Convaid Carrot 3 Instruction Manual

Child restraint system for children with special needs
Hide thumbs Also See for Carrot 3:
Table of Contents

Advertisement

Quick Links

CARROT 3 - CHILD RESTRAINT SYSTEM
For Children with Special Needs
Instruction Manual
!
WARNING!
Read all instructions
before using this
restraint system.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Carrot 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Convaid Carrot 3

Summary of Contents for Convaid Carrot 3

  • Page 1 CARROT 3 - CHILD RESTRAINT SYSTEM For Children with Special Needs Instruction Manual WARNING! Read all instructions before using this restraint system.

  • Page 2: Table Of Contents

    CARROT 3 CHILD RESTRAINT SYSTEM The Carrot 3 is designed to provide additional support for children who have di culty sitting correctly in conventional car seats. Always consult your doctor to make sure that this restraint system is suitable for your child.
  • Page 3 Table of Contents CHEST SUPPORT ..........14 Chest Support Pad Adjustment .

  • Page 4: Warnings

    Carefully read and understand all instructions on this child restraint and in the written instructions. If you have questions, contact Convaid at 1-888-CONVAID (266-8243). • Use only with children who weigh between 30 and 108 pounds (mass between 13.6 and 49 kg) and whose height is between 37 and 60 inches (94 and 152 cm).
  • Page 5 WARNING ! DEATH or SERIOUS INJURY can occur • Discontinue use of your child restraint if it has been involved in ANY type of accident. It may no longer be effective and should be replaced immediately. • This child seat must not be used in the home, in boats, or other non-certified applications.

  • Page 6: Safety Information

    Convaid Product Registration 2830 California Street Torrance, CA 90503 Or call Convaid at 1-888-CONVAID (266-8243). For recall information, call the U.S. Government’s Vehicle Safety Hotline at 1-888-327-4236 (TTY: 1-800-424-9153) or go to http://www.NHTSA.gov. Important Notes Correctly set up and install the child restraint before using.
  • Page 7 Safety Information WARNING! It is your RESPONSIBILITY to use the Vehicle’s Safety Belts at the same time. DO NOT secure a child only with the harness straps (5-point) of the child restraint; ALWAYS use the vehicle’s lap shoulder (3-point) safety belt at the same time to secure the child restraint and the child.
  • Page 8 Once reclined, re-tighten the harness straps. Reclining the back without loosening the harness straps may cause choking. The Carrot 3 was tested at a 30º recline from vertical, and should not be transported in a moving vehicle past this point.

  • Page 9: Features

    Features: Carrot 3 Standard Model Top Tether Strap (Optional Accessory) Head Pillow Head Support Shoulder Strap Comfort Pads Vehicle’s Belt Path Body Balance Pads Seat Backrest Chest Pad Support Harness Adjuster Harness Yoke Harness Buckle Chest Pad Support Height Adjuster LATCH Connector with 4”...
  • Page 10 Features: Carrot 3 Standard Model Top Tether Strap (Optional Accessory) Shoulder Width Adjustment Button Shoulder Protector Wings (Optional Accessory) Sholuder Harness Backrest Instruction Hip Pads Guide (inside) Lap Belt Guide Storage Pocket Comfort Seat Cushion Seat Depth Adjustment Knob Measurements with 6”...

  • Page 11: Installation

    Installation Lower Anchor and Tethers for CHildren LATCH Installation This child restraint system is recommended for use in a vehicle with LATCH anchors. Verify that your vehicle is equipped with LATCH anchors. Lower Anchor Straps Installation: 1. Press and hold the rst LATCH adjuster release button, then pull the LATCH strap to full length.

  • Page 12: Using Latch Top Tether Strap

    Installation USING LATCH Top Tether Strap If your vehicle is equipped with LATCH Top Tether Anchor points, you can use the Top Tether Strap to attach the Head Support. NOTE: All vehicles manufactured since September 1, 2002 are equipped with tether anchors located behind the rear seats. 1.

  • Page 13: Head Support

    Functions Head Support Head Support Depth Adjustment The Head Support can be adjusted forward or backward by 0.6” (1.5 cm) increments to provide a better t and added protection for the occupant (Fig. A). To Adjust: Remove screws on each side of the head support with a Phillips screwdriver. Move the head support to selected position, and reinsert screws (Figs.

  • Page 14: Shoulder Support

    Functions Harness Strap Shoulder Support Shoulder Harness Harness Adjustment Strap (B) Strap (A) Harness Strap Adjustment The Harness Strap comfortably positions the child in place. To tighten the shoulder harness strap, pull on the harness adjustment strap (Fig. A). To loosen the harness strap, press and hold the harness release lever (Red), while pulling the shoulder harness strap (Fig.

