- Page 1 SpliceCom PCS 505 Operating Instructions & User Guide...
- Page 2 Figure One...
-
Page 4: Telephone Features
The SpliceCom PCS 505 telephone has been designed for use with the SpliceCom maximiser business telephone system. Telephone Features Please refer to Figure One at the front of this user guide. Wall mounting – Using the template supplied, position where you want to fix your telephone. - Page 5 This jack is used to connect a Headset to your telephone. To adjust Headset volume Declaration of Conformity SpliceCom declares that this product SpliceCom PCS 505 is in conformity with the following harmonised standards: Health Safety EN 60950 : 1992 Electromagnetic Compatibility EN 55022 : 1998 &...
-
Page 6: Intended Use
Because the product is connected behind a PABX it must not be relied upon to contact the emergency services during a power failure. The following section explains how to use your SpliceCom PCS 505 with the SpliceCom maximiser business telephone system. - Page 7 Conclude the original call and put the handset down, the original call will clear and the new one will ring. System Feature Access Guide: The following maximiser system features can be accessed by using the telephone keypad of your PCS 505. • Voicemail Access – Dial “ 50” • Call Park – Dial “Recall ”...
- Page 8 (if configured). Collecting a message: Messages can be collected by; dialling 50 from your PCS 505, dialling a general number configured by your administrator, dialling the external DDI number for the Voicemail, or dialling your extension number, then pressing during the greeting.
- Page 9 Navigation: You can navigate you way through messages if required by pressing buttons on the PCS keypad. It is probably easier to remember them by referring to the chart below which is also provided on the PCS 505 keypad: 5 - Forwarding options: 1 –...
- Page 10 3 – Set forwarding 1 – Options 2 – Cancel forwarding 3 – Forward personal/direct calls to home number 4 – Forward personal/direct calls to mobile number 5 – Forward personal/direct calls to spare1 number 6 – Forward personal/direct calls to spare2 number 7 –...
- Page 11 PCS 60, PCS 50 and PCS 505: Even greater personal productivity can be realised when you use your PCS 505 phone alongside SpliceCom’s PCS 60 or PCS 50 Phone Partner application. These desktop solutions deliver similar functionality to SpliceCom’s top of the range PCS 410 IP Phone and are available for Microsoft Windows and Apple Mac OS X (PCS 60) and Linux (PCS 50) PCs and laptops.
- Page 12 In the event that a model may have been discontinued, any replacement will have similar or enhanced features. In the event that you have to return a faulty unit, please contact the Accredited SpliceCom reseller you purchased your PCS 505 from. This warranty is in addition to any statutory rights.
- Page 13 This telephone is approved to EEC directive 1999/5/EC SpliceCom Limited The Hall Business Centre, Berry Lane Chorleywood, Hertfordshire, WD3 5EX Tel:01923 287700 Fax:01923 287722 Email:info@splicecom.com Website:www.splicecom.com 3CPCS50511-38SP...
