Summary of Contents for Snooper DVR-2HD
-
Page 1: User Manual
DVR-2HD 270° Vehicle Drive Recorder Rotating Camera USER MANUAL... -
Page 2: Table Of Contents
Getting Started Product Features Explanation of LED Status and Buzzer Sound How to Remove microSD Memory Card Safety Warnings and Precautions 4. Using the Snooper Viewer What’s included Program Installation Running Program 1. Introduction to Product Snooper Viewer Control of Snooper Viewer... -
Page 3: Product Features
Product Features Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에 표시 Google Map에... - Page 4 주차 감시 모드 주차 감시 모드 ACC OFF 주차 중 움직임 및 충격이 주차 중 움직임 및 충격이 주차 감시 모드 주차 감시 모드 주차 감시 모드 주차 감시 모드 ACC OFF 주차 감시 모드 주차 중 움직임 및 충격이 주차...
-
Page 5: Before You Start
Before You Start Before reading the user manual, first check the following information Scope of Warranty and Liabilities • This product is a road safety accessory and the manufacturer is not liable for any losses brought on by malfunctions, loss of data or any other forms of losses from using this product. •... -
Page 6: Safety Warnings And Precautions
Do not cover or place anything on the product. If the unit ceases to operate, unplug the device and This may cause the product to overheat and cause contact your Snooper Technical on 01928 579579. premature failure of components. - Page 7 Safety Warnings and Precautions Use only the supplied power cable and windscreen bracket. Do not expose the device to liquids. Do not modify the supplied power cable and/or windscreen bracket. Do not install the product in an area which is Do not install product where it will obstruct your susceptible to moisture or dust.
- Page 8 Prolonged usage of an old micro SD memory card can SanDisk quality. lead to data loss. SanDisk SanDisk nDisk SanDisk SanDisk SanDisk Use only approved Snooper micro SD memory SanDisk cards. SanDisk Disk...
- Page 9 • The manufacturer will not be held responsible in the event of microSD card damage due to user negligence or external factors. • We recommend using Snooper 16GB microSD cards Causes of microSD Card Damage and Data Corruption • External impact during installation/uninstallation.
- Page 10 기 Safety Warnings and Precautions Preserving Data on the micro SD Memory Card 기기를 내려놓고 다음 사용할 장소에 본 기기를 내려놓고 다음 평평한 바닥이나 사용할 장소에 본 기기를 내려놓고 다음 포장을 벗겨낸 후 평평한 바닥이나 사용할 장소에 본 기기를 내려놓고 다음 Please pay attention to following information to minimize the possibility of losing recording data.
- Page 11 Safety Warnings and Precautions GPS Use • If you are using the product for the first time or using it after an extended period of non-use (3 days or Note longer), it will take longer than usual for the GPS to determine your current location. •...
-
Page 12: What's Included
을 구입하셨을 때 먼저 포장을 벗겨낸 후 평평한 바닥이나 사용할 장소에 본 기기를 내려놓고 다음 은 부속품이 모두 들어 있는지 확인해 보아야 합니다. 만약 부속품이 빠져있을 경우 제품을 구입한 로 문의하여 주시기 바랍니다. Snooper® DVR2-HD Power Cable microSD Card 16gb... -
Page 13: Introduction To Product
1. Introduction to Product Snooper DVR-2HD Camera lens To record images It is used to connect to the power Power input terminal cable. Memory card It is used to insert and remove the insertion slot microSD memory card. It is used to connect to the GPS GPS input terminal cable. - Page 14 1. Introduction to Product Snooper DVR-2HD Under the parking mode, it blinks, and while the car is parked, it is Security LED turned on under the event/motion recording. The LED blinks while the GPS cable is connected, and is turned on when GPS LED GPS signal reception begins.
-
Page 15: Name And Function Of Each Part Of Mounting Kit
Name of Each Part Function Mounting Kit Used to attach and detach the Snooper to the vehicle. Using double-coated tapes, the mounting kit can be fixed on the front glass of the Fixation of Mounting Kit inside of the car. -
Page 16: Installation
• Do not use the DVR without the mount. • Do not place any item between the DVR and the front windshield or cover up the Snooper. • Secure the mount in place using the double-sided tape. However, make sure the windshield area where you will be attaching... -
Page 17: Snooper Installation
2. Installation Snooper DVR-2 installation Check the general environment and the position on which the body shall be fixed. For the notice regarding the installation, please see page 5. This device should be installed on the upper center of the windscreen if you want to get the highest image quality. - Page 18 Connect the power cable to the "PWR" Connect the DC end of the power input on the recorder. cable into the car power outlet. You can Arrange the cables cleanly using a cable hardwire your DVR into your vehicle. holder. Find out more visit snooper.co.uk...
- Page 19 2. Installation 270° Rotation When the recording of the inside of vehicle is required, you can start the recording after rotating the body. • An alarm message appears when the microSD card is not normally recognized. (Voice message, LED) • For the connection of continuous power supply cables (3-phase), we recommend you to refer to a qualified service center. (Black line: GND/White line: ACC/Red line: BAT(B+)) •...
