FEATURES AND CONTROLS
Switches
Mode Switch
The yellow switch located
near the instrument gauge
is used to toggle through
mode options available
such as odometer, trip
meter, hour meter and
tachometer. See page 43
for operation of the
modes.

Auxiliary Outlet

The 12-volt accessory
plug receptacle has spade
connections on the back
that may be used to power
an auxiliary light or other
optional accessories or
lights. The connections are
under the dash.
Electronic Power Steering (EPS)
The EPS warning indicator briefly
illuminates when the key is turned to the
ON position. If the light remains on after
starting the engine, the EPS system is
inoperative. See your authorized Polaris
dealer for service.
Electronic power steering (if
equipped) engages when the
ignition key is turned to the ON
position. EPS remains engaged
whether the vehicle is moving
or idle.
36
Ignition
Instrument
Switch
Light Switch
AWD
Switch
Power Steering Unit
Mode
Cluster
Switch
EPS Warning
Indicator
12V Accessory
EPS Indicator
(under cover)
Outlet
