STOVES STSEB602TCCSTA User Manual

STOVES STSEB602TCCSTA User Manual

Built in multi function 60cm
Hide thumbs

Advertisement

Quick Links

Download this manual
Date: 30/05/2020
Stoves Built In Multi Function 60cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the STSEB602TCCSTA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STOVES STSEB602TCCSTA

Summary of Contents for STOVES STSEB602TCCSTA

  • Page 1 Date: 30/05/2020 Stoves Built In Multi Function 60cm...
  • Page 2 NZ - New Zealand DE - Germany ES - Spain NL - Netherlands AU - Australia To contact Stoves about your appliance, please call: Warranty Registration Customer Care Helpline 0800 952 1065 0344 815 3740 *Please call our Customer Care team for extended...
  • Page 3 INTRODUCTION ACKNOWLEDGMENT Thank you for purchasing our product. We hope you enjoy using the many features and benefits it pro- vides. This user guide book is designed to help you through each step of owning your new product. Please read it carefully before you start using your appliance, as we have endeavored to answer as many questions as possible, and provide you with as much support as we can.
  • Page 4 SAFETY WARNING • During use the appliance becomes hot. Care should be taken to avoid touching heating elements. • Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction...
  • Page 5 disconnection with a minimum contact separation of 3mm. • Connection should be made with a suitable flexible cable with a minimum temperature rating of 70°C. • Although every care has been taken to ensure this appliance has no sharp edges. We recommend that you wear protective gloves when installing and moving this appliance.

  • Page 6: Using Your Appliance

    USING YOUR APPLIANCE Getting to know your product Note: Your appliance layout may differ depending on the model. Control Panel Start/Confirmation Button Arrow butttons Clock Button Pause/Off Button Timer Button Temperature Button Function Button Oven / Grill functions Note: Your oven may not have all of the functions shown here. We recommend for best cooking results, please preheat for 15 minutes.
  • Page 7 Cooling Fan When cooking is finished, paused, or if the center oven temperature is over 75 C, the cooling fan will continue working for 15 minutes. When the center oven temperature drops below 75 C, the cooling fan will stop. To use your appliance To select a Cooking Function and Cooking Temperature 1.
  • Page 8 4. Press the Start/Confirmation Button to start the Minute Minder. The “:” will begin to flash and the Minute Minder indicator will light up on the display. 5. Press the Pause/Off Button once to pause the Minute Minder. 6. Press the Pause/Off Button twice to cancel the Minute Minder. 7.
  • Page 9 Soft Closing Door (If fitted) The door can be paused at any angle greater than 30 The door will close slowly under the action of the damper, if it is less than or equal to an angle of 30 Please do not close the door vigorously. Catalytic Oven liners (If fitted) Some oven specifications have catalytic oven liners fitted to the sides of the oven, you can easily tell if the are fitted because the panel is a light grey soft touch enamel.
  • Page 10 Removing the door from oven (optional) 1. To remove the door, open the door to the maximum angle. Then pull the catch at the door hinge backward. 2. Close the door to an angle approximately 30°. Hold the door with one hand on each side.
  • Page 11 Accessories Wire shelf: For grill, dishes, cake pan with items for roasting and grilling. Slider bracket: For cooking larger size food, these shelf support rails on the right and left sides of the oven can be removed. Grill pan: For cooking large quantities of food such as moist cakes, pastries, frozen food etc, or for collecting fat/ spillage and meat juices.
  • Page 12 Shelf placement warning: To ensure the oven shelves operate safely, correct placement of the shelves between the side rail is imperative. Shelves and the grill pan can only be used between the first and fifth layers. The shelves should only be used in the right direction as it ensures that trays and hot food items do not slide if the shelves are moved.

  • Page 13: Bulb Replacement

    The oven shelves can also be hooked onto the shelf runners Before removing the shelves completely, please make sure that the shelf is unclipped from the retaining tabs. BULB REPLACEMENT Risk of electric shock! Glass cover You must replace a damaged glass cover. Suitable glass covers may be obtained from the after-sales service.

  • Page 14: Cleaning Your Appliance

    CLEANING YOUR APPLIANCE Do’s Note: Always switch off your appliance and allow it to cool down before you clean any part of it. Note: Please take extra care when cleaning over the symbols on the control panel, as this can lead to them fading.
  • Page 15 Please keep this handbook for future reference, or for anyone else who may use the appliance.

  • Page 16: Technical Data

    TECHNICAL DATA Electric Built In Electrical supply / Load Appliance Size (cm) Electrical supply Load (kW) 60 Multi Function Oven 220 - 240V ~ 50Hz For the specific power rating of your model, refer to the data badge on the front frame of your appliance. WARNING: This appliance must be earthed. PN:16171100A27913...
