- Page 1 EFa 900H 900mm electric built in double oven & grill User & Installation Instructions...
-
Page 3: Table Of Contents
Technical Data ........28 Stoves Customer Care ........29 Please keep this handbook for future reference, or for anyone else who may use the appliance. -
Page 4: User's Section
Introduction Thank you for choosing a Stoves Electrical connection Newhome appliance Please refer to installation instructions We hope that the following information for electrical connection. will help you to familiarise yourself In your own interest, and that of safety, with the features of the appliance, and make sure that the installation is carried to use it successfully and safely. - Page 5 Introduction Cooling fan To replace an oven light bulb The cooling fan helps to keep the Caution: Switch off the electricity exterior cool during normal use. supply to the appliance, to avoid the When an element is operated, you risk of electric shock. should hear the cooling fan switch on Wait until the oven is cool, then automatically and be able to feel air...
-
Page 6: Be Safe - Not Sorry
Be Safe - Not Sorry When you are cooking, keep l When opening the appliance children away from the vicinity doors, take care to avoid skin of the appliance. contact with any steam which may escape from the cooking. l This product is designed as a domestic cooking appliance for l Using aluminium foil to cover the the preparation and cooking of... -
Page 7: Using The Grill
Using the Grill Caution: Accessible parts may Detachable grill pan handle be hot when the grill is used, trivet young children should be kept away. To switch on the grill Open the top oven / grill door. Turn the grill control fully clockwise to select either the full grill setting or economy grill setting. - Page 8 Using the Grill Using the grill When you have finished grilling, check that the control knob is The temperature of each grill setting is returned to the “off” position. fixed. Grilling can be adjusted by selecting a higher or lower shelf position, or by adjusting the trivet position, as detailed below;...
-
Page 9: Using The Top Oven
Using the Top Oven Caution: Accessible parts may Notes: be hot when the oven is used, C a u t i o n : The top element gets young children should be kept extremely hot when in use, so take away. -
Page 10: Top Oven Baking Guide
Using the Top Oven Top oven baking guide Cooking temperatures Because the top oven is more compact it may be necessary to reduce the Cooking times cooking temperatures specified in The cooking times given in the following recipes by up to 20˚C. Use the guide are based on a preheated oven, following guide as a reference for... -
Page 11: Using The Main Oven
Using the Main Oven Caution: Accessible parts may To help the air to circulate freely be hot when the oven is used, l Position the shelves evenly within young children should be kept the oven and maintain a clearance away. from the oven roof and base. -
Page 12: Cooking With A Fan Oven
Using the Main Oven Cooking with a fan oven Defrosting and cooling If you are used to cooking with a To defrost frozen foods, turn the conventional oven, you will find a oven control to the defrost position, number of difference to cooking with a place the food in the centre of the oven fan oven, which will require a different and close the door. -
Page 13: Main Oven Baking Guide
Using the Main Oven Main oven baking guide Because a fan oven has an even temperature throughout the oven, no The cooking times given below are only shelf positions have been given, approximate, because the size and type and there is no need to interchange of cooking dish will influence cooking dishes onto different shelves part times, as will personal preference. -
Page 14: Oven Furniture
Using the Ovens Oven furniture Aluminium foil Use foil only to cover food or cooking dishes. Do not use foil to cover the Baking tray and roasting tins shelves or oven base, as this creates a For best cooked results and even fire hazard. -
Page 15: Traditional Fruit Cakes
Using the Ovens Traditional fruit cakes Roast turkey It should be remembered that ovens Roasting turkey perfectly involves can vary over time, therefore cooking cooking two different types of meat - times can vary, making it difficult to be the delicate light breast meat, which precise when baking fruit cakes. -
Page 16: Roasting Guide
Using the Ovens Roasting guide Notes: The times given in the roasting guide l When cooking stuffed meat or are only approximate, because the poultry calculate the cooking time size and age of the bird will influence from the total weight of the meat cooking times as will the shape of a plus the stuffing. -
Page 17: Automatic Cooking In The Main Oven
Using the (Main) Oven Automatic cooking in the main oven l Warm food should never be placed in the oven if there is a The automatic cooking facility is delay period. Stews prepared by controlled by the programmer (see frying the meat and vegetables ‘Programmer/ Clock’... - Page 18 Using the (Main) Oven Important: Food is more susceptible Hints for automatic cooking to the growth of food poisoning l Food is placed in a cold oven so organisms in warm conditions. If the you will need to add about 10 - weather is hot, either take care to 15 minutes onto the cooking time ensure that food is not left standing in...
