- Page 1 K9 SERIES USER’S MANUAL 960H DVR K9-a400 K9-a900 K9-a1600 K9-a400 For safe use of system and to prevent product failure or accident, please read this manual carefully before use.
-
Page 2: Before Usage
K9-a Series Manual Before Usage This product has been designed and manufactured to assure personal safety. Improper use can result in electronic shock or fire hazard. The safeguards incorporated in this product will protect you if you observe the following procedures for installation, use, and servicing. This product does not contain any parts that can be repaired by user. - Page 3 K9-a Series Manual Note of Caution Warning Check if the power is switched off before Check if the power is switched off before installation. Don‟t plug in at the same time. installation or additional repair. Never plug in Otherwise it may be set on fire or put you at while the device is in operation.
- Page 4 K9-a Series Manual When strange noise or smell is sensed, Do not install device in humid place filled with immediately plug out and send inquiry to dust. It might be the cause of electrocution and service center or seller. fire. Caution Do not install the device in any place where Do not put anything heavy on the product.
- Page 5 K9-a Series Manual When HDD saving data gets old enough, video When any abnormal sign is detected, data to be saved may suffer so much damage Immediately contact seller or service center. that it may be irreparable. If screen appears broken while regenerating data saved in HDD, means won‟t...
- Page 6 K9-a Series Manual Check Components Software Battery Screw Remote Mouse Adaptor Power Cable Controller Component Description Stand Alone Digital Video Recorder Battery 1.5V (AAA) 2 PCS. Screw For HDD mounting Software USB USB with manual, Client software, and KT&C product specs Adapter DC 12V 5A Power Cable...
-
Page 7: Table Of Contents
K9-a Series Manual - Contents – Chapter 1. Features & Components 1-1 Features……………………………………………………………………………………………..……………………………………….9 1-2 Name and function of front panel……………………………………………………..……………………………………….10 1-3 Rear panel…..…………………………………………………………………………..…………………………………….11 1-4 Remote Controller……………………………………………………………………………..……………………………………….12 Chapter 2. Basic Information 2-1 Menu Display…………………………………………………………..…………………………………………..…………….…….16 2-2 Description of Icon…………………………………………………………………………………………………………..…..…..…16 2-3 Remote Controller……….……………………………………………………………………………………….…………………..…..18 2-4 How to set remote controller ID………………………………………………………………………………………..….…..20 2-5 How to display menu…………………………………………………………………………………………………………………... - Page 8 K9-a Series Manual 5-3 Email Notification…………..……………………………………………………………………………………….………………….36 5-4 Web Server…..…………………..……………………………………………………………………………………….………………….36 5-5 Free DDNS...…………………..…………………………………….………………………………………………….………………….37 5-6 Dual Codec Setup……………..…………………………………………………………………………………….………………….37 Chapter 6. Camera 6-1 Camera Setting……………...…………………………………………………………………………………………..…………..…38 6-2 Camera Title……………...…………………………………………………………………………………………..…………..…38 6-3 PTZ Setting………………………………………………………...………………………………………………………………...……39 6-4 How to use PTZ……….…………………………………………..………………………………………………………………...……40 Chapter 7. Record 7-1 Record Setting….……………………..………………………….……………………………………………………………….……….42 7-2 Weekly Record……………………..………………………………………………………………………………….……….……….43 Chapter 8.