  • Page 15: Shoulder Strap Comfort Pad

    Functions Shoulder Strap Comfort Pad The shoulder strap comfort pad can be moved by readjusting the Velcro attached to the back of the Head Support. Shoulder Protector Wing (OPTIONAL ACCESSORY) The Shoulder Wing has up to 4” of width adjustment. To adjust the width, press/ hold the yellow button on the back of the shoulder wing, and pull the shoulder wing outward to the desired position.

  • Page 16: Shoulder Protector Wing Installation

    Functions Shoulder Protector Wing Installation 1. Detach straps from shoulder strap harness bracket. Remove Fig. A straps and padded covers from chair (Fig. A & B). 2. Press and hold height adjustment buttons, and remove head support (Fig. C & D). 3.

  • Page 17: Chest Support

    Functions Chest Support WARNING! The top of the Chest Support Pad must be at armpit level or lower. Positioning the support pad too high may cause choking Chest Support Pad Adjustment To raise the height of the Chest Support Pad, press & hold the Height Adjustment Lever (Yellow) on the front of the child seat, and pull on the pad (Fig.

  • Page 18: Lateral Support

    Functions Lateral Support Lateral Support Adjustment (OPTIONAL ACCESSORY) Lateral supports are used to maintain midline positioning of the trunk. To adjust: 1. Unfasten the Velcro and the zipper on the back upholstery. 2. Pull back the upholstery. (Fig. A) 3. Loosen 2 screws with a 7/64” Allen Wrench. (Fig. B) 4.

  • Page 19: Backrest

    Functions Backrest IMPORTANT: · Height of the shoulder harness strap moves with the height of the backrest. · The Shoulder Harness Strap must be at or above the child’s shoulders, and parallel to the ground. · The Shoulder Harness Strap is for positioning only, and not designed to support occupant in a crash.

  • Page 20: Seat

    Functions Seat When the child is sitting with knees bent, the total seat length should be slightly shorter than the length from the pelvis, to the rear of the knee. Seat Length Adjustment – 2” or 4” Release lock by pulling the black “D” shaped ring - Seat Depth Release Strap on the front of the child restraint, and while pulling the strap, adjust the position of the rodded seat extension.

  • Page 21: Rodded Seat Extension - Long

    To attach the pommel, insert the seat extension rods* through the holes on the pommel’s attachment bracket, and into the holes on the front of the Carrot’s seat. * A rodded seat extension is required to attach the pommel to the Carrot 3.

  • Page 22: Seat Depth Adjustment

    It attaches with Velcro located on the side of the restraint. Wedge Cushion (OPTIONAL ACCESSORY) The wedge changes the seat-to-back angle by raising the front of the restraint system. Place the wedge under the front of the Carrot 3 seat.

  • Page 23: Pads And Cushions

    Functions Pads and Cushions (STANDARD ACCESSORIES) The following Pads and Cushions are provided as standard accessories, and easily attach / adjust with Velcro. Head Pillow Provides comfort and lateral head support. Body Balance Pads Used to balance / position the user. Hip Pads Provides proper positioning for balance, comfort and support.

  • Page 24: Securing Your Child

    Securing Your Child Securing Your Child Once the child restraint has been installed in the vehicle and adjustments have been made, follow these instructions to secure the child. Fig. A 1. Loosen the harness by pressing the harness strap release lever (Red) on the front of the child restraint, and pull the shoulder straps forward (Fig.
  • Page 25 Securing Your Child WARNING! It is your RESPONSIBILITY to use the Vehicle’s Safety Belts at the same time. DO NOT secure a child only with the harness straps (5-point) of the child restraint; ALWAYS use the vehicle’s lap shoulder (3-point) safety belt at the same time to secure the child restraint and the child.

  • Page 26: Care And Maintenance

    Care and Maintenance Upholstery Cover, Cushions, Pillows and Pads Upholstery Cover: SPONGE CLEAN using cold water & mild soap, and TOWEL DRY. Do not remove the upholstery cover. Contact the distributor for removal or replacement of the upholstery. Cushions, Pillow, and Pads: HAND WASH using cold water and mild soap. LINE DRY or LIE FLAT to prevent shrinkage.

  • Page 27: Warranty

    Warranty For your convenience, record all the information about your child restraint below. Refer to the Serial Number & Manufactured Date Label for all information: LIMITED FIVE-YEAR WARRANTY Product Model: CARROT 3 CHILD RESTRAINT SYSTEM Name: Street Address: City: State:...

  • Page 28: Warranty

    This warranty does not include damages which arise from negligence, minor use not in accordance with the product instruction. The use of non-CARROT 3 covers, inserts, toys, accessories, or tightening devices is not approved. Their use could cause this child seat to fail Safety Standard FMVSS 213, or not to perform as intended in a crash.
