Page 1: Operation Manual
Operation Manual Wireless Waterproof LCD TV ASV1743 BW ASV1743 SW... - Page 2 Catalogue Brief introduction Specification III. Safety Guide List of Package and Installation Wires Connection Panel Key Functions VII. Operation Instructions VIII. Wireless Trouble-shooting AquaSound www.aquasound.nl De Run 6720 info@aquasound.nl 5504 DV Veldhoven tel. 040-2534205 fax 040-2541645...
-
Page 3: Power Management
Brief introduction to the product. AquaSound does not assume any liability beyond the application or use of any products, or software described herein. AquaSound further reserves the right to make changes in any products described herein without notice. This publication is subject to change without notice. - Page 4 What is 802.11 a/b/g? This Wireless Display uses IEEE’s general 2.4 GHz 802.11b/g, and 5 GHz 802.11a, two kinds of frequencies used for wireless LAN specifications. The Wireless Display can automatically select the most appropriate frequency to use. Using advanced compression technology, it has a 11 ~ 54 Mbps capacity to constantly transfer and receive high quality video content.
-
Page 5: Specification
Specification Model ASV 1743 BW / ASV 1743 SW Screen size 17 Inch Aspect ratio 16:9 Screen brightness 385cd/ m² Contrast ratio: 400:1 Pixel H x V: 1440*900 Response time: 16ms Speaker (built-in) 5W*2 frequency range:400~20KHz Waterproof grade: IPX6 Power consumption DC12V/45W Dimension: (mm) 472mm*315mm*65mm... -
Page 6: Safety Guide
III. Safety Guide General Cautions: Designation and production of this LCD TV series meet international safety standard. User should read manual carefully before using the product, and follow instructions of the manual to ensure correct usage. Any of the following cases happen; user should stop using the product: Smoking, burning smell, no image, no sound, big sound, damage of outer housing, liquor or objects entering into product, or other irregular condition that might cause fire or electronic shock. - Page 8 III. List of Package and Installation: Please find following parts in the package. Wireless TV set Transmitter Remote controller Auxiliary transmitter to control DVD player AV wire Power adaptor for transmitter SCART plug to 3RCA plugs Power adaptor for TV...
-
Page 9: Installation Instruction
RCA MALE TO F FEMALE PAL FEMALE TO RCA MALE B ol t N ut T ube B ase M ai n F ram e M ai n F ram e N ut Plate for bath room (wall-mounting) Stainless tube (optional) for bath tub fixed) Installation: Bathtub mounting: you can select both models, to have a stainless tube described above by which the TV is installed on bath-tub or spa. - Page 10 V. Wires Connections Power adaptor input Rear view of transmitter C C D C am er a Lapt op Option 00: 08:28 00: 08:28 ² ¥ · Å Ô Ý Í £ Í £ Ö ¹ ³ ö ² Ö ²...
- Page 11 SCART Connection Chart Rear view of transmitter Item socket Source of signal antenna input Transmitting signal Transmitter box RJ-45 Input/output PC/ router power input DC-7.5V 2A S port input video Digital camera Head of output Remote controller for transmitter peripheral 6, 7, 8 AV-1 input...
- Page 12 POWER ON/OFF DIGITAL TUBE LINK ENTER DOWN POWER ACTIVE SOURCE STEREO Panel Key Functions 6.1 TV Panel Keys 1 Mode key 5 Menu 2 Confirm key 6 Decrease 3 Lock key 7 Increase 4 Power key 6. 2 Remote Controller Keys ON/OFF Mute Decrease...
- Page 13 Cautions using remote controller: 1. Keep remote controller transmitter head from direct sunlight to avoid fault. 2. To ensure good waterproof function, battery is pre-installed before shipment. 3. When battery is low, please replace it in time, otherwise it will affect sensitivity. 4.
- Page 14 VII. Operation Instruction Note: In this paragraph, operation for TV panel is “Touch”, and operation for remote controller is “Press” Confirm right connection and power light is on. Set on TV power source, to light up the backlight of keys, which are clearly shown on the screen panel, so further operations are possible.
