Summary of Contents for Snooper DVR-PRO
- Page 1 DVR- DVR- DVR- Professional Professional Professional Drive Recorder Drive Recorder Drive Recorder...
-
Page 2: Table Of Contents
Overview. Schematic diagram. Button and LEDs Installation guide. Record time table. On/Off operation. Smartphone app. Tv-Out interface. Snooper PC and MAC player. SD Card information. Firmware upgrade. Information and Guidance. Advanced connections. Troubleshooting. Service under warranty. DVR-PRo V1.0 EN 03/19... -
Page 3: Preface
Preface Thank you for purchasing the Snooper DVR-Pro dash Camera. Before installing or using this product please familiarise yourself with this user guide. Performance Products Ltd holds the copyright to this user guide and no part may be copied, reprinted or translated without the written permission of Performance Products Ltd. -
Page 4: Safety Instructions
There are no user serviceable parts inside the battery. It can only be • replaced by an authorised Snooper technical. Dispose of used batteries by observing local regulations. • Snooper products meet the requirements for transportation under • 967 Section II (UN3481, Lithium ion batteries packed with equipment). DVR-PRo V1.0 EN 03/19... - Page 5 It is normal for the device to get warm during use. • Improper use or operation of the product may result in damage of the • product or its accessories. This will void the warranty. DVR-PRo V1.0 EN 03/19...
-
Page 6: Packing List
SD card. It is the responsibility of the user to regularly review footage to check that videos and data are recording correctly. DVR-PRo V1.0 EN 03/19... -
Page 7: Technical Specification
Built-in Wi-Fi module (IEEE 802.11b/g/n, 2.412 Wi-Fi GHz-2.4835 GHz) Mobile terminal Snooper app(IOS V8.0 and above, Android V4.0 and above) Normal recording (card capacity of 79%, this space is automatically deleted after the old file coexistence of new files) Video... - Page 8 1920*1080 16M @30fps / 1280*720 12M @30fps /Frame rate Note: resolution / frame rate / bit rate is currently only two of the defaults Loop recording 1, 2 or 3 minutes optional PC/MAC player Snooper player DVR-PRo V1.0 EN 03/19...
- Page 9 Note: the vehicle is off and after full charge (within 10 min) Ideal operating -25 ° C to 65 ° C temperature Operating -40 ° C to + 85 ° C temperature storage -40 ° C to + 90 ° C temperature DVR-PRo V1.0 EN 03/19...
-
Page 10: Overview
Definition of power cord. Yellow Black Orange* Green* Emergency record button Brown* *Refer to advance connections on page #37 DVR-PRo V1.0 EN 03/19... -
Page 11: Schematic Diagram
Lock cover Camera Lens Front view GPS antenna Rear camera Video-In Double-sided tape Power Button Rotary Power cord shaft cover outlet hole HDMI Lock Left view Right view Reset button Red LED Blue LED Speaker Rear view DVR-PRo V1.0 EN 03/19... -
Page 12: Button And Leds
Installing the front camera. 1. Firstly, decide the optimum position for the unit, ensuring that it des not obscure the drivers view. The best position is usually in the center of the windscreen at the top, DVR-PRo V1.0 EN 03/19... - Page 13 5. Route the power cable by tucking it neatly across the top of the windscreen and down the A pillar. This is located at the side of the windscreen, down the same side of the vehicle where the fusebox is located. DVR-PRo V1.0 EN 03/19...
- Page 14 Note: Newer vehicles may have a battery save function. They have timed 'timed fuses' which stay live for a set number of minutes after the car ignition is turned off. DVR-PRo V1.0 EN 03/19...
-
Page 15: Record Time Table
128G Camera Res. bps Normal Event Normal Event Normal Event Normal Event Normal Event Front 1080P 30fps 16M Camera 25fps The 2nd 720*480 Camera 30fps Front 1280P 30fps 12M Camera 25fps The 2nd 720*480 Camera 30fps DVR-PRo V1.0 EN 03/19... -
Page 16: On/Off Operation
The Red and Blue LEDs will flash rapidly when the button is pressed. Smartphone App. 1. Download and install the App. For optimum user experience, download and install Snooper DVR-Pro app from either the Apple or Android App stores. DVR-PRo V1.0 EN 03/19... - Page 17 For Apple users, search ''Snooper DVR-PRO'' in the App stre search to download and install. Android users go to the Google Play Store search for "Snooper DVR-Pro" to download and install. 2. Connect the device via Wi-Fi Once the app has been downloaded and installed, turn on the device and connect it to your smart-phone.
- Page 18 Back Recording indicator Switch Record/ Stop Capture Refresh Mute/Unmute recording between Front and Rear Android App Live preview * To switch between front and rear camera view you camera (if must STOP recording before switching. fitted)* DVR-PRo V1.0 EN 03/19...
- Page 19 Click the App home page "Settings" to enter the settings page, you can set up the vehicle recorder and query related information. Note: Setting the black bold item in the sub-menu indicates the default settings for the recorder. DVR-PRo V1.0 EN 03/19...
- Page 20 Clip Time: Set the recording duration of each video clip/file. Option 1 minute, 2Minutes or 3 Minutes Press OK to save. Note: The video clip duration and resolution can affect the transfer time, via WiFi, between the device any the smart phone. DVR-PRo V1.0 EN 03/19...
- Page 21 Note: If the sensitivity is set too high the SD card may become full with 'protected files' 4) TVOUT The device supports video output to a third-party AV display, the screen display format can be set through this function. DVR-PRo V1.0 EN 03/19...
- Page 22 Note: Parking guard can be used only when the car battery is used to ensure the provision of permanent power for the device. See page 13 section 7 for connection instructions. DVR-PRo V1.0 EN 03/19...
