This product can be set
up using any current web
browser, i.e., Internet Explorer
6 or Netscape Navigator 7.0

Before You Begin

The Quick Installation Guide provides you with the step-by-step instructions to set up your
MFP Server, and lets you start your printing tasks. The model you have purchased may be
slightly different from those described in the illustrations. For more detailed information on the
MFP Server, its components, making network connections and technical specifications, please
refer to the User's Guide that is included in your MFP Server's Installation CD.
NOTE: The illustrations or setting values in this manual are FOR YOUR REFERENCE ONLY.
The actual settings and values depend on your MFP Server, system and network.
Check Your Package Contents
If any of the above items are missing, please contact your reseller.
©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders.
DPR-1061 Wired Multi-Function Print Server
CD-ROM (Software, Manual and Warranty)
Ethernet (CAT5 UTP) Cable
5V DC, 2.5A Power Adapter
Software and specifications subject to change without notice.
DPR-1061
Wired Multi-Function

Print Server

Using a power supply
with a different voltage
rating will damage this
product and void its
warranty.
