Illuminated Icons Explained
Colour of symbol
Power ON/OFF switch OFF
Sleep mode
Power ON/OFF switch ON
Stand by
Auto mode
Continuous jam boost mode
Reverse mode
Paper loading door open
Bin full/bin open
Paper jam
Paper jam clearance
Too many sheets are being fed into manual feed slot
Cutters are self-cleaning
Entering PIN password
Paper loading door is locked
Incorrect PIN password has been entered
Correct PIN password re-entered
Autofeed Operation
Oil Level Too Low
Auto/Manual Oiling

Auto-feed Technology

The Stack-and-Shred 750X has been designed to automatically
shred up to 750 sheets from the auto-feed chamber and up
to 12 sheets through the manual feed slot. The auto-feed
mechanism has been designed to handle paper fastened with
staples and paper clips and to only pull a few sheets of paper
into the cutting mechanism to minimize the risk of paper jams.

Initial Setup

The shredder is designed to automatically lubricate the cutting
mechanism as required to ensure the product continues to
work to its maximum performance and to extend the product
life. Please follow the operation instruction before turning
on the shredder for the first time. The 2oz bottle of oil* is
sufficient to allow the shredder to start for the first time and
to operate continuously for about one hour's shredding before
the reservoir will need refilling. When the 'Oil Refill' indicator is
illuminated ( ), flip up the oil reservoir cap (V) and refill the
oil reservoir using a bottle of standard Swingline oil (1760049).
The automatic oiling operation (
seconds and you will hear the distribution pump during this
time. Auto-oiling operates after 15 minutes of shredding time.
* ACCO Brands accepts no liability for product performance or safety
when other types or brands of lubricants are used on any part(s) of
this machine.
6
TM/MC
Lock Bin Full/
Door Open
Green Red Red
light
light
flash
light
flash x3
flash x3
) last approximately two
Oiling in Oil Paper
Operation Level Jam
Indicator
Green Red Red
light
light
light
flash
flash
light
light
Bin or Loading Door Open Safety
Function
As a safety precaution, if the bin or loading door is opened
during shredding, the shredder will stop and the bin full
indicator will illuminate (
Jam Free Technology in Manual
Feed Slot
Sensors in the paper feed area measure the thickness of
paper about to be shredded. The ability to shred or not is
communicated through red and green lighting. Green means
that the stack of paper is within the shredders sheet capacity
and OK to shred. Red means that you have too much paper,
remove some sheets in order to shred.
By preventing you from shredding more sheets of paper than
the shredder is capable of handling, paper jams are prevented.
This prevents wasting time reversing paper to unblock jams
and the mess they can create.
Rare Occasions of Jamming
In the unlikely event of the shredder jamming, the Stack-
and-Shred 750X will stop shredding. Check that the bin is
not full then try clearing the jam using the reverse (
and continuous jam boost (
mode ( ). If this is unsuccessful follow the reverse function
instructions.
Auto Jam
Free
Blue Green
light light
light
light
light
light
light
light
light
light
light
light
light
light
light
light light
light light
).
)
) buttons then return to Auto
Red
light
light
light
light
light
light
light
light
flash