- Page 23 If you can not read the SD card or if the card is full with events/protected files you can also try formatting the card. Note: Formatting the SD card will erase ALL data/files from the card. DVR-PRo V1.0 EN 03/19...
- Page 24 SSID and/or password to connect the device to your smart phone. Note: If you forget your password, you need to reapply the device firmware by using the upgrade function. This will return the WiFi setting to the factory default. DVR-PRo V1.0 EN 03/19...
- Page 25 Click the "..." button on the right to download the video or photo. Note: 1) When downloading file, to maintain download stability the device does not allow any other operations or functions other than can 'cancel' the download. DVR-PRo V1.0 EN 03/19...
- Page 26 Android users can view the downloaded video or photographs. The files will be stored in the mobile phones SD card root in a folder named "Snooper " . DVR-PRo V1.0 EN 03/19...
-
Page 27: Tv-Out Interface
The output interface is shown below: Recording Recording Video lock resolution and indicator information indication frame rate Video mode Speaker off Parking guard SD Card status Real-time Preview WIFI state Current date time Rear view Video duration Front view DVR-PRo V1.0 EN 03/19... -
Page 28: Snooper Pc And Mac Player
The player can view the information recorded in the video, such as GPS location, speed and gravity acceleration. 1. Get Snooper player. Download and install the Snooper player from: wwww.snooperneo.co.uk 2. Player interface Click on the desktop short-cut to open the player... - Page 29 25. Rear Camera video (option) 3. Playback video Open the Snooper player and click on 'add media files ' (23) this will open a new window, allowing you to browse your computer for video files. Select the removable 'disk drive' and choose 'normal', 'event' or 'photo' folder.
- Page 30 Playback volume can be adjusted by using the slide control (8). You can also adjust the size of the Snooper player window through the window control button (16) or view the video in full screen mode use the full screen button (19). To exit full screen press 'esc'. 4. Settings/ preferences.
- Page 31 To zoom in and out use the '+' and '-' buttons and to view the map in full screen use the button. Press 'esc' to exit full screen. A and B on the map indicate the start and end locations of the video clip and the route taken. DVR-PRo V1.0 EN 03/19...
- Page 32 The rear camera video playback widow will be automatically be displayed on the screen. Note: this window can be moved to any position within the player window by moving it with the computer mouse. DVR-PRo V1.0 EN 03/19...
-
Page 33: Sd Card Information
If you are using the device first time, please format the SD card. Backup any important data in the card before formatting. Turn on the device, open the "Snooper " app and connect it to the device via WIFI. Enter the "Settings" page, click the "formatting", and then click "OK"... -
Page 34: Firmware Upgrade
Then insert the SD card, including the firmware files, into the card slot. Soft upgrade method: Turn on the vehicle ignition to switch the device ON. The upgrade process will then begin. DVR-PRo V1.0 EN 03/19... -
Page 35: Information And Guidance
After the smart phone is connected to the device by WiFi, open the Snooper app and the time from the smart phone will synchronize to the device automatically. DVR-PRo V1.0 EN 03/19... - Page 36 ◆ The unit will continue to charge for approximately 10 minutes once the ignition is switched off. ◆ Be sure to clean the device recorder lens and the front windscreen, inside and outside for the optimum picture clarity. DVR-PRo V1.0 EN 03/19...
- Page 37 Please remember the new WIFI password, otherwise you can only recover the device by performing an upgrade. ◆ The GPS antenna is located in the 'shaft'. If the front windshield has a metal membrane, this will affect the GPS signals reliability. ◆ DVR-PRo V1.0 EN 03/19...
-
Page 38: Advanced Connections
Orgage cable to the reversing light circuit and when reverse gear is engaged the camera will switch to the AV monitor. Note the AV monitor should be connected to TV-OUT. IR/RX - Green wire. Not used Alarm out (-ve) - Brown wire. Not used DVR-PRo V1.0 EN 03/19... -
Page 39: Troubleshooting
❷turn off and restart preview ❸format the SD card ❶format the SD card SD card won't record ❷Replace the SD card (Class10) For product assistance please contact our support team 0333 121 2252 or visit www.snooperneo.co.uk DVR-PRo V1.0 EN 03/19... -
Page 40: Service Under Warranty
Faulty Products from 31 days to 12 months from purchase. Return the device to Snooper (Performance Products Ltd) who will offer a prompt repair service. In all cases we reserve the right to inspect the product and verify the fault. - Page 41 This Snooper product is warranted against all defects in both materials and workmanship for a period of one (1) year. This is from the date of original purchase. The product must be purchased from an authorized Snooper dealer. ALL PURCHASES OF SNOOPER PRODUCTS FROM NON-AUTHORIZED SNOOPER DEALERS ARE SUBJECT TO FURTHER WARRANTY RESTRICTIONS AS DESCRIBED BELOW.
- Page 42 Snooper will not assume responsibility for any loss or damage incurred in shipping. 9. The sole responsibility of Snooper under this Limited Warranty shall be limited to the repair or replacement of the product only (whichever is deemed appropriate and at the sole discretion of Snooper).
- Page 43 DETACHED AND CREATE A CHOKING HAZARD. Battery We recommend that you fully charge the battery before you use Snooper for the first time. Batteries which are new, or ones that have not been used for a long time can initially have a reduced capacity.
- Page 44 Performance Products Ltd, Cleaver House, Sarus Court, Manor Park, Runcorn, Cheshire, WA7 1UL. United Kingdom Tel +44 (0)1928 579579 E: customerservices@snooper.eu. Copyright © 2019 All rights reserved. All other marks, products or company names mentioned in this guide are trademarks of their respective companies.