-
Page 20: How To Use The Product
3. How to Use the Product Power Connection and Continuous Recording • The product is in “ON” status automatically when the power cable is connected. Guiding comments after power connection – “Please Drive Safely” Sound Guiding comments after boot completed - "Driving recording is beginning. ” Power LED (Blue) “ON”... -
Page 21: Voice Recording On/Off
3. How to Use the Product Voice Recording ON/OFF • Press the “MIC Button” to turn on and turn off the voice recording mode. (Initial setting: ON) Guiding comments – “Voice recording is beginning. ” Sound Guiding comments – “Voice recording is stopping. ” MIC LED “ON”... -
Page 22: Parking Mode
Security LED is turned on. (N.B.: When the parking mode runs continuously, Security LED continues to blink.) • The recording modes during parking are applied according to the values set through the Snooper only viewer. Continuous Parking Continuous Recording, Shock Recording... -
Page 23: System Initialization
3. How to Use the Product System Initialisation • Function Setting Initialization: when SPK Button is pressed for 5 seconds, System Initialisation begins. Button & Operation Guiding Comment LED Status “Do you want to initialize the MIC LED & SPK LED Press SPK Button for 5 seconds. -
Page 24: Explanation Of Led Status And Buzzer Sound
3. How to Use the Product Explanation of LED Status and Buzzer Sound The LED status and buzzer sound of each situation are as follows: Classification Situation Guiding Comment LED Status Note “GPS system has been GPS connection GPS LED Blinking GPS cable connection after boot completion connected. -
Page 25: How To Remove Microsd Memory Card
Turn off the car and unplug the power cable from the DVR-2HD. Remove the microSD memory card from the card insertion slot by pressing the card. • Removing the microSD card while the Snooper is turned on will cause data corruption. Note... -
Page 26: Using The Snooper Viewer
4. Using the Snooper Viewer Software Installation The user can playback recorded video through the video player with a compatible computer. Windows XP, Vista and 7. Connect the SD memory Double-click Designate an installation After the installation card to a computer. -
Page 27: Running Program
4. Using the Snooper Viewer Running Program ► Snooper Suite Connecting the microSD memory card to the computer Running Program Insert the microSD card into the USB gender and then connect it to the Run the launcher program clicking the program icon of the USB terminal of the computer. -
Page 28: Snooper Viewer
4. Using the Snooper Viewer Snooper Viewer Name of Each Part Function Main Display The images captured by the camera are played. 3-Axis Sensor Value The shock values "X," "Y" and "Z" of shock sensor are indicated. The routing velocity of the car is indicated. (Products coupled with... -
Page 29: Control Of Snooper Viewer
4. Using the Snooper Viewer Control of Snooper Viewer Name of Each Part Function The operating environment of the Snooper is set. Setting Screenshot It is used to capture images immediately and store them. (PNG, JPG) Images are outputted by printer. - Page 30 4. Using the Snooper Viewer Control of Snooper Viewer Name of Each Part Function Replay The file containing the selected images is replayed. Pause The images being played are stopped for a while. Stop The images being played are stopped and the play goes back to the beginning.
-
Page 31: Fetching Recorded Image Data
4. Using the Snooper Viewer Fetching Recorded Image Data Checking Driving Route (GPS) Select the route through which the images you want have been The GPS location information is shown on the map along with the stored after pressing the button. -
Page 32: Other Operation Functions
4. Using the Snooper Viewer Other Operation Functions Full-size Image: If you right-click on the screen, the image is enlarged to the full size. -
Page 33: Setting Program
Speaker Volume The volume of buzzer sound and voice guidance sound is set. The recording time of the Snooper is set up. Time can be set just to the Time Setting time on the computer by retrieving the current time. (Check whether the time on the computer is the standard time.) -
Page 34: Setting Time
4. Using the Snooper Viewer Clock Used to set the unit’s clock. Select Retrieve Time to use the computer’s system clock settings. -
Page 35: Gmt Setting (Time Zone)
4. Using the Snooper Viewer GMT Setting (Time Zone) The standard time zone corresponding to the region of each country is selected. microSD Memory Card Storage Folder Folder Name Note • The files of continuous driving recording and parking recording, including motion recording, are stored. -
Page 36: Firmware Upgrade
Create the “UPDATE” folder in the microSD card. Copy the firmware file into the "UPDATE" folder. Connect the microSD card to the DVR-2HD and connect the power. Once the power is connected, the firmware is upgraded, the body reboots and the upgrade process is completed. -
Page 37: Product Specifications & Product Certification Process
5. Product Specifications & Product Certification Process Product Specifications Classification DVR-2HD Image Sensor 2-megapixel Channel 1 channel Camera Angle of View 130° Image Compression H.264 Mode Resolution 1280X720(HD) Frame 30 fps max. Recording Mode Continuous/Event/Parking Mode Recording Event Mode Perception of 3-axis shock sensor Applied for 15 sec. - Page 38 5. Product Specifications & Product Certification Process Product Certification Process Certificate of Broadcasting and Communication Equipment Certificate of Safety and Quality for the European Market Certificate of Federal Communications Commission of the USA RoHS Restriction of Hazardous Substances Directive...
-
Page 39: Troubleshooting
6. Troubleshooting If you are having trouble with this product, please check the following troubleshooting information before requesting servicing. Contact Snooper Technical Support only if the problem persists after implementing the measures described below. Problem Solution Video recordings are not being saved to the microSD •... - Page 40 Like us at Follow us @ A wholly owned subsidiary www.snooper.co.uk snooperuk snooperuk of Cobra Electronics UK Ltd Performance Products Ltd, Cleaver House, Sarus Court, Manor Park, Runcorn WA7 1UL. Tel 0333 240 1000 Fax 0333 240 1100...
