- Page 1 VX-2200 LTR PERATING ANUAL Vertex Standard LMR, Inc.
- Page 2 We’re glad you joined the VERTEX STANDARD team. Call on us anytime, be- cause communications is our business. Let us help you get your message across.
- Page 3 Important channel frequency data is stored in EEPROM and flash memory on the CPU, and is easily programmable by dealers using a personal computer and the VERTEX STANDARD Programming Cable and CE94 Software. The pages which follow will detail the many advanced features provided on the VX- 2200 LTR Series transceiver.
-
Page 4: Front Panel
Front Panel Important! - All buttons located on the Front Panel are Programmable Function (PF) Buttons, configured according to your network requirements and programmed by your VERTEX STANDARD dealer. The instructions below describe a typically- configured radio. VOL/PWR Knob Turn this control clockwise to turn the radio on and to increase the volume. - Page 5 & C ONTROLS ONNECTORS LCD (Liquid Crystal Display) The display includes a 8-character alpha-numeric section showing group name tags/identity information and error messages, and an upper icon row displaying feature status (see below). TX/BUSY Indicator Indicates Transceiver’s Transmit/Receive Status ONVENTIONAL Steady Red: Transmitting in progress Steady Green:...
-
Page 6: Rear Panel
& C ONTROLS ONNECTORS Rear Panel 13.6V DC Cable Pigtail with Connector The supplied DC power cable must be connected to this 2-pin connector. Use only the supplied fused cable, extended if necessary, for power connection. Antenna Socket The 50-Ohm coaxial feedline to the antenna must be connected here, using a type-M (PL-259) plug. - Page 7 VX-2200 LTR S ERIES PERATING ANUAL...
-
Page 8: Basic Operation Of The Transceiver
ASIC PERATION OF THE RANSCEIVER Important! - Before turning on the radio the first time, confirm that the power con- nections have been made correctly and that a proper antenna is connected to the antenna jack. Switching Power ON/OFF Turn the VOL/PWR knob turn on the radio. The display will become illuminated. Press the [ ] / [ ] button to choose the desired operating group. -
Page 9: Automatic Time-Out Timer
ASIC PERATION OF THE RANSCEIVER LTR Z Press the PTT switch. When a group is available, the TX/BUSY indicator will glow red. The radio is now transmitting. While holding in the PTT switch, speak across the face of the microphone in a clear and normal voice. For best transmission, hold the micro- phone about 1-1/2 to 2 inches away from your mouth. -
Page 10: Advanced Operation
DVANCED PERATION Programmable Function (PF) Buttons The VX-2200 LTR Series includes six Programmable Function (PF) Buttons. The PF button functions can be customized, via programming by your VERTEX STAN- DARD dealer, to meet your communications/network requirements. Some features may require the purchase and installation of optional internal accessories. The pos- sible PF button programming features are illustrated below, and these functions are explained on the pages to follow. -
Page 11: Description Of Operating Functions
DVANCED PERATION Description of Operating Functions MONI M ONITOR Press (or press and hold) the assigned programmable key to cancel CTCSS- and DCS-controlled squelch; the TX/BUSY indicator will glow green Press (or press and hold) the assigned programmable key to open the SQL to hear background noise (unmute the audio);... - Page 12 DVANCED PERATION SCAN The Scanning feature is used to monitor multiple channels programmed into the transceiver. While scanning, the transceiver will check each group which is pro- grammed with scan memory “Enabled” for the presence of a signal, and will stop on a channel if a signal is present.
- Page 13 Press (or press and hold) the assigned programmable key to initiate an emergency call. For further details contact your VERTEX STANDARD dealer. Press (or press and hold) the assigned programmable key to send a 5-Tone sequen- tial burst which is pre-defined.
- Page 14 Press (or press and hold) the assigned programmable key to lock the various aspects of the transceiver’s keys. The precise lockout configuration must be programmed by your VERTEX STANDARD dealer. PTION This function is usable only when a FVP-35 Optional Unit is installed. It is used to toggle “on”...
-
Page 15: Arts (Auto Range Transpond System)
KILL status. When the radio is in the STUN status, the radio is not usable till a radio receives a REVIVE code. When the radio is in the KILL status, the radio is not usable, please bring the radio to your Vertex Standard dealer. VX-2200 LTR S... -
Page 16: Optional Accessories
Connection Cable for FIF-12 Availability of accessories may vary; some accessories are supplied standard per local requirements, others may be unavailable in some regions. Check with your VERTEX STANDARD Dealer for changes to this list. VX-2200 LTR S ERIES PERATING... - Page 17 ARRANTY OLICY Vertex Standard warrants, to the original purchaser only, its Vertex Standard manu- factured communications products against defects in materials and workmanship under normal use and service for a given period of time from the date of purchase. Limited Warranty Details: North America customers (USA and Canada): http://www.vertexstandard.com/lmr/warranty-terms.aspx...
- Page 18 VX-2200 LTR S ERIES PERATING ANUAL...
- Page 19 Part 15.21: Changes or modifications to this device not expressly approved by Vertex Standard could void the user’s authorization to operate this device.
- Page 20 Copyright 2013 Printed in China Vertex Standard LMR, Inc. All rights reserved. No portion of this manual may be reproduced without the permission of Vertex Standard LMR, Inc.
