KIRK 50xx, 60xx, 70xx + Butterfly manual
A. Initial operation
1. Requirements
Using this Spectralink IP telephone with your telephone system merely requires a sound broadband
connection.
The base is solely operated with Power over Ethernet (PoE). That means if your Ethernet connection
does not support PoE, you also need a PoE power supply for your base.
2. Adding an extension
All telephones sent to you are preconfigured and connected to the telephone system. If you prefer to
configure the devices yourself, please refer to the administration portal manual.
Register handsets to the base:
This is done via the menu on your KIRK handset.
1.) Press "Menu" on your handset display.
2.) Then select menu item "Settings".
3.) Next, select "Advanced...".
4.) Now, select "Access".
5.) Now, register your KIRK handset to the base using "Set up access". Now, it scans for existing
bases.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50xx and is the answer not in the manual?

Questions and answers

Related Manuals for Kirk 50xx

Summary of Contents for Kirk 50xx

  • Page 1 1.) Press “Menu” on your handset display. 2.) Then select menu item “Settings”. 3.) Next, select “Advanced...”. 4.) Now, select “Access”. 5.) Now, register your KIRK handset to the base using “Set up access”. Now, it scans for existing bases.
  • Page 2 ACD-data and user are required. In this case, please fill out both boxes with “9876”.) Your KIRK handset is now registered to the base. To cancel the registration of your handset to the base, you have to enter your password.

  • Page 3: Lock Keypad

    1.4. Lock keypad • To lock the keypad, press Menu, then • To unlock the keypad, press Unlock, then 2. Speed dial 2.1. Preset speed dials The preset speed dials are assigned to various handset keys. These cannot be changed. Call forwarding: Press the Answer key, then R.

  • Page 4: Placing Calls

    Custom speed dials You can add functions to a list with personal speed dials.Access this list using the right display key. Adding a speed dial: 1.) Press Shortcut. 2.) Scroll to Edit shortcut and press Select. 3.) Press Select, to add the function to the list of custom speed dials. Using a speed dial: 1.) Press Shortcut.

  • Page 5: Answering Calls

    • Press and hold one of the keys (0-9) for three seconds until the call is placed. (first, you have to assign a telephone number from the phone book to the key). From the call list: 1.) Press the left side of the navigation key to open the call list. 2.) Scroll to the respective name or number and press From the phone book: 1.) Press Menu to access the main menu.

  • Page 6: Unattended Call Transfer

    4.6. Unattended call transfer During a call, press the R key and dial the number to transfer to. Wait for the call to be connected and hang up with when you hear the dial tone. The call is now automatically transferred without being attended.
  • Page 7 6. Vibration alert on and off Press Menu to open the main menu. Scroll to Settings and press Select. Scroll to Vibration alert and press Select. Scroll to On or Off and press Change. Press Return. 7. Adding phone book contacts Press Menu to open the main menu.

  • Page 8: Call Forwarding

    Returning a call from voicemail: To return a call straight away after listening to a message, select “3” for Advanced options, then “2” for Return call. The telephone number is announced and the call connected. 9. Call forwarding You can configure various call forwarding scenarios. For this purpose you can use the call forwarding profiles.
  • Page 9 applies. If the extension is a member of a queue or a group and the queue or group receives a call, call forwarding for the individual extension no longer applies! In general, the destination should always be an available destination number. I.e., make sure that no voicemail or announcement comes on.
  • Page 10 You can then assign the handsets to the bases as described above. This only applies fot the Spectralink IP DECT server 400. 2. KIRK Repeater The Spectralink Repeater extends the coverage of your Spectralink solution. While the Repeater does not increase the number of data traffic channels, it does provide for a greater physical spread of the channels and therefore, extends the range covered by the bases.
  • Page 11 If neither the manuals nor the FAQs or other contents of the support website provide a solution, you can open a support ticket by phone. Our support staff is available Monday to Friday from 8:00 am to 6:00 pm at +44 20 3740 6740 for UK and +49 800 63 66 555 for Germany.