-
Page 19: Programmer / Clock
Programmer / Clock The programmer buttons Manual operation minute minder cook time ready time manual minus plus To set the programmer to manual To set the time of day operation at any time (cancelling any automatic setting), press the manual button. - Page 20 Programmer / Clock Semi-automatic cooking ( e x a m p l e ) 1. Auto symbol appears. You have started cooking a meal or dish in the oven, and want to set the time for the oven to switch off. Press the cook time button, then use the plus and minus buttons to set the display to show the length of cooking...
- Page 21 Programmer / Clock Fully automatic cooking 5. Auto symbol appears. (example) For use when a delayed start time is required. You want to set the length of cooking time, and the time for the oven to switch off. The programmer will automatically calculate the cooking start time.
- Page 22 Programmer / Clock The oven will automatically switch off 9. Auto symbol will flash. at 18.00 hours (6.00 pm) and the alarm will sound (9). To switch off the alarm press the minute minder button (10). When the oven has switched off, r e t u r n 11.
-
Page 23: Cleaning
Cleaning C a u t i o n : Any cleaning agent Chrome plated parts used incorrectly may damage & OVEN SHELVES OVEN SHELF RUNNERS the appliance. GRILL PAN TRIVET Always let the appliance cool Do not use abrasives or polishes. Use before cleaning. - Page 24 Cleaning Glass parts Important: if the inner door glass panel is removed for cleaning, it must & FACIA PANEL DOOR PANELS be replaced the right way up as Use a mild cream cleaner - eg; “Cif”. shown, and pushed fully in to the Rinse thoroughly and dry with a soft stop position.
- Page 25 Cleaning Stainless Steel surfaces (stainless steel finish models only) FACIA PANEL HANDLES DOOR PANELS Only use a clean cloth wrung out in hot soapy water, and dry with a soft cloth. Stubborn marks can be removed using “Luneta”. We recommend that you clean the whole of the stainless steel area to maintain a uniform finish.
-
Page 26: Installation
Installation Instructions Step 1: Prepare installation 1. Remove the fixing screws from the polythene bag on the top of the Do not lift the oven by the door appliance, but leave the appliance handle. in the base tray packaging until Whilst every care is taken to eliminate you are ready to install it. - Page 27 Installation Instructions 3. The appliance is designed to fit Please note that all sizes are nominal - into a standard 600mm wide some variation is to be expected. housing unit, with minimum internal dimensions as shown.
-
Page 28: Step 2: Connect To Electricity Supply
Installation Instructions Step 2: Connect to the electricity supply Warning: This appliance must be earthed. The appliance must be installed by a competent electrician using a double pole control unit of 30 ampere minimum capacity with 3 mm minimum contact separation at all poles. We recommend that the appliance is connected by a qualified electrician who is a member of the N.I.C.E.I.C. -
Page 29: Step 3: Check Edging Strip
Installation Instructions Step 3: Check edging strip Step 4: Secure appliance into housing unit The edging strip is factory fitted to the front side edges of the appliance Insert appliance into cabinet. front frame. This strip provides the Note: The unit housing the appliance c a b i n e t r y with extra protection from must be appropriately fixed. -
Page 30: Technical Data
Technical Data Electrical supply 220 - 240V ~ 50Hz Element ratings at 230V Dual Grill 1655 / 2575W Top Oven 1300W Main Oven 2300W Main oven stir fan Lights (1 each oven) 2 x 25W Cooling fan Maximum load 4990W... -
Page 31: Stoves Customer Care
Stoves Customer Care In case of difficulty within the UK and Northern Ireland, please call the Stoves Customer Care Centre Helpline on 0151 432 7838 When you dial this number you will hear a recorded message and be given a number of options. - Page 32 Stoney Lane, Prescot, Merseyside L35 2XW 08 25403 00 © 9.2003...
