T7.0 Treadmill • Model No. 831.24977 • Revised 08/19/11
®
For detailed instructions, see the User's Manual. Note: The underside of the walking belt is coated with high-
performance lubricant. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth
and a mild, non-abrasive cleaner.
#10 Star
Wa
sher (5)–4
#8 x 1/2" Ground
Screw (6)–1
3/8" x 2" Bolt (2)–2
G
UIDE
5/16" Star
Washer (8)–4
#8 x 1/2" Screw
(1)–14
5/16" x 2 3/4" Screw (12)–4
3/8" x 4" Screw (3)–6
5/16" Flat
Washer (XX)–4
3/8" Star
Washer (10)–6
#8 x 3/4" Tek
Screw (13)–8
3/8" x 2 1/2" Bolt (7)–2
3/8" Nut (9)–4
#10 x 3/4" Screw
(4)–4
