Polarity « - » of the
battery
Activate/deactivate the remote control
Remote control is supplied with battery inserted.
Activate: press the On/Off red button ( ) located on the side of the remote control for 1
▪
second (ref. Diagram.1). Indications appear on the LCD screen.
Deactivate: press the On/Off red button ( ) of the remote control for 1 second (ref.
▪
Diagram.1). The LCD screen is off.
To increase the battery life of the remote control, we recommend you to deactivate the unit if you are not
using it for a long period.
Activate/deactivate the receiver collar
A magnet located in the remote control is used to either switch on/off the receiver collar.
Activate: Place the red mark located on the remote control in contact with the red mark located on
▪
the receiver collar for 1 second (ref. Diagram 5). The indicator light on the collar will flash in green
indicating that the CANICOM receiver is ready.
Deactivate: Place the red mark located on the remote control in contact with the red mark red
▪
mark on the receiver for 1 second (ref. Diagram 5). The indicator light on the collar will flash from
green to red and then off: the CANICOM receiver is off.
To increase the battery life of the receiver collar, we recommend you to deactivate the unit if you are not
using it for a long period.
REMOTE
CONTROL
Coding of the remote control and receiver collar
CANICOM 200 – User's guide – May 2009
Polarity « + » of the
battery
Diagram 4
Approach until coming in contact those 2
areas for 1 second
RECEIVER
COLLAR
Seal
Diagram
5
