Appendix

Specifications

Product name
Appearance
Panel Size
Display method
Resolution
Scanning Fre‐ Digital
quency
Analog
Focus adjustment
Zoom adjustment
Lamp (light source)
Power supply
Power con‐ 100 to 120 V area
sumption
220 to 240 V area
Operating altitude
Operating temperature
Storage temperature
Mass
Connectors
Speaker
* The operating temperature is +5 to 30°C at an altitude of 2287 to 3000m.
This product is also designed for IT power distribution system with phase-to-phase voltage 230V.
Обладнання відповідає вимогам Технічного регламенту обмеження використання деяких небезпечних
EH-TW5200
297 (W) x 108 (H) x 247 (D) mm
0.61" wide
Polysilicon TFT active matrix
1920 (W) x 1080 (H) x 3
Pixel Clock: 13.5 - 150 MHz
Horizontal: 15 - 80 kHZ
Vertical: 24, 30, 50 - 85 Hz
Pixel Clock: 13.5 - 150 MHz
Horizontal: 15 - 80 kHZ
Vertical: 24, 50 - 85 Hz
Manual
Manual (approx. 1 to 1.2)
UHE lamp 200 W, Model No.: ELPLP78
100 to 240 V AC ±10%, 50/60 Hz, 3.0 to 1.4 A
Operating: 300 W
Standby power consumption: 0.28 W
Operating: 287 W
Standby power consumption: 0.31 W
Altitude 0 to 3000 m
*
+5 to 35°C (No condensation)
-10 to +60°C (No condensation)
Approx. 2.8 kg
PC port x 1, Mini D-Sub15-pin (female) blue
HDMI port x 2, HDMI
For HDCP, For CEC signals, For MHL signals (HDMI1 port only),
For linear PCM, Deep Color
Video port x 1, RCA pin jack
RS-232C port x 1, D-sub 9-pin (male)
Audio-L/R port x 1, RCA pin jack
USB 2.0 TypeA port x 1
Audio Out port x 1, Stereo mini jack
Maximum input 2 W x 1
