Summary of Contents for Orthoquad RS1200
- Page 1 RS1200 Mobility Scooter User’s Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Specifications III. Features Set Up Operating Your Scooter Safety Instructions VII. Battery Charging VIII. Maintenance Schedule Warranty... -
Page 3: Introduction
Please read this manual thoroughly and carefully to become familiar with all operation instructions prior to operating your RS1200. If you have any questions concerning the operation or maintenance, please contact your dealer. -
Page 4: Specifications
ABOUT THE MANUAL The manufacturer reserves the rights of final interpretation on the manual. For any printing mistakes or new improvements, the manufacturer will update in the new editions. SPECIFICATIONS RS1200 PERFORMANCE DATA Maximum forward speed 15km/h Maximum backward speed 4.8km/h Maximum Climbing Grade 15 degrees Ground clearance Turning radius 1.5m Load Capacity (max) 180kg (400 pounds) Range with Full Charge... -
Page 5: Features
III. FEATURES Emergency hand brake Adjustable seat height Swing away armrests 360 degrees swivel seat, fully reclining Adjustable Forward/Reverse Seat Adjustable tiller Dynamic regenerative braking coupled with fail-safe electro-mechanical disk brake Rear wheel direct drive with differential Fully solid state controller External Battery Charger 24-volt permanent magnet heavy duty DC motor ON/OFF switch lock... -
Page 6: Set Up
IV. SET UP 1) Remove battery cover. 2). Place two batteries onto the battery pan and secure them. 3). Join the battery terminals with the receptacle from the controller box. . 4). Join all cables with the same labeling, except the wire for turning lights. 5). -
Page 7: Operating Your Scooter
The brake may not be as effective when engaged on inclines greater than 15 degrees or 21% if the occupant’s weight exceeds 400 pounds. In case the brake fails to engage, the RS1200 may roll slowly on a slope. Turn off the power immediately. -
Page 8: Safety Instructions
VI. SAFETY INSTRUCTIONS The following guidelines are intended to assist you in the safe operation of your RS1200 scooter. If you have any questions about the correct operation of your scooter, please contact your authorized dealer. Consult your physician if in doubt of your ability to operate the scooter. - Page 9 The sources of radiated EMI can be broadly classified into three types: 1) Hand-held portable transceivers (transmitters-receivers) with the antenna mounted directly on the transmitting unit. Examples include: citizens band (CB) radios, “walkie talkie,” security, fire, and police transceivers, cellular telephones, and other personal communication devices.
- Page 10 4) Be aware that adding accessories or components, or modifying the powered scooter, may make it more susceptible to EMI (Note: There is no easy way to evaluate their effect on the overall immunity of the powered scooter. 5) Report all incidents of unintended movement or brake release to the powered scooter manufacturer, and note whether there is a source of EMI nearby.
- Page 11 In summary, - DO NOT try to climb sharp curbs. - DO NOT drive off or over obstacles exceeding 5 cm in height. - DO NOT make abrupt changes in direction at high speed or while traveling on an incline. - DO NOT attempt to make fast turn on flat surfaces.
-
Page 12: Battery Charging
VII. BATTERY CHARGING To ensure the best performance and maximum battery life, we recommend frequent battery charging. Your RS1200 comes with an external battery charger for your ease and convenience. The console battery display makes charging simple and easy. It is recommended that you charge your scooter every night. -
Page 13: Maintenance Schedule
VIII. MAINTENANCE SCHEDULE In order to obtain the best performance and lasting service life, please maintain your unit according to the following schedule and instructions: DAILY Check brake effectiveness before you drive. Recharge batteries fully every night. WEEKLY 1, Check tire pressure. The pressure should be 21 psi. 2. -
Page 14: Warranty
(2) The battery is guaranteed 6 months after the date of purchase by the end-user.(customer) (3) All other RS1200 components are guaranteed for 1 full year after the date of purchase by the end-user.(customer) GUARANTEE IS NOT ENSURED WITH THE PROBLEMS CAUSED BY THE FOLLOWING: (1) Do not operate according to the manual.
