CHANGING MAGNIFICATION

You can increase or decrease the size of the image by using the
SIZE dial at the center of the control panel (see Figure 1).
There are sixteen levels of
magnification available on Merlin HD.
• To increase the size of the image,
turn the dial clockwise, or to the
right.
• To decrease the size of the image,
turn the dial counterclockwise, or to
the left.
The size you selected will be
displayed in the upper left corner of
your monitor (see Figure 2).
18 Changing Magnification
Figure 1
ZOOM 7
Figure 2

CHANGING BRIGHTNESS

You can increase or decrease the brightness of the image by
using the brightness lever located underneath the right bottom
of the control panel. (see Figure 1) The Merlin HD will show
the most natural image quality when brightness is set in the
middle in normal color mode.
•To increase the brightness, slide the lever to the right.
•To decrease the brightness, slide the lever to the left.
An on screen display will show the level of brightness.
Changing Brightness
Figure 1
