FLASH12P CONFIGURATIONS (FIG.6)

FLASH12P
(8 ohm)
basic system
L
R
LEFT
FLASH12P (8 ohm sat) + SW115P (8 ohm sub)
(full system impedance = 4 ohm)
L
R
LEFT
FLASH12P
(8 ohm)
doubled system
FLASH12P (8 ohm sat) + SW115P (8 ohm sub)
(full system impedance = 4 ohm)

FLASH12P CONFIGURAZIONI (FIG.6)

RIGHT
FLASH12P FLASH12P
(8 ohm) (8 ohm)
basic system doubled system
RIGHT
basic system
2x FLASH12P
200W x2 (400W)
amplifier suggested:
HP-X900
doubled system
4x FLASH12P
200W x4 (800W)
amplifier suggested:
HP-X1200
SUB+SAT system
2x SW115P
+
2x FLASH12P
550W x2 (1100W)
amplifier suggested:
HP-X1200
