LG 47LX9500 Owner's Manual

Led lcd tv / plasma tv
Hide thumbs

Advertisement

User's Guide Specification
User's Guide Specification
1.
Model Description
MODEL
LX95/PK950
SUFFIX
USA
2.
Printing Specification
1. Trim Size (Format) :
2. Printing Colors
• Cover :
1 COLOR (BLACK)
• Inside :
1 COLOR (BLACK)
3. Stock (Paper)
• Cover :
Coated paper , S/White 150 g/㎡
Uncoated paper , 백상지 60 g/㎡
• Inside :
4. Printing Method :
5. Bindery :
6. Language :
7. Number of pages :
"This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,
N
Details should be followed Eco-SCM management standard[LG(56)-A-2524].
O
Especially, Part should be followed and controlled the following specification.
T
(1)Eco-hazardous substances test report should be submitted
E
when Part certification test and First Mass Production.
S
(2) Especially, Don't use or contain lead(Pb) and cadmium(Cd) in ink.
3.
Special Instructions
(1) Origin Notification
* LGEMX : Printed in Mexico
* LGERS : Printed in Mexico
* LGEAZ : Printed in Brazil
* LGESP : Printed in Brazil
* LGESY : Printed in China
4.
Changes
9
8
7
6
5
4
3
Apr./22/10 Park sun young
2
Apr./20/10 Park sun young
1
REV.
SIGNATURE
MM/DD/YY
NO.
BRAND
Product Name
182mm x 257 mm
Off set
Saddle stitch
English/Korean (2)
36
* LGENT : Printed in China
* LGENP : Printed in China
* LGEIL : Printed in India
* LGEDI : Printed in Indonesia
* LGEIN : Printed in Indonesia
S0-86634
S0-86321
CHANGE NO.
LG
LX9500/PK950
* LGEMA : Printed in Poland
* LGEWA : Printed in U.K.
* LGEEG : Printed in Egypt
* LGERA : Printed in Russia
* LGEAK : Printed in Kazakhstan
Deleted 3D glasses for LX9500 and deleted Korean manual.
Applied PQ test results of LX9500-U.
CHANGE
담 당
관 리 자
KANG
Park SY
KWANG SUK
10.03.29
10.03.29
Part No.
MFL62882711
(1004-REV02)
* LGETH : Printed in Thailand
* LGEVN : Printed in Vietnam