- Page 15 Transmitter Be sure correct connection between power source of transmitter and wireless TV, and then apply power. You will see power source indicator light (Orange) is light on, stereo indicator light (Red) is light on, state indication light is twinkling. (Green) Wireless TV Now that everything is in place, connected and ready, it is time to turn on the devices, establish a connection between your Wireless TV and the transmitter.
- Page 16 SSID EXIST(UP/DOWN) The reason that cause the result of “0 SSID EXIST (UP/DOWN)”might be blockage of signal. Turn off transmitter for a while and then turn on it again. When failure happens, try to check if they are within effective distance, position and hindrance, or try to select another suitable channel on transmitter to avoid disturbance.
- Page 17 NO Signal Through “SOURCE” key to select models, selectable models list below: “AV1, AV2, SV, TV” In TV mode, and then press “ENTER” key, screen display following menu : WIRELESS CHANNEL 007 STEREO A TV SYSTEM I TV FINE TUNE POWER ADDDLEL OFF 007 IRC/ M/N TUNER SCAN MPEG BITRATE 4.5MHz...
- Page 18 PRO GRAM ADD DEL O FF 00 7 IRC/M/N TUNER SC AN MPEG BITRATE 4 .5MH z SCAN ALL TX PASSW ORD C HANG E POW ER- OFF When select “WIRELESS CHANNEL 007”, through “DOWN”, “UP” key to increase or decrease wireless channels, which include 01, 03, 05, 07, 09, 11, 36, 40, 48, 52, 56, 60, 64, 149, 153, 157 and AUTO.
- Page 19 STER EO A Select “TV SYSTEM”, through “DOWN” “UP” key to select proper TV system, selectable TV system including: “TV SYSTEM I”, “TV SYSTEM G/H”, “TV SYSTEM M/N”, “TV SYSTEM B”, “TV SYSTEM D/K” TV SYSTEM I Select “TV FINE TUNE” to conduct fine tune. TV FINE TUN E Select “PROGRAM ADD DEL OFF 007 IRC/M/N”, through “DOWN”...
- Page 20 PRO GRAM ADDD EL OFF 007 IRC /M/N Select “MPEG BITRATE 4.5MHz”through “DOWN” “UP” to choose bit rate, which include “AUTO” and 3MHz, 3.6MHz, 4.5MHz, 5.4MHz, 6MHz, 6.7MHz, 7.2MHz, 8MHz, 9MHz, 10.8MHz, 12MHz, 13.5MHz. MPEG BITRATE 4 .5MH z Select “TUNER SCAN” through “DOWN” “UP” to select “TUNER SCAN G/H”, “TUNER SCAN I AIR”, “TUNER SCAN I”, “TUNER SCAN D/K AIR”, “TUNER SCAN D/K”, “TUNER SCAN B AIR”, “TUNER SCAN B”,“...
- Page 21 ALL TX SEARCHING Select “PASSWORD CHANGE” item, and then press “SOURCE” key, screen display “ORIGINAL PASSWORD” at the time, you may set password for starting-up. ( four-digit number for password.) through “UP” key to select a digit from 0~9, pressing “ENTER”to set next digit.
- Page 22 * * * * CONFIRM NEW PASSWORD Select “POWER-OFF” and then pressing “ENTER” key to turn off wireless TV. POW ER- OFF...
-
Page 23: Wireless Troubleshooting
VIII. Wireless Trouble-shooting Wireless Signal This monitor (Receiver) only can receive signals from transmitter box. Location and user environment will influence signal transmission quality. So, in order to get a high performance signal, choose a proper location to place the transmitter box. Sometimes you will lose signal when watching TV. - Page 24 But if you change to a channel that is so bad, the connection between TV and the transmitter can break. The way to get out of this trap by setting on TV might be in vain,now try to move either the TV or transmitter closer to get connected again when the distance is too far, or set the transmitter by following steps when interference is strong: To make this change, do the following.
- Page 25 About Usage under low temperature When use under low temperature, reaction of LCD screen might slow down. In some cases, the feature might cause image remaining, it is not fault. Once back to normal temperature, it will resume. AquaSound www.aquasound.nl De Run 6720 info@aquasound.nl 5504 DV Veldhoven tel.
