Dear MAGNAT Customer,
The EDITION TWO / EDITION TWO LIMITED. car hi-fi power amplifier will enable you to satisfy your high
demands on sound reproduction in your car. With its impressive deep-bass power reserves, low harmonic
content and neutral reproduction, the EDITION TWO / EDITION TWO LIMITED. takes car hi-fi to new
heights. The amplifier is characterized by low operating current, rapid switching capabilities and excellent
temperature stability. Increased output power can be achieved by switching two amplifier channels in an
amplifier together in bridging mode. Experience and enjoy how this high-tech machine perfectly
reproduces magnificent sound.
Please read all of the owner's manual before installing and using the amplifier.
1.

TECHNICAL DATA

Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 324, B+=14.4V)
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 324, B+=14.4V)
Loudspeaker impedance (stereo)
Frequency response
Total harmonic content (DIN 45 403)
Stereo separation (IEC 581 )
Weighted noise distance (IEC A)
Input sensitivity LOW LEVEL INPUT
Input impedance LOW LEVEL INPUT
Low-pass filter
High-pass filter
Bass boost
Supply
Fuse
Sizes (W x H x D)
Weight
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 324, B+=14.4V)
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 324, B+=14.4V)
Loudspeaker impedance (stereo)
Frequency response
Total harmonic content (DIN 45 403)
Stereo separation (IEC 581 )
Weighted noise distance (IEC A)
Input sensitivity LOW LEVEL INPUT
Input impedance LOW LEVEL INPUT
Low-pass filter
High-pass filter
Bass boost
Supply
Fuse
GB
EDITION TWO
Stereo / Bridged
2 x 150 W / 1 x 500 W
2 x 55 W / 1 x 150 W
2 x 250 W
2 x 75 W
2 – 8 Ohm
5 – 50 000 Hz (-3 dB)
< 0.08% (1 kHz)
> 60 dB (1 kHz)
> 100 dB
0.4 – 4 V
20 kOhm
40 – 300 Hz, 12 dB per octave
40 – 300 Hz, 12 dB per octave
0...12 dB at 45 Hz
+12 V (10 – 15 V), minus to ground
1 x 20 A
221 x 57 x 236 mm
2.1 kg
EDITION TWO LIMITED
Stereo / Bridged
2 x 200 W / 1 x 600 W
2 x 75 W / 1 x 220 W
2 x 300 W
2 x 110 W
2 – 8 Ohm
5 – 50 000 Hz (-3 dB)
< 0.08% (1 kHz)
> 60 dB (1 kHz)
> 100 dB
0.4 – 4 V
20 kOhm
40 – 300 Hz, 12 dB per octave
40 – 300 Hz, 12 dB per octave
0...12 dB at 45 Hz
+12 V (10 – 15 V), minus to ground
1 x 30 A
9
on 4 Ohm
on 4 Ohm
on 2 Ohm
on 2 Ohm
on 4 Ohm
on 4 Ohm
on 2 Ohm
on 2 Ohm
