This appendix shows the pinouts of the DP-100+ parallel and
serial printer ports.

Parallel Ports

The following table lists the pinouts of the print server's 25-pin
parallel port connector (identical to the connector used on most
personal computers), as well as the 36-pin Centronics
connector used on most printers.
Signal names beginning with n are active -low signals.
25-pin Centronics
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9

Port Pinouts

DP-100+ Multiprotocol Ethernet Print Server User's Guide
5 P
ORT
Signal
nStrobe
Data 1
Data 2
Data 3
Data 4
Data 5
Data 6
Data 7
Data 8
P
INOUTS
Source
Host
Bi-directional
Bi-directional
Bi-directional
Bi-directional
Bi-directional
Bi-directional
Bi-directional
Bi-directional
B