-
Page 9: Chapter 1. Features & Components
K9-a Series Manual ▒ Chapter 1. Features & components ▒ 1-1. Features The highly advanced and high-performance video recorder is designed to make it easier to install and use with safety. Main feature ㆍAble to control the PTZ by using mouse like joystick ㆍFront USB port for easy backup ㆍAble to back up by ODD (optional) ㆍSupport GIGA bit Ethernet. -
Page 10: Name And Function Of Front Panel
K9-a Series Manual 1-2. Name and Function of Front Panel (Front Panel Image) Button/Function Description Use as a control button on Setup menu Direction Button / Playback Button Speed control on playback, Stop button, Pause button. Menu Display a menu, Move to upper menu, Cancel a function Pan/Tilt Display Pan/Tilt menu Audio... -
Page 11: Rear Panel
K9-a Series Manual 1-3. Rear Panel This unit requires no special tools for DVR installation process. (4Ch rear panel) (9Ch rear panel) K9-a Series Manual... -
Page 12: Remote Controller
K9-a Series Manual (16Ch rear panel) [1] VIDEO INPUT [2] VIDEO LOOP OUT [3] RJ-45 [4] USB (REAR) [5] RS-485 [6] ALARM OUT [7] SENSOR INPUT [8] SERIAL PORT [9] AUDIO INPUT [10] AUDIO OUT [11] E-SATA INPUT [12] VGA OUT [13] COMPOSITE MONITOR OUT [14] SPOT OUT [15] POWER INPUT... -
Page 13: Video Input
K9-a Series Manual 【Video Input】 Use BNC connector to connect coaxial video source. 【Loop through Video out】 【VGA Out】 It is for VGA connection monitor use. K9-a Series Manual... -
Page 14: Alarm Out Connection
K9-a Series Manual 【RS-485 connection (PTZ camera)】 PTZ camera Please refer to above diagram for PTZ connection. 【RS-485 connection (External keyboard connection)】 Please refer to the keyboard manual for setup. 【Alarm Out connection】 It supports 1 alarm out. Please refer to above diagram for proper setup. K9-a Series Manual... -
Page 15: Sensor Input Connection
K9-a Series Manual 【Sensor Input connection】 The DVR supports 4 sensor inputs. Please refer to above diagram for proper setup. 【RJ-45 Port(Internet connection)】 The DVR can be connected to the network through 10/100/1000Mbps ethernet connection for remote viewing capability. 【USB Port】 There are 2 USB ports each on front and back. -
Page 16: Chapter 2. Basic Information
K9-a Series Manual It is for HDMI connection monitor use. 【E-SATA】 It is for the external HDD connection. It needs E-SATA cable for connection. ▒ Chapter 2. Basic Information ▒ 2-1. Menu Display It‟s available to call setup menu with menu button on front panel, a mouse or the remote controller. - Page 17 K9-a Series Manual Recording Motion Detection Sensor [2] Camera title will be shown as above. K9-a Series Manual...
-
Page 18: Remote Controller
K9-a Series Manual [3] Status Bar 1. Display date and time 2. ER means Emergency Recording and SR means Schedule Recording. 3. Show network status and key lock status. 4. Show HDD status and display “Overwrite” when overwrite function is enabled. 2-3. - Page 19 K9-a Series Manual [1] ID : Press to select a remote controller ID in case of using one remote to control multiple DVRs. [2] SPLIT : Press to display various split modes. Keep pressing the same button will toggle different modes. [3] BACK UP : Press to start archiving stored data to external media.
-
Page 20: How To Set Remote Controller Id
K9-a Series Manual [9] SET UP : Press to display setup menu. [10] DIRECTION KEY / CONFIRM BUTTON / PLAYBACK CONTROL [11] Record Button – toggle between Emergency Recording and Schedule Recording • EMERGENCY : Emergency Recording Button • SCHEDULE : Schedule Recording Button 2-4. -
Page 21: How To Display Menu
K9-a Series Manual Remote controller ID menu displays as above image when you press ID button of remote controller. • DVR ID : It displays current ID of the system. • “0” : Input the same ID number of DVR and press “Confirm” 2-5. -
Page 22: Zoom In/Out
K9-a Series Manual 2-6. Zoom in/Out Magnify the image at live or playback. [1] How to magnify with a mouse Move the mouse pointer to the position you want to magnify. And hold down left button and drag it to select an area. You can cancel the selection by making another selection within the selection. -
Page 23: Time/Date
K9-a Series Manual [1] Remote ID : Assign the ID of remote controller so that user can control multiple DVRs with one controller. (ID range : 0 ~ 99) [2] Language : Select a language [3] Version : Show Software, Hardware and Network version information [4] Health : Indicates storage status. - Page 24 K9-a Series Manual [1] Time : Set time [2] Date : Set date [3] Date format : Select a Time/Date display format. [4] Daylight Saving Time : Set “ON” to apply daylight saving time. Enter Month/Week/Day to begin and also enter Month/Week/Day to end. [5] Time Server : Set time automatically through internet.
