LED indicators

Each LED represents a different display adjustment. Use the Select button
to choose the item to be adjusted and the Adjust button to change the
setting.
.
Brightness: Adjusts the brightness of the display.
.
Contrast: Adjusts the contrast, the difference between
the light and dark areas on the screen.
.
H-Size: Adjusts the display width (horizontal size).
.
H-Phase: Adjusts the horizontal position of the display
(left or right).
.
V-Size:
size).
.
V-Center: Adjusts the vertical position of the display
(up or down).
.
Pincushion: Controls the concave and convex curve at
the vertical edges of the display.
.
Trapezoid: Controls the trapezoidal distortion on the top
User's Guide
Adjusts the vertical display height (vertical
5
