ADDITIONAL PORTS
LED PORT
Route the red and blue wires in the 2 pin white connector from the LED to the
control module, and plug it into the mating white connector on the side of the
module.
VALET / PROGRAMMING PORT
Route the 2 pin red connector from the override switch previously mounted to
the mating two pin connector on the module.
SHOCK SENSOR PORT
Route the 4 pin connector form the previously installed shock sensor to the
mating 4 pin connector of the module.
COMPLETING THE INSTALLATION
Adjusting the Shock Sensor: Gently turn the adjustment dial counter
clockwise to turn down the sensitivity and turn clockwise to turn up sensitivity.
Close the hood and trunk lids, and arm the alarm . Wait 6 seconds for the
accessories trigger zone to stabilize, then test the sensitivity adjust as needed
CAUTION: Never perform this test on the vehicle's glass, as you may break the
window.
WARNING ! Setting the sensitivity too high can cause false alarms due to noise
vibrations from passing trucks and heavy equipment. To decrease sensitivity,
turn the adjustment screw counter clockwise.
Wire Dressing: Always wrap the alarm wires in convoluted tubing, or with a
spiral wrap of electrical tape. Secure these looms along the routing using cable
ties. This will ensure that the alarm wires are not damaged by falling onto hot or
sharp moving surfaces in the vehicle.
