- Page 1 Users Guide & Installation Handbook Stoves SEB900MFSe Part No 082755900 Date 21/07/2011...
- Page 2 CONTENTS & INTRODUCTION CONTENTS WARRANTY • SAFETY Your new appliance comes with our 12-month guarantee, protecting you • USING THE PRODUCT against electrical and mechanical • CLEANING breakdown. To register your appliance please call 0844 481 0182, complete • INSTALLATION INSTRUCTIONS the registration form included or register •...
- Page 3 BEFORE USING THE PRODUCT • Make sure that you have removed all packaging and wrapping. Some of the items inside this appliance may have additional wrapping. • It is advised that you turn the ovens and/or grill on for a short while. This will burn off any residues left from manufacturing.
- Page 4 SAFETY BEFORE USING THE PRODUCT OVEN / GRILL Make sure that you have removed all packaging and wrapping. Some of the • Always take care when removing food items inside this appliance may have ad- from the oven as the area around the ditional wrapping.
- Page 5 INTRODUCTION FUNCTION TOP OVEN CONTROLS TIMER & CONTROLS MAIN OVEN CONTROLS Timer Symbols Child Lock Function The following image identifies the symbols To operate, ensure that both controls are that will be found on the timer display. in the “off” position. Touch and hold the button for 5 seconds.
- Page 6 USING THE TOP OVEN GRILL - ELECTRIC Caution: Accessible parts may be hot grill can create a fire hazard, and the high when the grill is used, young children reflectivity can damage the grill element. should be kept away. The cooling fan Detachable grill pan handle When the grill is switched on, you will hear the cooling fan come on - this keeps the fascia and control knobs of the ap- pliance cool during grilling.
- Page 7 USING THE TOP OVEN - ELECTRIC When you are cooking keep children temperature has not been reached. Once away from the vicinity of the oven. the temperature is reached the knob will illuminate permanently. Caution: The top element gets extremely hot when in use, so take extra care to Preheat the oven until the control knob avoid touching it.
- Page 8 USING THE TOP OVEN - ELECTRIC When using the top oven or chilled food, use the highest possible shelf position, while allowing some As part of the cooking process, hot air clearance between the food and the top is expelled through a vent at the top of element.
-
Page 9: Using The Main Oven
USING THE MAIN OVEN Accessible parts may be hot when the setting oven is used. Young children should This could be used for foods requiring be kept away. extra base heat e.g. Pizza Main Oven Control 5th Touch - Defrost Light Only Mode The temperature display will show the Turn the oven control knob towards the... - Page 10 USING THE MAIN OVEN Main Oven Grill Baking tray 350mm x 280mm To switch on the main oven grill rotate the This size of baking tray will hold up to 16 control to the symbol. small cakes. The display will show the single grill Roasting tin 370mm x 320mm symbol .
- Page 11 USING THE MAIN OVEN which will require a different approach: no need to follow the shelf positions given in the baking guide. There are no zones of heat in a fan oven as the convection fan at the back of the oven There is no need to interchange dishes ensures an even temperature throughout onto different shelves part way through...
- Page 12 USING THE MAIN OVEN Do not defrost larger joints of meat and Note: poultry over 2kg/4lb using this method. This is a high efficiency oven, therefore Never place uncooked food for defrosting some adjustment will have conventional next to cooked food which is to be cooled, made as this can lead to cross contamination.
- Page 13 USING THE MAIN OVEN Dish Recommended Approximate temperature °C cooking time (Preheated oven) Scones 8 - 15 mins Meringues 2 - 3 hours Cakes Small cakes 15 - 25 mins Whisked sponge 15 - 20 mins Swiss roll 10 - 12 mins Victoria sandwich 20 - 30 mins (2 x 180mm/7”)
- Page 14 USING THE MAIN OVEN Biscuits 25 - 35 mins Shortbread rounds 20 - 25 mins Nut brownies 10 - 12 mins Brandy snaps 20 - 25 mins Flapjacks 10 - 20 mins Ginger nuts Traditional fruit cakes breast meat, which must not be allowed to dry out, and the darker leg meat, which It should be remembered that ovens can takes longer to cook.
