EYEZONE B1080PX-4
User Manual
A u g 1 3 , 0 9
FCC Notices
It's herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is
subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
residential installation. This equipment generated uses and can radiate radio frequency
energy and if not installed and used in accordance with the instruction manual may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio of television reception, which can be determined by turning the
equipment off or on, the user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio TV technician for help.
CE Declaration
This device complies with CE class B.
EN55022
EN61000-3-2
EN61000-3-3
EN55024
IEC 61000-4-2
IEC 61000-4-3
Printed in Taiwan R.O.C.
All contents are subject to change without notice.
All trademarks are the property of their respective owner.
1
2
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B1080PX-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EYEZONE B1080PX-4

Summary of Contents for EYEZONE B1080PX-4

  • Page 1 FCC Notices EYEZONE B1080PX-4 It’s herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. User Manual This device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Table Of Contents

    FTP server. What’s more, the Eyezone B1080PX-4 supports multiple display zones, 10.2 Start the Schedule Software…..……………...………….. 38 you can play the stored videos on CF card or the HD videos from HDMI sources (the B1080PX-4 10.3 Apply the Schedule on the B1080PX-4…………..…….. 42 supports HDMI input), picture and scrolling text on the screen simultaneously, and the text color 11.

  • Page 3: Features

    Exports the Configuration Value: You can export the configuration value to the CF card. The configuration value can be modified on your PC, and can be applied to the B1080PX-4 or Power Switch: Toggle between main power on & off.

  • Page 4: Remote Control

    Status 1: If the “AUTOPLAY (Movie/ Picture/ All Files/ MultiLayer/ HDMI In)” function is Open the setup menu Mute sound enabled and there are media files on the CF card or the B1080PX-4 is already connected to OSD display function on/ off...

  • Page 5: Setting Up

    IP Assigned by DHCP: If you have a DHCP-enabled router, please select “On”, and then the router will automatically assigns an IP address to the Eyezone B1080PX-4. If you don’t have a DHCP –enabled router, select “Off” and type the network information in “Assign IP Address”.
  • Page 6 With the bundle tool “IP Detect”, user could search B1080PX-4 on the local area network. User could area network. also change the IP setting via this tool. For example, user might assign a static IP to B1080PX-4 by the steps as below: Step1: Insert the driver CD into your CD-ROM drive, then the autorun function will start up the shell program.

  • Page 7: Ftp Setup

    Step6: The default IP mode of B1080PX-4 is DHCP. User should change the mode to “Manual”, if he 7.2 FTP SETUP wants to assign a static IP address to B1080PX-4. Then enter the preferred “IP”, “Net Mask” and “Gateway” in the “Network Setting”. Finally, click on the “Setup” button for completing the setting.

  • Page 8: Video Setup

    HDMI: Select the HDMI output resolution among 480i / 480p/ 720p / 1080i/ 1080p. (GMT+02:00) Bucharest (GMT+10:00) Hobart Select the “Auto EDID”, the Eyezone B1080PX-4 will scan the display device connected and set Magadan, Solomon Is., New (GMT+02:00) Athens, Istanbul, Minsk (GMT+11:00) the correct resolution automatically.

  • Page 9: Other Setup

    Off: Turn off the Auto Play function. Play Button: Only for used with play buttons. The Eyezone B1080PX-4 supports two options SlideShow Interval: Set the time each photo is shown to 10, 15, 30 seconds or 1, 10, 15, 30 (Repeat Default / Repeat All) when the demo file finishes playing.

  • Page 10: Scrolling Text Setup

    8.1 PLAY MEDIA FILES ON THE CF CARD Step 1: Insert the CF card with media files, then turn on the Eyezone B1080PX-4 and press the “ENTER” button on the remote control when “’mnt/CF” is highlighted to take you into the CF card.
  • Page 11 8.1.1 Using the Remote Control When Media File Is Playing PAUSE/STEP: Pause the playback or play frame by frame. SETUP: Press the button to adjust the brightness, contrast or saturation while the video or picture ZOOM: Zoom in/ out on the movie or picture. is playing.

