_cr-kuehlschraenke.book Seite 1 Montag, 13. Februar 2006 3:46 15
CR-0065E
CR-50, CR-65, CR-80, CR-110
DE
12
Kühlschrank
Bedienungsanleitung
EN
31
Refrigerator
Operating Manual
FR
49
Réfrigérateur
Notice d'utilisation
ES
68
Nevera
Instrucciones de uso
IT
87
Frigorifero
Istruzioni per l'uso
CR-0110E
CR-0050E
NL
106 Koelkast
DA
125 Køleskab
SV
143 Kylskåp
NO
161 Kjøleskap
FI
179 Jääkaapp
CR-0080E
Gebruiksaanwijzing
Betjeningsvejledning
Bruksanvisning
Bruksanvisning
Käyttöohje
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Waeco CoolMatic CR-0110E
Summary of Contents for Waeco CoolMatic CR-0110E
- Page 1 _cr-kuehlschraenke.book Seite 1 Montag, 13. Februar 2006 3:46 15 CR-0110E CR-0080E CR-0065E CR-0050E CR-50, CR-65, CR-80, CR-110 Kühlschrank 106 Koelkast Bedienungsanleitung Gebruiksaanwijzing Refrigerator 125 Køleskab Operating Manual Betjeningsvejledning Réfrigérateur 143 Kylskåp Notice d'utilisation Bruksanvisning Nevera 161 Kjøleskap Instrucciones de uso...
- Page 2 WAECO an. Bestellen Sie einfach unsere Kataloge kostenlos und unverbindlich unter der Internetadresse: www.waeco.de We will be happy to provide you with further information about WAECO products. Please order our free catalogue with no obligation to buy on our homepage: www.waeco.com...
- Page 3 _cr-kuehlschraenke.book Seite 3 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR-Serie CR-50 CR-65...
- Page 4 _cr-kuehlschraenke.book Seite 4 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR-Serie CR-80 CR-110...
- Page 5 _cr-kuehlschraenke.book Seite 5 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR-Serie...
- Page 6 _cr-kuehlschraenke.book Seite 6 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR-Serie c a . 50 mm...
- Page 7 _cr-kuehlschraenke.book Seite 7 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR-Serie...
- Page 8 _cr-kuehlschraenke.book Seite 8 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR-Serie...
- Page 9 _cr-kuehlschraenke.book Seite 9 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR-Serie ∅/mm² 12 V 24 V...
- Page 10 _cr-kuehlschraenke.book Seite 10 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR-Serie CR-50...
- Page 11 _cr-kuehlschraenke.book Seite 11 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR-Serie CR-65 CR-80 CR-110...
-
Page 12: Table Of Contents
_cr-kuehlschraenke.book Seite 31 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR Series Please read this instruction manual carefully before starting the appli- ance. Keep it in a safe place for future reference. If the appliance is handed over to another person, this operating manual must be handed over along with the appliance. -
Page 13: Notes On Using The Manual
“item 1 in figure fig. 5 on page 3”. Please observe the following safety instructions. Safety instructions Caution WAECO International will not be held liable for claims for damage resulting from the following: – Damage to the appliance resulting from mechanical influences and over voltage –... -
Page 14: General Safety
Improper repairs can lead to considerable hazards. Should your appliance need to be repaired, please contact WAECO customer service. Do not open the refrigerant circuit under any circumstances. Set up the appliance in a dry location where it is protected against splashing water. -
Page 15: Scope Of Delivery
_cr-kuehlschraenke.book Seite 34 Montag, 13. Februar 2006 3:46 15 Scope of delivery COOLMATIC CR Series Operating the appliance safely Electrical appliances are not toys! Keep electrical appliances out of reach of children or infirm persons. Do not let them use the appliances without super- vision. -
Page 16: Intended Use
Technical description WAECO CR series cooling appliances can cool goods and keep them cool. Products can be deep-frozen in the freezer compartment. All materials used in the refrigerator are compatible for use with foodstuffs. -
Page 17: Control Elements
_cr-kuehlschraenke.book Seite 36 Montag, 13. Februar 2006 3:46 15 Technical description COOLMATIC CR Series Control elements inside the fridge The various types of refrigerators are shown in the following illustrations: CR-50: fig. 1, page 3 CR-65: fig. 2, page 3 CR-80: fig. -
Page 18: Installing And Connecting The Refrigerator
_cr-kuehlschraenke.book Seite 37 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR Series Installing and connecting the refrigerator Installing and connecting the refrigerator Installing the refrigerator The appliance is designed for ambient temperatures between –10 °C and +43 °C. In continuous operation, the air humidity may not exceed 90 %. Set up the fridge in a dry, sheltered place. - Page 19 _cr-kuehlschraenke.book Seite 38 Montag, 13. Februar 2006 3:46 15 Installing and connecting the refrigerator COOLMATIC CR Series Undo the lock The refrigerator has a locking mechanism (fig. 8 1, page 6) which is also used, to protect it during transport. The following settings are possible: Lock (turn wheel clockwise to the end stop): The door is locked and secured.