- Page 15 USING THE MAIN OVEN before cooking. For large joints it is calculate the cooking time from the total advisable to thaw over night. weight of the meat plus the stuffing. Frozen poultry should be thoroughly • For joints cooked in foil or covered thawed before cooking. The time required roasters, and for lidded casseroles, add 5 depends on the size of the bird - e.g.
- Page 16 USING THE TOUCH PROGRAMMER Select a function Plus - increase time or volume Minus - decrease time or volume Power ON/initial operation After connecting the appliance to the mains, the display shows the default TIME of DAY flashing. In the event of a power failure, the oven & grill elements will not automatically switch on when power is resumed;...
-
Page 17: Minute Minder
USING THE TOUCH PROGRAMMER Minute Minder TIME, the MANUAL mode changes to the AUTOMATIC mode, the COOKING POT Select the MINUTE MINDER mode by using symbol & the current TIME of DAY are the FUNCTION symbol until the MINUTE displayed. MINDER symbol is flashing. The MIN- UTE MINDER can be set using the... - Page 18 USING THE TOUCH PROGRAMMER COOKING TIME symbol is flashing. The END of COOKING TIME can be modified by using the symbols. The END of COOKING TIME can be deleted by counting back using the symbol until it equals the current TIME of DAY. The END of COOKING TIME has expired - see COOKING TIME has expired paragraph 3.6.
- Page 19 CLEANING General • Some foods are corrosive eg; vinegar, fruit juices and especially salt - they • It is important to clean the product can mark or damage the metal if they regularly as a build up of fat can af- are left on the surface.
- Page 20 CLEANING REMOVING OVEN PARTS FOR Shelf Runners CLEANING • Shelf runners can be removed to Inner Door Glass enable you to clean them thoroughly. Make sure they are cool to touch and • The inner door glass panel can be then grasp the runners and slide out removed for cleaning but it must be of their hanging holes.
- Page 21 CLEANING TELESCOPIC SHELVING SYSTEM To remove the telescopic shelves • In addition to the traditional shelving • Make sure the shelf is cool enough to fitted in your appliance, the tele- touch. scopic shelving system is fitted in the • Push the oven shelf back into the most commonly used location in your cavity, until it hits the stop position.
- Page 22 INSTALLATION STEP 1 : PREPARE INSTALLATION Do not lift the appliance by the door handle. Whilst every care is taken to elimi- nate burrs and raw edges from this product,please take care when handling - we recommend the use of protective gloves during installation.
- Page 23 INSTALLATION - 60CM i) When installed in a typical 600mm Ensure that you route all mains electrical deep built in housing unit, the false back cables and flexible tubing well clear of should be removed from the housing unit any adjacent heat source, such as an to provide the necessary depth for oven, grill or hob.
- Page 24 INSTALLATION - 70CM Before you start If this appliance is to be installed near to a corner where the adjacent cabinets run Please read the instructions carefully - at right angles forward of the appliance, planning your installation will save you there must be a gap of at least 90mm time and effort.
- Page 25 INSTALLATION - 70CM METHOD 1: WITHOUT HOUSING side of the appliance. UNIT(BETWEEN 2 BASE UNITS) 2. Make sure they are the right way up as shown. Before installing the appliance, check the 3. Take one of the side trims, hold it internal dimensions as shown.
- Page 26 INSTALLATION - 70CM METHOD 2: HOUSING UNIT WITH To fix the runners (if required) INTERNAL HEIGHT LESS THAN 1. Take the side trims, hold it against the 710MM side of the base unit, and use it to mark off the 687mm from the top edge of the Note: You will not need the 2 side trims side unit, to the top edge for the runner.