-
Page 25: Password
K9-a Series Manual • Time server : Input the URL of server (Default : us.pool.ntp.org) • Synchronize Period : Select the period to syncronize between DVR and time server • Power On : Try to sync once power on. • 12Hour : Try to sync every 12 hours. •... -
Page 26: Hard Disk
K9-a Series Manual • Hard Disk : Permission to set Hard Disk • Search : Permission to search • Backup : Permission to back up • PTZ Setting : Permission to control PTZ • PTZ OSD Menu : Permission to access PTZ OSD menu •... -
Page 27: Default Setup
K9-a Series Manual • Hard Disk 1~2 : Display the hard disk capacity internally mounted • E-SATA : Display the capacity of E-SATA • Delete : Select a disk and format(delete) it [2] Total : Display total capacity and used capacity of Hard Disk [3] Over write : Record continuously by overwriting the hard disk [4] Erase Data : Format hard disks by type •... -
Page 28: Upgrade
K9-a Series Manual [1] Default Setup : Except major configuration (Network, Password), parameters are initialized. [2] Factory Setup : All parameters are initialized. 3-6. Upgrade [1] Firmware Update : In order to update system firmware with USB memory stick, the firmware file must be saved in the USB‟s root folder and then insert to DVR to start the update from the menu. -
Page 29: Rs-485
K9-a Series Manual • Auto key lock : When there is no key input during selected period of time, system will lock keys automatically. In order to unlock, the user need to input the password. (10 sec., 30 sec., 1 min., OFF) •... -
Page 30: Split Mode
K9-a Series Manual [1] Camera Title : ON / OFF [2] Status Bar : ON / OFF. [3] Multiscreen Border : ON / OFF. [4] Display Lock : Select a display lock option • Off : Display live image after reboot. •... - Page 31 K9-a Series Manual • Default 16 split mode. • Select 16 split mode then press “QUAD” button to setup 16 split mode. 13 Split mode (For 16Ch Model) • 13 split mode provides 2 different group of display. • Select 13 split mode and press “QUAD” button to display 13 split mode on the screen. Press “Right”...
- Page 32 K9-a Series Manual • 9 split mode provides 2 different group of display. • Select 9 split mode and press “QUAD” button to display 9 split mode on the screen. Press “Right” direction button to select the group 1 or group2. 6 Split mode (For 9/16Ch Model) •...
-
Page 33: Auto Sequence
K9-a Series Manual • 4 split mode provides 4 different group of display. • Select 4 split mode and press “QUAD” button to display 4 split mode on the screen. Press “Right” direction button to select the group 1, group2, group 3 or group 4. 4-3. -
Page 34: Tv Adjustment
K9-a Series Manual Control spot output on rear panel. By using additional monitor, event triggered video display and sequence display are available. [1] Mode • Sequence : Display videos of selected channels in order. • Event : Display event triggered channel. •... -
Page 35: Ip Address
K9-a Series Manual 5-1. IP Address This setup allows user to connect DVR to the network so that it can be viewed at remote location. The user must know whether their internet is dynamic IP (DHCP) or fixed (static) IP. Please check with your Service Provider (ISP) before setup. -
Page 36: Email Notification
K9-a Series Manual E-mail Setup It‟s a basic setup to send email, so if it is not correct, email cannot be delivered. So be careful to make Setup correctly. [1] SMTP Server : Enter email server address to use as SMTP server. If you don‟t know the server address, contact a person who manages SMTP server you use. -
Page 37: Web Server
K9-a Series Manual Select which type of notifications you are going to use. Notification type : You can select the type for email notification. • Alarm : Email is sent with still image when an alarm occurs. • Sensor : Email is sent with still image when triggering a sensor •... - Page 38 K9-a Series Manual Free DDNS service is provided by KT&C DVR products. [1] Go to http://www.ktncddns.net and register your DVR using your DVR‟s Web Code. The Web Code can be found in „System – Information‟ menu. K9-a Series Manual...
