Related Manuals for Daikin VRV X RXQ6ARY6
Summary of Contents for Daikin VRV X RXQ6ARY6
- Page 1 INSTALLATION MANUAL OPERATION MANUAL E WASTE GUIDELINES ...
- Page 2 RXQ6ARY6 RXQ8ARY6 RXQ10ARY6 RXQ12ARY6 RXQ14ARY6 RXQ16ARY6 RXQ18ARY6 RXQ20ARY6 RXQ6ARY6ES RXQ8ARY6ES RXQ10ARY6ES RXQ12ARY6ES RXQ14ARY6ES RXQ16ARY6ES RXQ18ARY6ES RXQ20ARY6ES...
- Page 3 19. Precaution for antirust model 19.1. Caution of installation 19.2. Maintenance precautions...
- Page 19 Procedure 1 pipe Procedure 2 CAUTION...
- Page 20 10.2.3 Connecting refrigerant piping to the outdoor unit INFORMATION All local inter unit piping are field supplied except the accessory pipes. NOTICE Precautions when connecting field piping. Add brazing material as shown in the figure. NOTICE • Be sure to use the supplied accessory pipes when carrying out piping work in the field.
- Page 25 High COP Model Minimum circuit ecommended Wire Model pere uses Size RXQ12AH RXQ14AH 32.2 A 35 A RXQ16AH 32.2 A 35 A RXQ18AH 37.3 A 45 A RXQ20AH 42.4 A RXQ22AH 48.3 A Select and install the RXQ24AH 48.3 A power RXQ26AH 53.4 A...
- Page 42 19.1 Caution of installation VRV Antirust system should be installed in such a way that wall of the building can protect the system from sea breeze. When the VRV Antirust system is installed where it faces the ocean front, the windbreaker panel must be installed to protect the system from direct blow from salt spray.
- Page 43 RXQ6ARY6 RXQ8ARY6 RXQ10ARY6 RXQ12ARY6 RXQ14ARY6 RXQ16ARY6 RXQ18ARY6 RXQ20ARY6 RXQ6ARY6ES RXQ8ARY6ES RXQ10ARY6ES RXQ12ARY6ES RXQ14ARY6ES RXQ16ARY6ES RXQ18ARY6ES RXQ20ARY6ES...
- Page 44 Thank you for purchasing this Daikin air conditioner. Carefully read this operation manual before using the air conditioner. It will tell you how to use the unit properly and help you if any trouble occurs. After reading the manual, keep it in your custody for future reference.
-
Page 45: Table Of Contents
Operation manual 1. Definitions Contents 1.1. Meaning of warnings and symbols Page 1. Definitions..........Warnings in this manual are classified according 1 .1 . Meaning of warnings and symbols..to their severity and probability of occurrence. 1.2. Meaning of used terms......&... -
Page 46: Safety Precautions
Once in the unit, such animals can cause to instructions in this manual, but which are not malfunctions, smoke or fire when making contact supplied by Daikin. with electrical parts. • Consult your local dealer about installation work. Doing the work yourself may result in water 1.3. - Page 47 • Be sure to use fuses with the correct • Do not operate the air conditioner with wet ampere reading. hands. Do not use improper fuses, copper or other An electric shock may result. wires as a substitute, as this may result in electric shock, fire, injury or damage to the unit.
- Page 48 • When the air conditioner is malfunctioning � CAUTION ----------- (giving off a burning odour, etc.) turn off power to the unit and contact your local dealer. • Do not remove the outdoor unit's fan guard. Continued operation under such circumstances The guard protects against the unit's high speed may result in a failure, electric shocks or fire fan, which may cause injury.
- Page 49 • Do not put flammable containers, such as • Watch your steps at the time of air filter cleaning or inspection. spray cans, within 1 m from the blow-off mouth. High-place work is required, to which utmost The containers may explode because the warm attention must be paid.
