Configuring the Camera
Sensor AOI Left
- As shown in Figure 4 on
AOI, i.e., how far the sensor AOI will be offset from the left edge of the sensor. The setting must be
a multiple of 2. *
Sensor AOI Top
- As shown in Figure 4 on
AOI, i.e., how far the sensor AOI will be offset from the top edge of the sensor. The setting must be
a multiple of 2. *
Sensor AOI Width
- As shown in Figure 4 on
The setting must be a multiple of 8. *
Sensor AOI Height
- As shown in Figure 4 on
AOI. The setting must be a multiple of 8. *
* You can also use the Sensor AOI Editor (see
you make to the AOI parameter settings on the Global tab will be reflected on the Sensor AOI
Editor.
Image Rotation
- Sets the degrees of rotation for the images captured by the sensor.
0° = Don't rotate the images.
180° = Rotate the images 180 degrees.
Test Image Mode
- Enables or disables the camera's test image feature. When the test image
mode is enabled, the camera will generate test images using its digital devices rather than the
imaging sensor. The generated test images will be transmitted on all enabled streams. Test images
are useful for troubleshooting the camera's basic functionality and the network connection.
Off = The test image function is disabled.
On = The test image functioned is enabled. The camera will stream test images that include
diagonal red, green, and blue gradients. The gradients will appear to move as the test images
are received.
20
Frame Rate Mode
- Sets the rate at which the camera's sensor will
capture frames (images). For example, selecting 15 FPS means that
the camera's imaging sensor will capture 15 frames per second.
Note that on some camera models, typically those with large imaging
sensors, the maximum rate at which the sensor can capture images
(i.e., the frame rate) is limited. On these cameras, if you decrease the
height of the sensor AOI, the rate at which the sensor can capture
images will increase. So if you decrease the setting for the AOI
Height parameter, you may see an increase in the maximum setting
available for the Frame Rate Mode parameter.
page 19, sets the left offset (in pixels) for the sensor
page 19, sets the top offset (in pixels) for the sensor
page 19, sets the width (in pixels) of the sensor AOI.
page
page
19, sets the height (in pixels) of the sensor
21) to set this parameter, and any changes