-
Page 39: Dual Codec Setup
K9-a Series Manual [2] Create your own domain name and register. [3] After registering is successful, log onto your DVR remotely by using registered IP address. Ex) http://myfirstconnection.ktncddns.com 5-6. Dual Codec Setup It is available to transmit data through extra network transmission codec. Split Resolution is for multi channel mode and Popup Resolution is for single channel full screen. -
Page 40: Camera Title
K9-a Series Manual • Channel : Channel selection • Covert : camera covert setup · On : It doesn‟t display the image · Off : Display the image • Brightness : Brightness control • Contrast : Contrast control • Saturation : Black/White control •... - Page 41 K9-a Series Manual [1] Channel : Select a channel [2] ON/OFF : Enable or disable to use PTZ. [3] MODEL : Select the PTZ protocol or, model [4] ID : Select the PTZ ID. (For more detail, refer to the manual of PTZ device.) Advanced [1] Reverse Control (Pan) : Set the Pan works reverse direction.
-
Page 42: How To Use Ptz
K9-a Series Manual The touring number is selectable 1~16. [1] Touring number : Select the number. [2] Preset number : Select the preset number saved before. [3] Touring interval : Select the touring dwell time in seconds. [NOTE] PTZ protocol selection Protocol is PTZ moving driver. - Page 43 K9-a Series Manual • When you select PTZ button, + shape icon appear. Then move to the channel you want by the direction key. (2) If you moved to PTZ channel, then after pushing “SET UP” button, select the menu to operate. •...
-
Page 44: Chapter 7. Record
K9-a Series Manual (Preset Save) (Preset moving) • Tour : It activates saved tour number. • MENU : It calls the PTZ OSD menu. • Channel : Change channel at split screen. Available to move with direction button after selecting a channel. -
Page 45: Weekly Record
K9-a Series Manual [1] Channel : Set channel [2] On/Off : Set 'On' or 'Off' for recording [3] Resolution : Set resolutioin [4] Quality : Set picture quality of recorded video [5] Frame Rate : Set record frame rate [6] Post-Recording : Set recording duration time after an event is triggered. [7] Audio : Set On or Off for audio recording [8] Total Frames : It shows the occupied frames from total record frames. - Page 46 K9-a Series Manual [How to setup] • Select a channel • After selecting the day of the week and time, every mouse click toggles between different modes N(Grey) → C(Green) → M(Blue) → S(Red) → M+S(Yellow) • After selecting the other day of the week and time, every OK button click makes color shift. •...
-
Page 47: Chapter 8. Event Setup
K9-a Series Manual ▒ Chapter 8. Event Setup ▒ 8-1. Sensor It is for sensor setup. [1] Sensor Input : Select the sensor input channel. [2] On/Off : Select the sensor usage. [3] Input Type : Select the sensor input type. •... -
Page 48: Event Action
K9-a Series Manual The cursor moving by the direction key and if press “enter”, this block is designated for motion detection. • MD selected area : Pink color • MD non-selected area : Transparent • If the movement is detected, the color of that area turns green. [Apply to all] If you use the following key, you can apply or release in one button “No1”... - Page 49 K9-a Series Manual • Channel : Select the channel to apply. • Preset channel : Select the preset camera being applied for the event. • Preset number : Select the preset number to move. • Popup Channel : Select the usage Popup usage by ON/OFF. •...
