- Page 1 CARROT 3 BOOSTER SEAT - CHILD RESTRAINT SYSTEM For Children with Special Needs Instruction Manual...
- Page 2 CARROT 3 CHILD RESTRAINT SYSTEM The Carrot 3 Booster Seat is an extended version of the standard Carrot 3 child restraint system. The Carrot 3 Booster Seat offers a larger configuration to meet the needs of children that require additional seat growth that is not available on the standard Carrot 3.
-
Page 3: Table Of Contents
Table of Contents Warnings ........................4 Safety Information ....................6 Important Notes ....................6 Certification ......................7 Features ........................8 Installation ........................ 9 LATCH Installation ....................9 Functions ....................... 11 Head Support ......................11 Head Support Depth Adjustment ..............11 Head Support Contour Adjustment ............... -
Page 4: Warnings
(145 cm) and 70” (180 cm). It has been successfully crash tested. • Use in forward-facing only. • Never alter construction of the Carrot 3 Booster Seat child, unless specially authorized in the instruction manual. • Adjust the belts provided with this child seat so they fit snugly around your child. -
Page 5: Page Header
WARNING! Page Header DEATH or SERIOUS INJURY can occur • The child restraint system cover should only be replaced with the one recommended by the manufacturer. • This instruction manual should be stored in the pocket on the back of the child restraint system. -
Page 6: Safety Information
Safety Information Important Notes Correctly set up and install the child restraint before using. Before each use, verify it is securely installed to the vehicle seat and the harness is properly adjusted around child. • Adjust harness to fit securely around the clothes the child is wearing. Remove bulky coats and/or jackets before putting child in restraint system. -
Page 7: Certification
Once reclined, re-tighten the harness straps. Reclining the back without loosening the harness straps may cause choking. The Carrot 3 was tested at a 30º recline from vertical, and should not be transported in a moving vehicle past this point. Recline... -
Page 8: Features
Features Head Pillow Head-Support Comfort Pads Shoulder Protector Wing Booster Seat 4-Point Backrest Harness Strap Table Feet Receiver Vehicle’s Belt Path Metal Yoke Backrest Release (D-shape) Ring Instruction Manual (in pocket) Seat Depth Adjustment Knob... -
Page 9: Installation
Page Header Installation Anchor. Tether. LATCH The next generation of child safety. Lower Anchor and Tethers for Children LATCH Installation This child restraint system is recommended for use in a vehicle with LATCH anchors. Verify that your vehicle is equipped with LATCH anchors. Lower Anchor Straps Installation: 1. - Page 10 Installation USING LATCH Top Tether Strap If your vehicle is equipped with LATCH Top Tether Anchor points, you can use the Top Tether Strap to attach the Head Support. NOTE: All vehicles manufactured since September 1, 2002 are equipped with tether anchors located behind the rear seats.
-
Page 11: Functions
Functions Head Support Head Support Depth Adjustment The Head Support can be adjusted forward or backward by 0.6” (1.5 cm) increments to provide a better fit and added protection for the occupant (Fig. To Adjust: Remove screws on each side of the head support with a Phillips screwdriver. -
Page 12: Shoulder Support
Functions Shoulder Support Shoulder Width Adjustment The Shoulder Protector wing can be extended by 4” (100mm), by extending the right and left sides by 2” (50 mm) each. To extend the Shoulder Protector wing by 4” (100mm) you must move the wing to the fifth position. -
Page 13: Backrest
Functions Backrest IMPORTANT • The height of the Shoulder Harness Strap moves with the height of the Backrest. • The level of the Shoulder Harness Strap must be at or above the occupant’s shoulders, parallel to level ground. Backrest Height Adjustment Release the lock ring by pulling the Backrest Release (D-shape) ring on the back of the occupant child seat. -
Page 14: User's Seat Measure
Functions User’s Seat Measure Seat To determine the appropriate seat depth for a user, the user should be placed in the best possible seated position that can be obtained. A measurement is taken from the back of the pelvis (furthest part of the buttocks), forward to the back of the knee. -
Page 15: Accessories
Functions Accessories Support Tray The X-Large support tray is designed specifically for the booster seat and may not be used to secure the child’s upper limbs. Seat Wedge Use to increase and adjust the height and angle of the front area of the seat for better secure and stability of seating. -
Page 16: Crotch Belt For Xl/Booster Seat Only
Functions Crotch Belt for XL/Booster Seat only ATTENTION: This accessory is only adaptable to the latest version of XL/ Booster seat which has a slit and holes in the center area of the seat and fabric. 1. Undo the seat cover partly by unfastening the Velcro and zipper on ®... -
Page 17: Securing Your Child
Securing Your Child Once the Carrot 3 Booster Seat has been installed in the vehicle’s seat and adjustments have been made, follow these instructions to secure the child. • Loosen the harness and unfasten the harness buckles (upper and lower). Move the harness straps to the side of the seat (Fig. - Page 18 Securing Your Child WARNING: In order to avoid injury or choking the child, always manually test the straps to ensure child’s safety and comfort (Fig. J) Reconfirm that the 4-piece harness is not twisted and the child is properly secured. After you secure the child with the 4-point harness, fasten the vehicle’s lap shoulder 3-point safety belt over the Carrot seat routing through the RED belt...
- Page 19 Securing Your Child • Always pull on the harness after securing the occupant to ensure the buckle tongues are secure in the harness buckle. • Always park your car in a safe place when you make any adjustments to the child restraint system, including reclining the car seat. Adjusting and/ or handling the child restraint system during driving could cause SERIOUS INJURY to you and your child.
-
Page 20: Care And Maintenance
Care and Maintenance Upholstery Cover, Cushions, Pillows and Pads Upholstery Cover: SPONGE CLEAN using cold water & mild soap, and TOWEL DRY. Do not remove the upholstery cover. Contact the distributor for removal or replacement of the upholstery. Cushions, Pillow, and Pads: HAND WASH using cold water and mild soap. LINE DRY or LIE FLAT to prevent shrinkage. -
Page 21: Product Dimensions
Product Dimensions Specifications 20 - 22” (510 - 560 mm) Overall Width 15 - 16.5” (380 - 420 mm) Seat Depth 20” (510 mm) Seat Width 29 - 34” (745 - 870 mm) Extendable Backrest Height 21 lbs (10.5 kg) Product Weight 79 - 165 lbs (36 - 75 kg) Target User Weight... -
Page 22: Limited Warranty
Warranty LIMITED WARRANTY Product Model: CARROT 3 Booster Seat Name: _________________________________________________________ Street Address: __________________________________________________ City: ____________________ State: ________________________________ Zip Code: ______________ Country: ________________________________ Phone Number: _________________________________________________ Email Address: ___________________________________________________ Lot Number: ____________________________________________________ Serial Number: CT3 - _____________________________________________ Manufactured Date: ______________________________________________... - Page 23 This warranty does not include damages which arise from negligence and/or misuse not in accordance with the product instruction. The use of other (non-Carrot 3 Booster Seat) covers, inserts, toys, accessories, or tightening devices is not approved. Their use could cause this child seat to fail Safety Standard FMVSS 213, or not perform as intended in a crash.
