Electrolux E36GF76J Parts Catalog

36-inch free standing gas range
Hide thumbs

Advertisement

Quick Links

E36GF76JPS.jpg CE36GF76JPS1.eps BRE36GF76JPS1.wmf BE36GF76JPS1.eps
ME36GF76HPS3.eps DE36GF76JPS1.eps
Electrolux Major Appliances
P.O. BOX 8020
CHARLOTTE, NC 28262
Product No.
E36GF76JPS2
32166696F00S2
Series
36" f/s gas
Color
stainless
Market
North America
Wiring Diagram
318403413
Owner's Guide
318203967
Installation Instructions 318201779
Service Data Sheet
318204805
318403413.eps
Publication No.
5995592341
11/04/11
(EN/SERVICE/ECL)
377
36-INCH FREE
STANDING GAS
RANGE
Model No.
E36GF76J

Advertisement

loading

  Summary of Contents for Electrolux E36GF76J

  • Page 1 318403413 Owner's Guide 318203967 Installation Instructions 318201779 Service Data Sheet 318204805 36-INCH FREE E36GF76JPS.jpg CE36GF76JPS1.eps BRE36GF76JPS1.wmf BE36GF76JPS1.eps STANDING GAS ME36GF76HPS3.eps DE36GF76JPS1.eps 318403413.eps RANGE Electrolux Major Appliances Model No. P.O. BOX 8020 E36GF76J CHARLOTTE, NC 28262 Publication No. 5995592341 11/04/11 (EN/SERVICE/ECL)
  • Page 2 Publication No: 5995592341 E36GF76JPS2 BACKGUARD CE36GF76JPS1 04/11...
  • Page 3 E36GF76JPS2 Publication No: 5995592341 BACKGUARD POS. NO PART NO. DESCRIPTION 318285735 Panel, control, stainless 318389500 Retainer, lens 24 # 5308015487 Switch, oven light, rocker 26 # 5304452799 Board, indicator light, (2), LED 318377000 Support, control panel, (2) 318242252 Knob, control, stainless, (4) 318242253 Knob, control, stainless, dual, (2) 318242230...
  • Page 4 Publication No: 5995592341 E36GF76JPS2 BURNER 04/11...
  • Page 5 E36GF76JPS2 Publication No: 5995592341 BURNER POS. NO PART NO. DESCRIPTION 318357805 Manifold, (2) 5303311333 Screw, 8-32 x 3/8 1A # 318305453 Tube, manifold, interconnect 1B # 318305454 Tube, manifold, interconnect 316520700 Valve, burner, 5K 2A # 316574900 Valve, top burner, 18K dual 2B # 316520703 Valve, burner, 14.2K...
  • Page 6 Publication No: 5995592341 E36GF76JPS2 BODY 108A BE36GF76JPS1 04/11...
  • Page 7 E36GF76JPS2 Publication No: 5995592341 BODY POS. NO PART NO. DESCRIPTION 318259255 Back, main 318260057 Panel, rear box, upper 318258956 Shield, insulation, upper 318352766 Panel, side, stainless, LH 318352767 Panel, side, stainless, RH 318106070 Insulation, side wall, (2), w/foil 318364127 Liner, oven bottom 318939600 Shield, heat, burner cover 318175506...
  • Page 8 Publication No: 5995592341 E36GF76JPS2 BODY 108A BE36GF76JPS1 04/11...
  • Page 9 E36GF76JPS2 Publication No: 5995592341 BODY POS. NO PART NO. DESCRIPTION 318260050 Panel, rear box, lower 318259151 Shield, insulation, sides, (2) 318364902 Front, oven 318293702 Spacer, control 316114100 Spacer 318364800 Plate, oven mtg 318373700 Bracket, oven, (2) 318258785 Shield, insulation, lower 318364205 Liner, oven top 318364304...
  • Page 10 Publication No: 5995592341 E36GF76JPS2 04/11...
  • Page 11 E36GF76JPS2 Publication No: 5995592341 POS. NO PART NO. DESCRIPTION 318079001 Module, spark 318387301 Bracket, spark module 318185235 Main Top Assy, frame/glass, stainless/black 318361402 Grate, top burner, black, (3), double 318293107 Skirt, 5K burner, black 316515100 Skirt, 18K burner, black, (2) 318293308 Skirt, 14K burner, black 318293007...
  • Page 12 Publication No: 5995592341 E36GF76JPS2 DOOR DE36GF76JPS1 04/11...
  • Page 13 E36GF76JPS2 Publication No: 5995592341 DOOR POS. NO PART NO. DESCRIPTION 318260550 Baffle, door 318372003 Insulation, door 318106068 Insulation, w/aluminum foil 318212250 Glass, oven door, heat barrier, (2) 318364602 Liner, oven door 5304415832 Screw, 8-18 x 0.406 5304400794 Screw, 10-32 x 3/4, (4) 3201909 Washer, flat, lower 318053151...
  • Page 14: Wiring Diagram

    Publication No: 5995592341 E36GF76JPS2 WIRING DIAGRAM 04/11...
