Code Alarm ca 3051 Installation Manual page 6

GREY
This is an instant on ground trigger wire. It must be connected to the previously
installed hood and/or trunk pin switches.
GREEN
If the vehicle's courtesy light switches have a (-) ground output when the door is
opened (GM and most Imports), you must connect the Green wire to the negative
output from one of the door switches.
PURPLE
If the vehicle's door courtesy light switches have a + 12 volt output when the
door is opened (most Fords and some Imports), you must connect the Purple wire
to the positive output from one of the door switches. In most cases, the Violet
wire will only needs to be connected to one door switch, no matter how many
doors the vehicle has.
YELLOW
Connect this wire to the ignition 1 wire from the ignition switch. This wire will
show +12 volts when the ignition key is turned to the to the ON, RUN and START
positions, and will have 0 volts when the key is turned to the OFF and
ACCESSORY positions.
ORANGE/GREEN
This wire is programmable to provide either a 30 second pulsed output when the
system is ARMED or a pulsed ground output to the factory door lock control relay
for a passive door locking feature. The maximum current draw through these
outputs must not exceed 300 mA.
6
(-) HOOD/TRUNK TRIGGER
NEGATIVE DOOR TRIGGER INPUT
POSITIVE DOOR TRIGGER INPUT
IGNITION INPUT ( + )
30 SECOND OUTPUT WHEN ARMED ( - )
OR PASSIVE DOOR LOCK OUTPUT (-)
ca3051 rev B. 2011 Audiovox Electronics Corporation. All rights reserved.