-
Page 50: Chapter 9. Search
K9-a Series Manual • Relay duration : Relay out duration. • Internal buzzer : Internal buzzer usage. [3] Video loss : It is the setup for PTZ, pop-up, relay out, buzzer in video loss. • Channel : Select the channel to apply. •... -
Page 51: Calendar Search
K9-a Series Manual · Calendar search : It allows to search by calendar. · Date /Time search : It allows to search for specific Date/Time. · Event search : It allows to search by events. · Go to first : It allows to search the first recorded data on HDD. ·... -
Page 52: Date/Time Search
K9-a Series Manual 9-3. Date/Time search If you know the specific date/time to search, input the date/time to search. [1] Record Begin : It shows the first recorded data. [2] Record End : It shows the last recorded data. [3] Channel : Select the channel to search. [4] Play Begin : Input the time to search. -
Page 53: Event Search
K9-a Series Manual 9-4. Event search It searches for event data. [1] Disk : Select recorded data location. [2] Day : Select date of the event. [3] Channel : Select the channel to search. [4] Event Type : Select type of event you want to search for. [5] Play : When you click “Play”, it will start playback. -
Page 54: Search Control
K9-a Series Manual 9-6. Search Control [Control by mouse] Description of search button [1] Real-time playback [2] Pause [3] Stop [4] Reverse playback [5] Playback speed control [6] Reverse playback speed control [7] Audio during playback [8] Calendar search during playback [9] Mark In-Mark Out : If you click it during playback, it recognizes as a backup start time and if you click it once again, it recognizes as a backup end time. -
Page 55: Chapter 10. Backup
K9-a Series Manual [1] Menu recall : When you select the “Audio Out” during the live or playback, the audio menu will show up. The menu call is possible by both remote controller and mouse. [2] Mode selection • OFF : No audio use. •... - Page 56 K9-a Series Manual [2] Select the date from Calendar. [3] Select the hour. [4] Select the minute. Once you select “Start“, the backup start time will be automatically input. K9-a Series Manual...
- Page 57 K9-a Series Manual [5] Backup end time selection • If the backup end time is the same hour, select the minute and click, “end“, the backup end time will be automatically input. • If the backup end time is the different hour, go back to the previous menu by right click or “MENU”...
- Page 58 K9-a Series Manual [8] Before backup, it shows the USB port used, backup time, and various backup options. • Log Backup : The log file will be saved together. • Password : Backup data can be protected by the password. •...
- Page 59 K9-a Series Manual [10] When the backup is complete, you will see the below icon as a file in USB stick. When you run it, the playback starts. [11] How to use the viewer program (If you click the backup file, it runs automatically). ①...
- Page 60 K9-a Series Manual ▒ 11. Mobile Viewing by iPhone ▒ 11-1 Install App Go to Apple Store and download „KVRmobile‟. Then install the KVRmobile. 11-2 Execute the program When the installation is complete, the following icon is created. Select the icon to execute. K9-a Series Manual...
- Page 61 K9-a Series Manual 11-3 Register Remote Site information Enter the network information to access the DVR with iPhone. [1] Register Execute the app in iPhone and click “New” to add a remote connection. [2] Enter Name. Any name can be used for „Name‟ section. K9-a Series Manual...
- Page 62 K9-a Series Manual [3] Select the type of device [4] Enter the DVR ID and Password. ◎ DVR ID : Enter the ID registered in the DVR ◎ Password : Enter the password registered in the DVR (Note : You can check the ID and password in the DVR Setup Menu) [5] Enter the IP address of the DVR K9-a Series Manual...
-
Page 63: Live Monitoring
K9-a Series Manual [6] DDNS – This function shouldn‟t be used and must be set to „OFF‟ position at all time. After setting all, press “ADD” to save. 11-4 Live monitoring [1] Click the registered “DVR Name”. K9-a Series Manual... - Page 64 K9-a Series Manual [2] Connect remotely For a channel selection, click “CH SELECT” to select a number. Relay can be controlled remotely. Click “PTZ” to control Pan/Tilt/Zoom of PTZ camera. Disables display of time, resolution, channel, etc. and displays the video only. When selected, it transmits still images with certain intervals in case video streaming is interrupted due to the network load.
- Page 65 K9-a Series Manual [1] Select Date/Time After selecting a date, select “SEARCH”. [2] Search key operation Play reverse Pause Play K9-a Series Manual...
-
Page 66: Relay Out
K9-a Series Manual Switch to Live 11-6 Relay out Relay can be controlled remotely. Time selection : Set the duration of alarm output Off : Alarm off Infinity : Keep the alarm output continued. 11-7 PTZ control PTZ control is available on iPhone. K9-a Series Manual... - Page 67 K9-a Series Manual (1) Select (2) Cancel (3) Automatic camera focus (4) Call the PTZ menu (5) Direction button (6) Camera focus control (7) Camera zoom control (8) Select the channel (9) Relay out button (A user can set relay out) (10) Select the PTZ menu (11) OSD display On/Off button for live screen ▒...
