system setup after saving Save Changes and Exit the changes.

  • Page 61: Updating The Bios

    Updating the BIOS You can download and install updated BIOS for this motherboard from the manufacturer’s Web site. New BIOS provides support for new peripherals, improve- ments in performance, or fixes for known bugs. Install new BIOS as follows: If your motherboard has a BIOS protection jumper, change the setting to allow BIOS flashing.

  • Page 62: Using The Motherboard Software

    Chapter 4 Using the Motherboard Software About the Software DVD-ROM/CD-ROM The support software DVD-ROM/CD-ROM that is included in the motherboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your motherboard version.

  • Page 63: Running Setup

    Drivers Click the Setup button to run the software installation program. Setup Select from the menu which software you want to install. Click the Utilities button to display the application software and Utilities other software utilities that are available on the disk. Select the sofware you want to install then follow installation procedure.
  • Page 64 Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recom- mended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.

  • Page 65: Manual Installation

    Windows Vista/7 will appear below UAC (User Account Control) message after the system restart. You must select “Allow” to install the next driver. Continue this process to complete the drivers installation. Manual Installation Insert the disk in the DVD-ROM/CD-ROM drive and locate the PATH.DOC file in the root directory.

  • Page 66: Intel ® Matrix Storage Manager Raid Configurations

    Chapter 5 Intel ® Matrix Storage Manager RAID Configurations ® The Intel Matrix Storage Manager allows you to configure RAID 0, and 1 sets on the external Serial ATA hard disk drives. Before creating a RAID set Prepare the following items: One SATA HDD.

  • Page 67: Entering Intel ® Matrix Storage Manager Raid Bios Utility

    ® Entering Intel Matrix Storage Manager RAID BIOS util- ® During POST, press <Ctrl-I> to enter the Intel Matrix Storage Manager RAID BIOS menu. ® The main Intel Matrix Storage Manager RAID BIOS menu appears. Use the arrow keys to move the color bar and navigate through the items. Intel ®...

  • Page 68: Creating A Raid Set

    Creating a RAID set ® In the main Intel Matrix Storage Manager RAID BIOS menu, highlight Create RAID Volume using the up/down arrow key then press <Enter>. When the RAID Level item is highlighted, use the up/down arrow key to select the RAID set that you want to create.
  • Page 69 When done, press <Enter> to confirm the creation of the RAID set. A dialogue box appears to confirm the action. Press <Y> to confirm; other- wise, press <N>. Pressing <Y> deletes all the data in the HDDs. The following screen appears, displaying the relevant information about the RAID set you created.

  • Page 70: Deleting A Raid Set

    Deleting a RAID set ® In the main Intel Matrix Storage Manager RAID BIOS menu, highlight Delete RAID Volume using the up/down arrow key then press <Enter>. Use the space bar to select the RAID set you want to delete. Press the <Del>...

  • Page 71: Resetting Disks To Non-Raid

    Resetting disks to Non-RAID An HDD that has been previously configured as part of another RAID set in another platform is called a broken RAID HDD. When you install a broken RAID HDD, you cannot select this disk when configuring a RAID ®...

  • Page 72: Trouble Shooting

    Chapter 6 Trouble Shooting Start up problems during assembly After assembling the PC for the first time you may experience some start up problems. Before calling for technical support or returning for warranty, this chapter may help to address some of the common questions using some basic troubleshooting tips.

  • Page 73: Start Up Problems After Prolong Use

    2. From the BIOS setting, try to disable the Smartfan function to let the fan run at default speed. Doing a Load Optimised Default will also disable the Smartfan. Start up problems after prolong use After a prolong period of use your PC may experience start up problems again. This may be caused by breakdown of devices connected to the motherboard such as HDD, CPU fan, etc.

  • Page 74: Basic Troubleshooting Flowchart

    Basic Troubleshooting Flowchart...
  • Page 75 Memo Trouble Shooting...

  • Page 76: Post Code Checkpoints

    POST Code Checkpoints The POST code checkpoints are the largest set of checkpoints during the BIOS pre-boot process. The following table describes the type of checkpoints that may occur during the POST portion of the BIOS : Checkpoint Description 01-0F SEC Status Codes &...
  • Page 77 CPU post-memory initialization. Boot Strap Processor (BSP) selection CPU post-memory initialization. System Management Mode (SMM) initialization Post-Memory North Bridge initialization is started Post-Memory North Bridge initialization (North Bridge module specific) Post-Memory North Bridge initialization (North Bridge module specific) Post-Memory North Bridge initialization (North Bridge module specific) Post-Memory South Bridge initialization is started Post-Memory South Bridge initialization (South Bridge module specific) Post-Memory South Bridge initialization (South Bridge module specific)
  • Page 78 FB-FF Reserved for future AMI error codes Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Reset PPI is not available Recovery failed S3 Resume failed DXE Core is started NVRAM initialization...
  • Page 79 9E-9F Reserved for future AMI codes IDE initialization is started IDE Reset IDE Detect IDE Enable SCSI initialization is started SCSI Reset SCSI Detect SCSI Enable Setup Verifying Password Start of Setup Reserved for ASL (see ASL Status Codes section below) Setup Input Wait Reserved for ASL (see ASL Status Codes section below) Ready To Boot event...
  • Page 80 ECS H67H2-M v 1.1 Описание Характеристики...