-
Page 50: Installation Site
Consult your installer. sensitive to touch chemicals. System relocation Installation Site • Consult your Daikin about remodelling and relocation. Regarding places for installation • Install the air conditioner in a well-ventilated place that is free of obstructions 2. -
Page 51: System Layout
4. User interface 2.2. System layout Your VRV X series outdoor unit can be one of This operation manual will give a non-exhaustive following overview of the main functions of the system. models: RXQ: Single and multi continuous cooling model. Detailed information on required actions to achieve Depending on the type of outdoor unit which is certain functions can be found in the dedicated... -
Page 52: Program Dry Operation
STARTING THE SYSTEM NOTICE • Do not turn off the power immediately after the unit stops, but wait for at least 5 minutes. • The system need at least 5 minutes for residual operation of drain pump device. Turning off the power immediately will cause water leak or trouble. -
Page 53: Adjusting The Air Flow Direction
The air flow direction can be adjusted in one of the following ways: • The air flow flap itself adjusts its position. ,,,DAIKIN l c "- 1 ;!: I . . - • The air flow direction can be fixed by the user. -
Page 54: Precautions For Group Control System Or Two User Interface Control System
When the system is not operating (all indoor units thermo OFF), you can define the master RA indoor unit by addressing that unit with infrared user ,,,DAIKIN interface (instruct thermo ON in desired mode). The only way to change the master unit is by repeating the previous procedure. -
Page 55: Energy Saving And Optimum Operation
7. Energy saving and optimum Your system is equipped with advanced energy saving functionality. Depending on the priority operation emphasises can be put on energy saving or Observe the following precautions to ensure the comfort level. Several parameters can be selected, system operates properly. -
Page 56: Maintenance Before A Long Stop Period (E.g.,At The End Of The Season)
8.2 Maintenance before a long stop period 9.4 The fan direction does not correspond to (e.g., at the end of the season) the setting • The fan direction does not correspond with the • Let the indoor units run in fan only operation user interface display. -
Page 57: Troubleshooting
2.) Indoor unit, outdoor unit 10. Troubleshooting • A continuous low hissing sound is heard when If one of the following malfunctions occur, take the the system is in cooling operation. This is the measures shown below and contact your dealer. sound of refrigerant gas flowing through both &... -
Page 58: After-Sales Service And Warranty
11.2. After-sales service 2. If the system goes into fan only operation, but as soon as it goes into cooling operation, the 11.2.1 Recommendations for maintenance and system stops: inspection • Check if air inlet or outlet of outdoor or indoor Since dust collects when using the unit for several unit is not blocked by obstacles. -
Page 59: Shortening Of "Maintenance Cycle" And "Replacement Cycle" Needs To Be
11.2.2 Recommended inspection and 11.3 Shortening of "maintenance cycle" and maintenance cycles "replacement cycle" needs to be considered in following situations Be aware that the mentioned maintenance and The unit is used in locations where: replacement cycles do not relate to the warranty period of the components. -
Page 60: Malfunction Codes
Moving and discarding the unit • Contact your dealer for removing and Contents Main code reinstalling the total unit. Moving units requires technical expertise. Electronic expansion valve malfunction (outdoor) Discharge temperature malfunction (outdoor) • This unit uses hydrofluorocarbon. Contact your Abnormal suction temperature (outdoor) dealer when discarding this unit. - Page 61 E-WASTE GUIDELINES PROTECT THE ENVIORNMENT FROM E-WASTE (GUIDELINES) Meaning of E-waste under E-waste (Management) Rules, 2020 (E-waste rules) - Waste, electrical and electronic equipment, whole or in part of reject from their manufacturing and repair process, which are intended to be discarded. Our product is RHS compliant.
- Page 62 DAIKIN AIRCONDITIONING INDIA PVT. LTD. Head office: 12th Floor, Building No.9,Tower A, DLF Cyber City, DLF Phase-Ill, Gurgaon-122 002, Haryana, India www.daikinindia.com 3P714767-1A...
