Table of contents Please read & save this guide Finding information ............2 Thank you for choosing Electrolux, the new premium brand in home appliances. This Use & Important Safety Instructions ........3-5 Care Guide is part of our commitment to customer Getting Started ............6...
Important Safety Instructions What you need to know about safety instructions Warning and Important Instructions appearing in this guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when installing, maintaining or operating a microwave.
Important Safety Instructions and range have been designed, tested and • Do Not Use Water or Flour on Grease listed by an independent test laboratory for Fires—Smother the fire with a pan lid, or use use in combination with each other. baking soda, a dry chemical or foam-type extinguisher. • When heating fat or grease, watch it closely.
Important Safety Instructions under the hood, turn fan on. Refer to hood burner is on. Burns will occur if the hot covers manufacturer’s instructions for cleaning. are touched. Damage may also be done to the • Utensil Handles Should Be Turned Inward cooktop or burners because the covers may and Not Extend Over Adjacent Surface cause overheating. Air will blocked from the Burners/Unit —To reduce the risk of burns, burner/unit and cause combustion problems.
Getting Started Grounding Instructions For personal safety, the cooktop must be properly Grounding Do not, under any grounded. For maximum safety, the power cord type wall circumstances, cut, must be plugged into an electrical outlet that is receptacle remove, or bypass correctly polarized and properly grounded.
Surface Cooking Surface cooking utensils *GOOD POOR • Curved and warped pan bottoms. • Flat bottom and straight sides. • Pan overhangs unit by more • Tight fitting lids. than 2.5 cm (1”). • Weight of handle Pans should have flat bottoms. Check does not tilt pan. Pan for flatness by rotating a ruler across is well balanced. the bottom. There should be no gaps • Pan sizes match the • Heavy handle tilts pan.
Surface Cooking Using the wok stand (accessory not included) The Wok Stand is designed to allow round- bottomed woks to be used. It is recommended that you use a 14 inch diameter (35.5 cm) or less Wok. It is recommended that you use the POWER burner with the wok stand for best performance.
Surface Cooking Using the simmer plate (accessory not included) The simmer plate (Figure 1) is intended to diffuse lower temperature of the burner to help cooking delicate aliment such as chocolate, milk, bechamel, etc. It can also be use for cooking sauce during long period. With the grate in position over the burner, set the simmer plate Figure 1 on top of the grate positioning the notches in the...
Surface Cooking Placement of burner caps Burner Cap Place a burner cap on each burner head, matching Burner Cap Lip Burner Head the cap size to the head size. The cap for each burner has an inner locating ring which centers the cap correctly on the burner head. Be sure that all the burner caps and burner heads are correctly placed BEFORE using your appliance. Make sure each burner cap is properly aligned and level. Turn the burner on to determine if it will light.
Surface Cooking Flame Size For most cooking, start on the highest control *Flame Size Type of Cooking setting and then turn to a lower one to complete Start most foods; bring water the process. Use the chart below as a guide for High Flame to a boil;...
Surface Cooking Setting surface controls To operate the surface burner: Your cooktop may be equipped with any combination of the following burners: 1. Place cooking utensil on burner. Simmer Burner: best used for simmering delicate 2. Push in and turn the Surface Control knob to sauces, etc. Note: All electronic ignitors will click at the same time Standard Burner: used for most all surface cooking when the knob is pushed in.
Care and Cleaning Care and cleaning table Cleaning Recommendations Surface Type Cleaning Recommendation • Painted and For general cleaning, use hot, soapy water and a cloth. For more difficult soils and Plastic Control built-up grease, apply a liquid detergent directly onto the soil. Leave on soil for 30 Knobs to 60 minutes. Rinse with a damp cloth and dry. DO NOT use abrasive cleaners on any of these materials;...
Care and Cleaning Cleaning burner grates, caps, heads and glass cooktop Should you experience ignition problems it may be that an ignition port hole is partially blocked with soil (see figure below). With the burner head in ● To avoid possible burns use care when place, use a small wire gauge needle or the end of cleaning the cooktop.
Care and Cleaning Cleaning burner grates, caps, heads and glass cooktop Cleaning recommendations for the Plastic or foods with a high sugar content: These types of soils need be removed immediately if ceramic glass cooktop spilled or melted onto the ceramic cooktop surface. Permanent damage (such as pitting of the cooktop surface) may occur if not removed immediately.
Solutions to common problems Before you call for service, review the following list. It may save you time & expense. The list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Before you call Problem Solution Surface burners • Surface control knob has not been completely turned to...
Warranty Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will repair or replace any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used, and maintained in accordance with the provided instructions.
