AIRREX AIR CONDITIONER
▶ Thank you for purchasing an AIRREX AIR CONDITIONER.
▶ Keep this manual readily available.
▶ It is ESSENTIAL that you read the 'NOTES ON SAFETY' carefully
▶ The Air Conditioners are specified for use on a 115V. 60Hz. 1ph power supply.
▶ The Warranty form is on Page 15. Please complete it now and keep
▶ We have a policy of continual improving to our products.
BEFORE operation please read this user's manual carefully.
before use and follow them at all times.
You must check that the local electricity supply is the same and
have the appropriate plug fitted by a qualified electrician.
in a safe place.
The contents (features and specifications) in this manual are
therefore subject to change without notice.
USER'S MANUAL
HSC-14S
Advertisement
Table of Contents
Related Manuals for Airrex HSC-14S
Summary of Contents for Airrex HSC-14S
- Page 1 AIRREX AIR CONDITIONER USER’S MANUAL HSC-14S ▶ Thank you for purchasing an AIRREX AIR CONDITIONER. BEFORE operation please read this user’s manual carefully. ▶ Keep this manual readily available. ▶ It is ESSENTIAL that you read the ‘NOTES ON SAFETY’ carefully before use and follow them at all times.
-
Page 2: Table Of Contents
TABLE OF CONTENTS ■ SAFETY INSTRUCTIONS ■ DESCRIPTION ·Front View ·Back View ·Control Panel ■ OPERATING INSTRUCTIONS ·On/Off Operation ·Selection of Area/Room or Spot Cooling ·Economic Mode ·Temperature Control ·Off Timer ·Indicator and Operational Error Alerts ■ CLEANING AND MAINTENANCE ■... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS The following instructions are for ensuring the user’s safety and to prevent any physical injury or material damage. Please read carefully and follow all instructions. There are two sections to these instructions: WARNING and CAUTION. The following symbols are for your guidance : = You must NOT. - Page 4 SAFETY NOTICE CAUTION Do not place cooler on uneven, unstable or inclined surface. (This could cause malfunction) When storing the cooler, ensure that it is kept in a dry, cool place. (To prevent corrosion and malfunction) If not being used for some time or if lightening is present, always unplug from power.
-
Page 5: Description
EXTERIOR DESCRIPTION FRONT VIEW LOUVER OUTLET (COLD AIR) HANDLE DIgITAL CONTROLLER OzONE DISCHARgE TUBE ELECTRIC PANEL (ACCESS BY AUTHORISED SERVICE PERSONNEL ONLY) POWER PLUg CASTERS (FRONT LOCKABLE) BACK VIEW CONDENSER OUTLET (HOT AIR) EVAPORATOR FILTER AMBIENT AIR INTAKE. CONDENSER FILTER WATER LEVEL INDICATOR TO CHECK WATER LEVEL OF THE CONDENSATE TANK. -
Page 6: Control Panel
CONTROL PANEL FUNCTIONS ⑩ ⑦ ⑧ ⑪ ⑫ ⑨ ③ ④ ⑤ ⑥ ⑬ ② ① ① Power : Use to power On / Off. If the power is On, the OzONE discharge tube which is inside of machine is automatically On, and the power is Off, the OzONE discharge tube also off. -
Page 7: Operating Instructions
OPERATION RUNNING & STOP 1. START BY PRESSINg THE ‘POWER’ BUTTON. ·Cooler and OzONE discharge tube will start up automatically. ·To STOP the unit, press the ‘POWER’ button once again. 2.To change fan speed, press the ‘Low’ button. 3.If you wish to operate on fan only, press the ‘COOL’ button. To resume cooling, press the ‘COOL’... -
Page 8: Selection Of Area/Room Or Spot Cooling
SELECTION of AREA/ROOM or SPOT COOLING To reduce the temperature of the entire room select 'Area/Room'. For ‘targeted’ cooling of machinery, servers, or people etc. select ‘Spot Cooling’. 1. If you want to display room temperature, 2. If you want to change temperature unit ℉... -
Page 9: Temperature Control
TEMPERATURE CONTROL OPERATION 1. When power is ON, the setting temperature is displayed. Default of setting temperature is as below. ♣ 50℉ in Spot Mode. ♣ 60℉ in Room Mode. 2. When you push either button, the setting temperature is changed. 3. -
Page 10: Off Timer
HOW TO SET THE ‘OFF’TIMER. This function enables you to set the length of time you want the cooler to operate. You can set the time period from 30min. to 24 hours in 30min. and 1 hour increments. 1. When cooler is operating, press the ‘Off Timer’ button and set the length of time you want by pressing ▲... -
Page 11: Indicator And Operational Error Alerts
'ERROR' and WARNING INDICATORS The machine’s safety devices will automatically signal any problems via the display window on the control panel. The information below shows how to read these signals. 1. WATER FULL- Display shows “FU” When the water container is full, “FU” is displayed and the LED “Water Full”... -
Page 12: Cleaning And Maintenance
CLEANING AND MAINTENANCE CLEANING THE AIR FILTERS 1. To remove filters, slide up a little ① and pull towards you ②. 2. Clean the filters with water or compressed air. 3. Clean evaporator and condenser units with a vacuum cleaner or compressed air. MAINTENANCE 1. -
Page 13: Trouble Shooting / Accessories
● Dust in heat exchanger ● Clean heat exchanger ● Obstacle against inlet side ● Remove and allow 20inch.clearance ● Ambient temp. too high ● Use only below 105℉ (over 105℉) ACCESSORIES MODEL DRAWING ITEM HSC-14S Aluminium Filter for Evaporator Aluminium Filter for Condenser... -
Page 14: Specifications
SPECIFICATIONS HSC-14S 13,600 BTU/h Cooling Capacity (3.98) Power Supply 115Va.c. 60Hz. 1Ph. Dimensions inch. 19.3 X 23.6 X 46.8 (WxDxH) Weight ft 3 /m Evaporator Air Flow Power Consumption 1.59 Current Consumption Amp. 13.3 Nema Plug 5-15 Refrigerant R410A, 1.33... -
Page 15: Warranty
WARRANTY (Applicable to first retail purchaser only) AIRREX AIR CONDITIONERS give more reliable performance, comfort and durability the more they are used. They are built under a strict quality assurance regime which includes inspection both during and after production and exhaustive reliability testing. - Page 16 FAX : 1-469-574-7924 sales@airrexusa.com HEPHZIBAH CO.,LTD. 423-5 CHUNGCHUN-DONG, BUPYUNG-KU INCHEON, KOREA TEL : +82-32-509-5834 FAX : +82-32-502-5519 E-mail : airrex@hdtek.com Website : www.airrex.co.kr ● Designs and specifications of products are subject to change without prior notice for the improvement of products.