- Page 68 K9-a Series Manual screen. 12-2 Execute App Select “KVRmobile” to execute. (Select the icon) (Executed Program) 12-3 Register the remote site information Register the remote site information for remote viewing. [1] Add K9-a Series Manual...
- Page 69 K9-a Series Manual Select “Add” to start the registration. [2] Enter the DVR information (1) Enter the name, User, Password, and Port information. Name : Enter any name you want. User : Enter the “User ID” registered to the DVR. Password : Enter the “Password”...
-
Page 70: Remote Connection
K9-a Series Manual 12-4 Modify/Delete of Registered Information If you want to modify or delete the registered information, select the triangle-shaped icon. Select to edit the registered info. Select to delete the registered info. Close Tool menu (As a dual function, it ends the connection) 12-5 Remote connection Select the registered DVR list for connection. - Page 71 K9-a Series Manual brief information. When you click the red-colored background, detailed information would appear. Click OK to execute the viewing program. (Select the list) (Detailed information) 12-6 Live Live shows the streaming of video from each camera in real-time. (1) Number : The channel number currently displayed is shown with bold white.
-
Page 72: Main Menu
K9-a Series Manual different by model.) (2) OSD : You can turn on or off the display for channel number, date, time, event, etc. (3) I frame : It transmits still images with certain intervals in case video streaming is interrupted due to network load. - Page 73 K9-a Series Manual Go back to the previous step or close the connection. Move to live mode (Channel change, 1 Frame and OSD display is available) Go to PTZ mode Go to PTZ preset mode Go to search mode Go to alarm mode Screen Capture App registered info.
- Page 74 K9-a Series Manual 12-9 PTZ You can control the PTZ camera remotely. (Select PTZ mode) (PTZ mode screen) (1) Go to PTZ mode Select the PTZ connected channel and click the PTZ button. (2) How to control PTZ The PTZ camera moves to the selected direction. Zoom in/ out Focus adjustment Touring operates according to the previously registered „Preset‟...
-
Page 75: Ptz Preset
K9-a Series Manual Call the PTZ menu Auto Focus OK button for PTZ OSD menu Cancel or the upper menu on PTZ OSD menu 12-10 PTZ Preset You can set the movement of PTZ camera previously and make the automatic PTZ movement. (Select preset mode) (Preset mode screen) (1) How to go to preset mode... - Page 76 K9-a Series Manual 12-11 Search (1. Select the search mode) (2. Select “Time Search”) (3. Select the date and time) (1) Select the search mode (2) Select “Time Search” : Select “Time Search” to enter the search conditions. (Note : Select “To Live” to return to the live mode during the search.) (3) Enter the date and time : Select the date and time and click “Start Search”...
-
Page 77: Screen Capture
K9-a Series Manual 12-12 Relay Out Relay can be controlled remotely. (1) Relay : Select On or Off (2) Number : Select the relay number. (3) Time : Select the duration time. 12-13 Screen Capture This function allows to save current screen capture. The screenshot will be saved into your SD card. -
Page 78: Information Display
K9-a Series Manual 12-14 Information display It shows the information of current connection. (Select info) (Display the connection information) [Display Info] Below is the example for an explanation. • IP : 61.250.157.37 : 2000 Via DDNS ← Connected IP information. •... - Page 79 K9-a Series Manual (Select the back button) (Select the Yes button) There are several ways to finish the program. 1. When you click „Back‟, a message will pop up as “Do you want to disconnect?” You may click „Yes‟. 2. You may just press close button on the phone. K9-a Series Manual...
-
Page 80: Chapter 13.Specification
K9-a Series Manual ▒ 13. Specification ▒ Specification 16ch Operating System Embedded Linux Video Algorithm H.264 Audio Algorithm G723.1 Video Method NTSC/PAL Video Input Video Input/Output Video Output Composite(1), Spot(1), VGA(1), HDMI(1) Output Mode CCTV, VGA, HDMI Monitor Live Real-time Live Split Mode 1,4,6,9 1,4,6,9,13,16...
