Table Of Contents; Technical Specifications; Specifiche Tecniche - PROEL FLASH12A-V2 User Manual

INDEX
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . 3
FREQUENCY RESPONSE . . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONS AND FLYING POINTS . . . . . . . . . . . . . 4
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
FLASH12A CONTROL PANEL (FIG.1) . . . . . . . . . . . . 6
FLASH12A CONNECTIONS (FIG.2) . . . . . . . . . . . . . 6
FLASH12A CONFIGURATIONS (FIG.3) . . . . . . . . . . . 7
FLASH12P INPUT PANEL (FIG.4) . . . . . . . . . . . . . . . 8
FLASH12P CONNECTIONS (FIG.5) . . . . . . . . . . . . . 8
FLASH12P CONFIGURATIONS (FIG.6) . . . . . . . . . . . 9
SAFETY AND PRECAUTIONS . . . . . . . . . . . . . . . . . 10
IN CASE OF FAULT . . . . . . . . . . . . . . . . . . . . . . . . . 10
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . 10
CE CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . 11
INSTALLATION AND DISCLAIMER . . . . . . . . . . . . . 11
POWER SUPPLY AND MAINTENANCE . . . . . . . . . 11
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . 12
FLASH12A INSTRUCTIONS (FIG. 1 / 2 / 3) . . . . . . 12
FLASH12P INSTRUCTIONS (FIG. 4 / 5 / 6) . . . . . . 14

TECHNICAL SPECIFICATIONS

MODEL FLASH12A-V2
System type
Low Frequency Device
High Frequency Device 1" CELESTION compression driver with 1"VC
Angular Coverage
Frequency Response 50 Hz - 20 kHz
Sensi vity
Crossover Frequency
Nominal Impedance
Input Con nuous Power
Input Peak Power
Max SPL at 1mt (peak)
Amplifi er Con nuous HF: 50 W Class AB
Power LF: 250 W Class D (SMPS)
Input Impedance 30 kohm balanced
15 kohm unbalanced
Input Sensi vity LINE: +4 dBu / MIC: +34 dBu
Controls MIC GAIN, LINE LEVEL,
LOW EQ, HIGH EQ, GND li
Connectors
LINE: Combo XLR-F / JACK
Power Supply 230 V~ or 120 V~ - 50/60 Hz
Rated Consump on
Construc on Hi Density Polypropylene with Metal Grid
Cabinet Colour
Flying System
Pole Adapter
Handles
Monitor taper
Weight
Dimensions (W x H x D)
FLASH12P-V2
2-way vented
12" woofer with 2"VC
90° H x 60° V
60 Hz - 20 kHz
- 98 dBspl @ 1W / 1m
2100 Hz 2400 Hz
- 8 ohm
- 200 W
- 400 W
125 dBspl 124 dBspl
-
-
-
-
MIC: XLR-F 2 x NL4 speakon
(linked)
LINK: XLR-M
-
255 W -
Black
4 x M10
1 x bo om
2 x sides, 1 x top
42°
16.5 Kg (36.4 lb)
390 x 630 x 360 mm
INDICE
SPECIFICHE TECNICHE . . . . . . . . . . . . . . . . . . . . . . 3
RISPOSTA IN FREQUENZA . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONI E PUNTI DI SOSPENSIONE. . . . . . . . . 4
ACCESSORI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
FLASH12A PANNELLO DI CONTROLLO (FIG.1) . . . . 6
FLASH12A CONNESSIONI (FIG.2) . . . . . . . . . . . . . . 6
FLASH12A CONFIGURAZIONI (FIG.3) . . . . . . . . . . . 7
FLASH12P PANNELLO INGRESSO (FIG.4) . . . . . . . . 8
FLASH12P CONNESSIONI (FIG.5) . . . . . . . . . . . . . . 8
FLASH12P CONFIGURAZIONI (FIG.6) . . . . . . . . . . . 9
AVVERTENZE PER LA SICUREZZA . . . . . . . . . . . . . 15
IN CASO DI GUASTO . . . . . . . . . . . . . . . . . . . . . . . 15
PROBLEMATICHE COMUNI . . . . . . . . . . . . . . . . . . 15
CONFORMITÀ CE . . . . . . . . . . . . . . . . . . . . . . . . . . 16
INSTALLAZIONE E LIMITAZIONI D'USO . . . . . . . . . 16
ALIMENTAZIONE E MANUTENZIONE . . . . . . . . . . 16
INFORMAZIONI GENERALI . . . . . . . . . . . . . . . . . . 17
FLASH12A ISTRUZIONI (FIG. 1 / 2 / 3) . . . . . . . . . 17
FLASH12P ISTRUZIONI (FIG. 4 / 5 / 6) . . . . . . . . . 19

SPECIFICHE TECNICHE

MODELLO
Sistema
Altoparlante bassi
Altoparlante al driver a compressione 1" CELESTION - 1" VC
Copertura angolare
Risposta in Frequenza
Sensibilità
Frequenza Crossover
Impedenza Nominale
Potenza Con nua
Potenza di Picco
SPL max a 1m (picco)
Potenza Con nua Al : 50 W Classe AB
Amplifi catore Bassi: 250 W Classe D (SMPS)
Impedenza ingresso 30 kohm bilanciato
15 kohm sbilanciato
Sensibilità ingresso LINE: +4 dBu / MIC: +34 dBu
Controlli MIC GAIN, LINE LEVEL, LOW
EQ, HIGH EQ, GND lif
Conne ori
LINE: Combo XLR-F / JACK
Tensione alim. di rete 230 V~ or 120 V~ - 50/60 Hz
Consumo nominale
Costruzione Polipropilene Alta Densità con Griglia in Metallo
Colore
Sistema di sospensione
Flangia per suppor
Maniglie
Inclinazione monitor
Peso
Dimensioni (LxAxP)
FLASH12A-V2 FLASH12P-V2
2 vie bass-refl ex
woofer 12" - 2" VC
90° H x 60° V
50 Hz - 20 kHz 60 Hz - 20 kHz
- 98 dBspl @ 1W / 1m
2100 Hz 2400 Hz
- 8 ohm
- 200 W
- 400 W
125 dBspl 124 dBspl
-
-
-
-
MIC: XLR-F 2 x NL4 speakon
(in parallelo)
LINK: XLR-M
-
255 W -
Nero
4 x M10
1 x so o
2 x ai la , 1 x sopra
42°
16.5 Kg
390 x 630 x 360 mm
