Energenie EGM-PWM User Manual

Usb energy meter
Hide thumbs

Advertisement

Quick Links

Download this manual
USER MANUAL
HANDBUCH
HANDLEIDING
MANUEL DESCRIPTIF
РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
EGM-PWM ENERGY METER
КЕРІВНИЦТВО КОРИСТУВАЧА

Advertisement

loading
Need help?

Need help?

Do you have a question about the EGM-PWM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Energenie EGM-PWM

Summary of Contents for Energenie EGM-PWM

  • Page 1 USER MANUAL HANDBUCH HANDLEIDING MANUEL DESCRIPTIF РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ EGM-PWM ENERGY METER КЕРІВНИЦТВО КОРИСТУВАЧА...
  • Page 2 EGM-PWM ENERGY METER Energy Meter Energiemessgerät Energiemeter Compteur d'énergie Измеритель мощности и энергии Вимірювач потужності та енергії All brands and logos are registered trademarks of their respective owners...

  • Page 3: Specifications

    EGM-PWM ENERGY METER Features  USB Energy Meter, allows insight in your energy consumption (voltage/current/power)  Power Manager software helps calculate the actual energy costs of your equipment  Software provides basic power consumption readings (home use) and advanced readings (business/scientific use) Specifications ...
  • Page 4 EGM-PWM ENERGY METER 1. Indicators and controls of the EGM-PWМ Figure #1 Socket Day/Night mode indicator Load indicator USB socket All brands and logos are registered trademarks of their respective owners...
  • Page 5  USB cable  CD with Power Manager software for Windows 4. Installation of EGM-PWM To install your EGM-PWM please follow the steps below: 1. Install the Power Manager software (see chapter 5 below). 2. Plug the EGM-PWM into the wall socket...
  • Page 6  EGM-PWM should be connected to a European AC wall socket of the DIN 49 440 (German Schuko type) standard  It is possible to connect the EGM-PWM to the power mains via socket strips, surge protectors, voltage regulators or a UPS 3.
  • Page 7 PC with the Power Manager software running. In this mode the software keeps downloading the power readings from the EGM-PWM into a database. In the offline mode the EGM-PWM will only save Energy consumption data (kWh), which will be logged into the database when the device comes online again.
  • Page 8 EGM-PWM ENERGY METER Figure #2 Push the Device settings button (bottom right here) to set the device- specific options (see Figure #3 below) All brands and logos are registered trademarks of their respective owners...
  • Page 9 To delete all previous recorded data, just push the Clear database button. Note: Device IP, Port and Enabled fields will be grey – these functions are only available on the LAN version of the EGM-PWM All brands and logos are registered trademarks of their respective owners...
  • Page 10 EGM-PWM ENERGY METER To open the Power Meter window, select your EGM-PWM device from the list (see Figure #2 above) and then click the Power meter button (see the chapter 7 below). 7. Power Meter The Power Meter window can be opened in either a minimized or maximized mode.
  • Page 11 EGM-PWM ENERGY METER Push Maximize button in this window to open the full-size Power Meter window – see Figure #5 below. Figure #5 All brands and logos are registered trademarks of their respective owners...
  • Page 12 EGM-PWM ENERGY METER This window displays all the measured values:  Real power (P)  Active impedance (R)  Frequency of current (Fq)  Energy consumed (E)  The cost of energy consumed (money sign)  RMS voltage (V rms) ...
  • Page 13 EGM-PWM ENERGY METER Figure #6 Choose the rate (per kWh) and currency. If you have different rates for peak hours and off-peak hours, just check the box Use Day/Night modes. You will then be able to enter the dual rates and the start/finish times for these modes.
  • Page 14 EGM-PWM ENERGY METER 8. Using the charts In the online mode the values of P, R, Fq, Irms, Vrms and Cost are continuously logged into the database. These readings can be used to build time charts. To display the charts just click on the desired value in the Main Power Meter window (see Figure #5 above) or push the Chart button in the Power Manager window (see Figure #2 above).
  • Page 15 EGM-PWM ENERGY METER Figure #7 The horizontal axis represents the date/time and the vertical axis represents the values of the chosen parameter. All brands and logos are registered trademarks of their respective owners...
  • Page 16 EGM-PWM ENERGY METER Note: The scale of the vertical axis changes automatically once you browse or zoom the chart. The scale will be chosen in such a way that all the values within the displayed time period fit onto the screen.
  • Page 17 EGM-PWM ENERGY METER Figure #8 All brands and logos are registered trademarks of their respective owners...
  • Page 18 EGM-PWM ENERGY METER  - The zooming tool allows changing the time scale of the chart. Push the zooming tool button and then click with the left mouse button to adjust the scale to the desired level  - When you select the home tool, the chart displays every...
  • Page 19 EGM-PWM ENERGY METER 9. Advanced features The Power Manager software also allows you to define a number of user-defined events. Possible events are: Lighting up the indicators in the Power Meter window (see Chapter 7 above), or run a user-specified application.
  • Page 20 EGM-PWM ENERGY METER below a certain minimum – fill in the Min field. Secondly you select the desired action from the Action list box. If you choose to execute a specific application or program, you can select the path to this application in the Path field.
  • Page 21 EGM-PWM ENERGY METER All brands and logos are registered trademarks of their respective owners...
  • Page 22 EGM-PWM ENERGY METER All brands and logos are registered trademarks of their respective owners...
  • Page 23 EGM-PWM ENERGY METER Waste disposal: Entsorgungshinweise: Do not deposit this equipment with the Werfen Sie dieses Gerät nicht in den household waste. Improper disposal can harm Hausmüll. Unsachgemäße Entsorgung kann both the environment and human health. For sowohl der Umwelt als auch der menschlichen...

  • Page 24: Warranty Conditions

    EGM-PWM ENERGY METER WARRANTY CONDITIONS GARANTIE BEDINGUNGEN The warranty period is 24 months and begins with the sale to the end user. The receipt must clearly list Die Garantie beträgt 24 Monate ab Verkaufsdatum the date of purchase and the part number, in addition an den Endverbraucher.

  • Page 25: Conditions De Garantie

    EGM-PWM ENERGY METER GARANTIE VOORWAARDEN CONDITIONS DE GARANTIE De garantietermijn bedraagt 24 maanden en gaat in Garantie est de 24 mois a partir de la date d’achat de l'utilisateur final. op de aankoopdatum van het product door de Le talon de garantie doit énumérer clairement la date eindgebruiker.
  • Page 26 EGM-PWM ENERGY METER ГАРАНТИЙНЫЙ ТАЛОН УМОВИ ГАРАНТІЙНОГО ОБСЛУГОВУВАННЯ 1. Гарантийное обслуживание предоставляется в течение 1. Гарантійне обслуговування надається протягом терміну срока гарантии, при наличии правильно и четко заполненного гарантії, при наявності Гарантійного талону, заповненого гарантийного талона, и изделия в полной комплектации.