  • Page 12: Multiple Display Zones

    Use the “Notepad” to create a text file on your PC. Enter the message that you want to display and named the file “message.txt”. Step 1: Connects the HDMI source (DVD Player, TV Game or camcorder) to HDMI input of B1080PX-4. Step 2: Select the Multiple Display Zones item to display the movies and pictures with scrolling text Step 2: Turn off the background of scrolling text (refer to 7.5 Scrolling Text Setup).

  • Page 13: Download Function

    30 1 The first value is the Initial Time (unit: minutes) Step 1: Connects the HDMI source (DVD Player or camera) to HDMI input of B1080PX-4. The second value is Interval Time (unit: minutes) Step 2: Put pictures (only supports PNG format/ size: 213x641/ 96DPI) on the CF card.
  • Page 14 Step2: Remember to save the file after editing, and named the command file d + MAC address.txt. Item Description Example: The MAC address of B1080PX is 0013fe100000, and named the file d0013fe100000.txt. [file] Enter the filename you want to download. NOTE: The MAC address of B1080PX will be displayed in the setup menu.

  • Page 15: Rs-232 Function

    8.5 RS-232 FUNCTION (RS-232 cable is optional) 8.6 LOG FUNCTION Use the tool “Tera Term” or other tools to control the Eyezone B1080PX-4 with ASCII command. Step1. Please turn on the Log Function first. (Refer to 7.4 Other Setup) NOTE. 1. The available baud rates is “19200”.

  • Page 16: Http Command Function

    Confirm the “Local HTTP Server” function has been enabled, and the “Local HTTP Server Setup” set has been completed (refer to 7.2). Set your router or firewall, and open a port 80 for the Eyezone B1080PX-4. The following figure is an example, please refer to your user’s manual of router for opening ports.

  • Page 17: Network

    Key/ Passphrase: The key you enter here must match the password of the device exactly. FTP Server Address: Click on the address to directly connect to the B1080PX-4 server. Enter the user name and password (Default User Name: root, Default Password: admin) to log on. After logging on all the media files on the CF card will be listed.

  • Page 18: Time

    Port: Enter the port of the B1080PX-4 (default port: 80) GMT Server: Enter the NTP server IP address like: 66.187.233.4. User ID: Enter the user name of the B1080PX-4 (default ID: root). Time Zone: Set the time zone of your location.

  • Page 19: Schedule Function

    10. SCHEDULE FUNCTION 10.2 START THE SCHEDULE SOFTWARE You might double click the “Schedule Maker” icon on your desktop for opening the “Schedule NOTE: The “NTP Server” or “Local Time” must be set before using the Schedule Generator”. Or you might click on <Start> → <Programs> → <Schedule Maker 20090217> → < Function.
  • Page 20 Remove: Click this button to remove the file from the list. NOTE: Do not rename the file (schedule.ini), otherwise the B1080PX-4 will not be able to read the file. Select the file that you want to remove from the list, and press the “Remove” button to delete.

  • Page 21: Apply The Schedule On The B1080Px-4

    Step 4: After finishing all setup, press the “SAVE” button and a pop-up window will appear. Select the path, then click the “SAVE” button to save. NOTE: Do not rename the file (schedule.ini), otherwise the B1080PX-4 will not be able to read the file. 10.3 APPLY THE SCHEDULE ON THE B1080PX-4 Put the “schedule.ini”...

  • Page 22: Optional Auxiliary Equipment

    Step 2: Insert the CF card to the Eyezone B1080PX-4, and the Eyezone B1080PX-4 will play the default file automatically while powered on. Step 2: Insert the CF card to the B1080PX-4, and the B1080PX-4 will play the default file automatically Step 3: Press one of the buttons 1-5 to play the corresponding demo file.

  • Page 23: Troubleshooting

    Network Not Working If using wired network, make sure the network cable is plugged in NOTE: If you are in Video In Display mode, the B1080PX-4 will automatically play the live video from video source when the demo file finishes playing.
