- Page 1 14021600 ed8.qxp 16/03/05 11:46 Side 1 KIRK 3040 for KIRK Wireless Server 1500 and 500 User’s Guide VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 2: Table Of Contents
11:46 Side 2 Congratulations on your new KIRK handset Your new handset from KIRK telecom will provide you with the greatest possible degree of flexibility and mobility due to high battery capacity, practical weight, size and design. Contents: 1. Construction ................4 7.5.1 Create subscription..........21... -
Page 3: Construction
MENU key Display with backlight 1. Construction Left arrow key, Redial menu Key for internal calls from standby text (not used on KIRK Wireless Server 1500) Keyboard LOCK (Menu*) Headset Connector (ACS Stratus Ultra) Right arrow key, save number. Telephone book menu from... -
Page 4: Charging
LED flashes at a low frequency while charging and lights constantly when the charging is finished. The display goes back to normal mode when fully charged. KIRK ..When the handset is placed in the charger it will not vibrate, and B-answer is inactive. If the battery is fully dis- charged, up to 10 min. -
Page 5: Turning The Handset On/Off
- On hook/off hook and turn ON. ” ” - * (Change from pulse to DTMF on KIRK Wirelss Server), Long = pause (-), extra long: change from pulse to DTMF (a ”T” appears in the display, GAP standard). “0-9”... -
Page 6: Making A Call
CLIP or the name of the person who called and the LED is on. Press the -key, the -icon will flash until the connection is established. Using the handset in residential systems: (not on KIRK Wireless Server 1500 and 500) Internal call post-dial: Press the INT-key, the -icon in the display will flash... -
Page 7: Receiving Calls
14021600 ed8.qxp 16/03/05 11:46 Side 7 6.1. Receiving calls If the phone rings, the call can be answered by pressing the -key. When ringing the LED flashes fast, and the display shows the CLIP (if presented). If it is an external call (or if no CLIP) the display shows “INCOMING CALL”... -
Page 8: Menu Structure
-key, jumps to a lower level in the menu. When the lowest menu level is reached, it will store the setting and jump to a higher level. It has to be used if a “YES” is wanted. KIRK MENU MENU... -
Page 9: The Key Functions
14021600 ed8.qxp 16/03/05 11:46 Side 9 7.2 The key functions Æ Ø Å @ Ä Ö ß Ü 1 A B C @ Ä Á À Â 2 D E F 3 G H I Ï Î 4 J K L 5 M N O Ö... -
Page 10: Profile Set Up
: Can be turned on/off using the > and <. Confirm with ( ). When turned on, the telephone automatically goes ANSWER off hook when ringing. If subscribed to a KIRK solution it automatically goes on hook when calls are terminated. : Automatic on-hook is only reliable under defined conditions related to the interface settings between the EMARK KIRK Wireless Server and the PBX. -
Page 11: Menu Subscription And Login
14021600 ed8.qxp 16/03/05 11:46 Side 11 SUBSCRIPTION 7.5 Menu subscription and login REMOVE MENU REMOVE? LOGIN PASSWORD _ _ _ _ _ MENU SUBSCRIPTION SUBSCRIPTION SUBSCRIPTION SELECT LOGIN CREATE REMOVE REMOVE LOGIN CREATE REMOVE SYSTEM1* SEARCH ID: SYSTEM 1 123456789012 REMOVE REMOVE REMOVE... -
Page 12: Login
14021600 ed8.qxp 16/03/05 11:46 Side 12 7.5.2 Login The handset can be subscribed to 10 different systems enabling you to use the same handset on 10 different systems. If you would like to change to another system, use the login menu to connect to another system number. The actual chosen system is shown with the red LED on. -
Page 13: Remove Subscription
If one of the systems not chosen is removed, the handset remains connected to the system in use. 7.5.5 Change startup text The startup text is predefined as i.e. ”KIRK telecom” as factory default. This can be changed by using the fol- lowing procedure: Press **** , BOOK, ( ) and give in the new startup text by the keyboard followed by ( ). -
Page 14: Redial
It is possible to edit the CLIP or redial numbers. Find the number you wish to edit and press the digits you want to add to the number, e.g. prefix = O. The Redial and CLIP stack Menu (fig) KIRK < BILL GATES... -
Page 15: Book
After storing the telephone will go back to standby mode. If the display shows “MEMORY FULL”, it is necessary to delete KIRK TELECOM one or more numbers from the telephone book. (See menu structure page 29) -
Page 16: External Services
7.9 External services External services are facilities placed in the main system, and only available if the handset is subscribed to a KIRK solution. Under External services can be found. Clip stack, Delete clip stack and local Phone book. The Local Phone book is a comman Phone book for all handsets subscribed to the actual system, and all handsets subscri- bed to the system are listed in the Phone book. -
Page 17: Mail/Textmessages
14021600 ed8.qxp 16/03/05 11:46 Side 17 7.11 Mail/Text Messages Available in systems configured with the possibility of sending text messages At the reception of a text message the envelope icon appears in the display. The envelope icon is indicating one or more unread messages. The text message is shown in the display, and when the message is read the envelope icon will disappear. - Page 18 -key, type the number of the receiver and confirm with the -key. The messa- ge is send. Note In case a sent message is not received, the sender will get a message in the display. KIRK telecom The Mail Menu (fig) MAIL N25-01 04.38 L26-01 14.32 N28-01 15.46...
-
Page 19: Menu Language
There are 6 predefined languages in the handset: English, German, French, Italian, Spanish and Dutch. Select the required language by pressing the -key. If a 7th language is present this will be shown as ”OPEN”. The ”OPEN” selection is a specific dealer language and is factory programmed. KIRK SET PROFILE PROFILE LANGUAGE... -
Page 20: Information
9.2 Error information Improper function of the handset might be related to the installation of the KIRK solution or failures related to the main system. Before declaring a handset for repair be sure that the main system is operating properly. -
Page 21: Technical Information
14021600 ed8.qxp 16/03/05 11:46 Side 21 9.4. Technical information Approvals Acoustics: TBR 10 Electrical: TBR 6 (DECT RF) Access profile: TBR 22 (GAP) EMC: ETS 300 329 (CE labelling) Size and weight Size: 143 x 48 x 26 mm Weight: 121 g including battery ±...
