Passenger Train Set

Owner's Manual

CAUTI O N—ELECTRI C TOY

NOT RECOMMENDED FOR CHILDREN UNDER FOURTEEN YEARS OF AGE. AS

WI T H ALL ELECTRI C PRODUCTS, PRECAUTI O NS SHOULD BE OBSERVED DURI N G

HANDLI N G AND USE TO PREVENT ELECTRI C SHOCK.

TRANSFORMER RATINGS—I N PUT: 120 VAC; 60 HZ ONLY.

AC OUTPUT: 18 V; 80 VA

AC OUTPUT: 18 V; 40 VA

73-1779-250 HHP-8.indd 1

Amtrak

Ready to run

HHP-8

73-1779-250

09/09

9/3/09 8:46 AM

Table of Contents

Need help?

Do you have a question about the Amtrak HHP-8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lionel Amtrak HHP-8

Page 1 73-1779-250 09/09 Amtrak HHP-8 Amtrak HHP-8 ® ® Ready to run Ready to run Passenger Train Set Passenger Train Set Owner’s Manual Owner’s Manual CAUTI O N—ELECTRI C TOY CAUTI O N—ELECTRI C TOY NOT RECOMMENDED FOR CHILDREN UNDER FOURTEEN YEARS OF AGE. AS NOT RECOMMENDED FOR CHILDREN UNDER FOURTEEN YEARS OF AGE.
Page 2: Fcc Statement
Expand your railroad empire with additional FasTrack track sections, enhance your layout with accessories. Explore the possibilities at your authorized Lionel dealer. Use this Owner’s Manual to learn how to set up, operate, and maintain your train set for years of reliable operation.
Page 3 • Flush fitting windows • Interior illumination • Metal frame • Detailed interiors • Illuminated marker lights on rear of last passenger car Lionel Amtrak HHP-8 Passenger Train Set Includes: ® Powered HHP-8 electric locomotive Three Amfleet coaches Seven straight FasTrack sections ®...
Page 4 Replacing your locomotive’s traction tire Replacing your locomotive’s lamp Replacing the lamps in your passenger cars Troubleshooting Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel , TrainMaster , Odyssey...
Page 5: Creating Your Layout
• Parents should periodically inspect this product for potential hazards and, if necessary, have them repaired by an authorized Lionel Service Center. In the event that such a condi- tion exists, the transformer should not be used until it has been properly repaired.
Page 6: Building Your Lionel Layout
Creating your layout Building your Lionel layout our set comes with twelve curved, seven straight, and one terminal section of track. By adding more FasTrack track sections, you can create an endless number of exciting track arrangements for more fun, action, and variety. The railroad empire of your dreams can quickly become a reality! Joining the FasTrack track sections asTrack track sections join together easily.
Page 7: Wiring Your Cw-80 Transformer
Creating your layout Wiring your CW-80 Transformer onnect your FasTrack terminal section to the CW-80 Transformer by using the wires that are already attached to the terminal section. Make sure that all connections are secure. Loose connections can produce extremely high temperatures. For this reason, do not touch the terminals or track connections during use.
Page 8: Running Your Train
Running your train Coupling the cars hen coupling your cars, at least one of the mating couplers must be open as shown at the left in Figure 3. Press down on the lock release to open the coupler, then push the cars toward each other until they lock together.
Page 9: Running Your Train Set
Running your train Running your train set With track power off, place your train set on the track. See page 8 for coupling cars. Power up your locomotive with your transformer. Your powered car is designed to operate on 7-15 volts alternating current.
Page 10: Experiencing The Features Of The Cw-80 Transformer
Running your train Experiencing the features of the CW-80 Transformer Refer to Figure 4 on page 11 for the location of the transformer features listed in this section. THROTTLE Push the throttle forward to increase track power. The markings on the throttle approxi- mate the percentage of full power.
Page 11 Whistle Activates the whistle or horn sound Throttle effect in your Lionel locomotives. Controls your locomotive’s speed. Throw the throttle Press WHISTLE to begin the sound; forward to increase locomotive speed, backward to slow release the button to end it.
Page 12: Powering Your Layout With The Cw-80 Transformer
Running your train Powering your layout with the CW-80 Transformer our CW-80 Transformer provides a total output of 5.0 amps. Also, available voltage depends on how much load is on the output. Generally, track voltage is 0-16 volts (AC). You may momentarily approach or exceed the 5.0 amp limit of the CW-80 Transformer when pulling illuminated cars, or fighting over grades with heavy loads.
Page 13: Reverse Unit Procedure
Running your train Reverse unit procedure he electronic reverse unit inside your Lionel locomotive acts like the transmission in a car. When you apply power to the track, the locomotive moves in the direction specified by the reverse unit—or it sits in neutral, awaiting another power interruption. Power interruptions are the signal that tells the reverse unit to sequence to the next operational state.
Page 14: Adjusting The Volume
Running your train Operating the locomotives horn and bell he locomotive in your train set is equipped with horn and bell sounds. To operate the horn, press the HORN button on your transformer. To operate the bell, press the BELL button on your transformer.
Page 15: Command Control Operations
Command Control operations Command Control operations ommand Control is an advanced model railroad control system from Lionel. To operate your locomotive in the Command Control environment, you need a Command Base (avail- able separately, 6-12911) and a CAB-1 Remote Controller (available separately, 6-12868).
Page 16: Cab-1 Remote Controller Numeric Keypad Commands
Command Control operations CAB-1 Remote Controller commands he CAB-1 Remote Controller commands are detailed below. The corresponding RailSounds sound system effects are in bold italic type. Activates the numeric keypad. Toggles the headlights and ditch lights on and off. Accelerates the locomotive with a clock- wise rotation.
Page 17: Assigning Your Locomotive A New Id
Command Control operations Assigning your locomotive a new ID# s your roster of Command Control-equipped locomotives grows, you will want to give each unit a unique ID#. The locomotive will respond to commands associated with its ID# while all other units will disregard these commands. Note! To restore your locomotive’s features, see below.
Page 18: Maintaining And Servicing Your Set
Maintaining and servicing your set Lubricating your HHP-8 locomotive elp your Lionel locomotive lead a long and productive life on your railroad by maintain- ing it properly. We recommend that you purchase a Lionel Lubrication and Maintenance Kit (6-62927), available from your Lionel dealer. Two basic rules to keep in mind: never over-lubricate (a small amount will do), and avoid getting grease or oil on the locomotive’s wheels, contact...
Page 19: Troubleshooting
During the course of normal operations, you may find that these lamps require replacement. Due to the dis-assembly required to access the lamps, we recommend that you have your lamps replaced by an authorized Lionel Service Center or Lionel Service.
Page 20: Lionel Limited Warranty Policy & Service
(or copy) from an Authorized Lionel Retailer*, will at the discretion of Lionel LLC, be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a suitable replacement is not available, Lionel will offer to replace the product with a comparable model (determined by Lionel LLC), if available.
