Wiring Diagram - Python 592 Owner's Manual

Wiring Diagram

Status LED
Control Center 6711T
D2D jumpers; Factory setting is horizontal position.
Most Xpresskit modules use this setting, check the
Xpresskit installation guide for the specific setting.
LIGHT FLASH POLARITY
(10A (MAXIMUM) FUSE JUMPER)
+ -
10A FUSE
MINI ATM
RPN: 8540
Main Harness (H1)
(see wiring tables)
IMPORTANT! Neutral Safety
switch must be plugged in
and in the ON position
© 2009 Directed Electronics. All rights reserved.
Control button
Neutral Safety
ON
Switch
Bitwriter
Port
Temperature
Sensor
Door Lock
(see wiring tables)
CPU1
RF Port
for IVU
D2D Port (for external
Xpresskit interface module)
H2 Harness
(see wiring tables)
Remote Start (H3)
(see wiring tables)
Optional Mux Port
(for additional sensors)
Control Center
5