- Page 27 INSTALLATION - 70CM Method 3: Housing unit with internal Remove any fixings that may prevent height 710mm or more entry of the oven into housing, or obstruct the gas inlet pipe. The cabinetry Note: You will not need the 4 runners and should be kept structurally sound by 2 trims that are packed with the oven for fixing to adjacent cabinets, floor or this installation.
- Page 28 INSTALLATION - 90CM STEP 1 : PREPARE INSTALLATION may be fitted (see diagram). Important: Do not modify the outer Do not lift the appliance by the door panels of this appliance in any way. handle. Remove the fixing screws from the polythene bag on the top of the appli- ance, but leave the appliance in the base tray packaging until you are ready to install it.
- Page 29 INSTALLATION - 90CM Dimensions The appliance is designed to fit into a standard 600mm wide housing unit, with minimum internal dimensions as shown. Note: All sizes are nominal, some variation is to be expected.
- Page 30 INSTALLATION STEP 2 & 3 CONNECT TO THE ELEC- cable through the cable clamp in the TRICITY SUPPLY terminal block cover. 5. Connect the cable to the terminal block We recommend that the appliance is & tighten the cable clamp screw. connected by a competent person who 6.
- Page 31 INSTALLATION STEP 4: SECURE APPLIANCE INTO 60/70/90 fixing positions HOUSING UNIT Note : The unit housing the appliance must be appropriately fixed. Ensure that the appliance is centrally located. Take care not to damage the appliance or cabinetry. 70cm only Method 1 : Care must be taken to ensure the appliance runners are sufficiently engaged over the top of the runners on the base units.
- Page 32 INSTALLATION Anti-stain trim (if fitted) The anti-stain trim is factory fitted to the edges of the appliance front frame. This trim provides the cabinetry with extra protection from any escape of heat. - When Installing the product, ensure the anti-stain trim is correctly located on the edges of the front frame, before positioning and securing the appliance to the cabinet.
-
Page 33: Technical Data
TECHNICAL DATA ELECTRIC PRODUCTS Electrical supply/load 220 - 240V ~ 50Hz 90cm: load = 6.0kW Countries of destination GB - Great Britain, IE - Ireland Warning: This appliance must be earthed. Databadge is located at the bottom of the front frame, behind the door. -
Page 34: Customer Care
CUSTOMER CARE FAQs duce condensation when the oven is cooling down with food inside. What parts of the appliance can be washed in a dishwasher? Should the cooling fan continue to run once the appliance has been • Any enamelled parts such as the grill- switched off? pan can be cleaned in a dishwasher, as can oven shelves and shelf guides. - Page 35 CUSTOMER CARE CUSTOMER CARE WEB SHOP range of Bake ware and Cookware essen- tials including Roasting Pans, Cake Tins Having purchased a superior cooker, hob and Non-Stick Cooking Liners. or hood from us, you’ll naturally want to keep it looking great. And who better to For all enquires, please visit our Web Shop at www.gdhaonline.co.uk or help you care for it than the manufac-...
- Page 36 CUSTOMER CARE CUSTOMER CARE CHANGING LIGHT BULBS (where fitted) Warning: There is a risk of electric shock, so always make sure you have turned off and unplugged your appliance before starting. Always allow the product to cool down before you change a bulb. Not all appliances have the same number and type of bulbs.
- Page 37 Please keep this handbook for future reference, or for anyone else who may use the appliance.
- Page 38 Please keep this handbook for future reference, or for anyone else who may use the appliance.
- Page 39 Please keep this handbook for future reference, or for anyone else who may use the appliance.
- Page 40 CUSTOMER CARE In case of difficulty within the UK, please call Stoves Customer Care Helpline on 0844 815 3740 Alternatively general, spares and service information is available from our website at www.stoves.co.uk Please ensure that you have the product’s model no and serial no available when you call. These can be found on the silver data label on your product which is located: Ovens Open the door;...