- Page 20 _cr-kuehlschraenke.book Seite 39 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR Series Installing and connecting the refrigerator ➤ Before starting up the appliance for the first time, check whether the op- erating voltage and the battery voltage match (see type plate). ➤...
- Page 21 _cr-kuehlschraenke.book Seite 40 Montag, 13. Februar 2006 3:46 15 Installing and connecting the refrigerator COOLMATIC CR Series Connecting the refrigerator to AC power (accessory) You can connect the refrigerator to AC power if you use a rectifier (accessory): 110 V: EPS-35US 220 –...
-
Page 22: Using The Refrigerator
_cr-kuehlschraenke.book Seite 41 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR Series Using the refrigerator Using the refrigerator Note Before starting your new refrigerator for the first time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to the see "Cleaning and care"... - Page 23 _cr-kuehlschraenke.book Seite 42 Montag, 13. Februar 2006 3:46 15 Using the refrigerator COOLMATIC CR Series Note After switching on, the refrigerator requires approx. 60 s until the compressor starts up. Setting the temperature You can set the temperature to any level using the control knob. The built-in thermostat regulates the temperature as follows: 1 = least cooling 7 = most cooling...
- Page 24 _cr-kuehlschraenke.book Seite 43 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR Series Using the refrigerator Wrap food in aluminium foil or cling film and shut in in a suitable box with a lid. This ensures that aromas, the shape and the freshness will be better conserved.
-
Page 25: Cleaning And Care
_cr-kuehlschraenke.book Seite 44 Montag, 13. Februar 2006 3:46 15 Cleaning and care COOLMATIC CR Series Replacing the interior light If the interior light in the refrigerator is faulty, you can change the bulb (12 V, 3 W). ➤ Remove the cover. ➤... -
Page 26: Guarantee
Guarantee Our general guarantee conditions apply. If the product is defective, please re- turn it to the WAECO branch in your country (see the back of the instruction manual for the addresses) or to your dealer. For repair and guarantee... - Page 27 _cr-kuehlschraenke.book Seite 46 Montag, 13. Februar 2006 3:46 15 Troubleshooting COOLMATIC CR Series Interior temperature too low in control level “1” Fault Possible cause Remedy Compressor runs con- Faulty thermostat Change the thermostat stantly Compressor runs for a Large quantities have been frozen in –...
- Page 28 _cr-kuehlschraenke.book Seite 47 Montag, 13. Februar 2006 3:46 15 COOLMATIC CR Series Troubleshooting Compressor is not running (connected to AC supply) Fault Possible cause Remedy No voltage Interruption in the supply cable Establish a connection Main switch faulty (if installed) Replace the main switch Additional supply line fuse has blown Replace the supply line...
-
Page 29: Technical Data
4.5 l Average power consumption: 40 W 40 W Weight: 19 kg 20 kg CR-80 CR-110 Item number CR-0080E CR-0110E Capacity: 78 l 108 l Freezer compartment: 10 l Average power consumption: 40 W 45 W Weight: 23 kg 28 kg Versions, technical modifications and delivery options reserved. - Page 30 _cr-kuehlschraenke.book Seite 196 Montag, 13. Februar 2006 3:46 15 Headquarters WAECO International GmbH · Hollefeldstraße 63 · D-48282 Emsdetten Fon: +49 2572 879-195 · Fax: +49 2572 879-322 · E-Mail: info@waeco.de · Internet: www.waeco.de Europe Overseas + Middle East WAECO Schweiz AG WAECO Italcold SRL WAECO Pacific Pty.
