EYEZONE B1080P-6
User Manual
Jul 27, 09
FCC Notices
It's herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation
is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
residential installation. This equipment generated uses and can radiate radio frequency
energy and if not installed and used in accordance with the instruction manual may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio of television reception, which can be determined by turning the
equipment off or on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio TV technician for help.
CE Declaration
This device complies with CE class B.
EN55022
IEC 61000-4-4
EN61000-3-2
IEC 61000-4-5
EN61000-3-3
IEC 61000-4-6
EN55024
IEC 61000-4-8
IEC 61000-4-2
IEC 61000-4-11
IEC 61000-4-3
Printed in Taiwan R.O.C.
All contents are subject to change without notice.
All trademarks are the property of their respective owner.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B1080P-6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EYEZONE B1080P-6

Summary of Contents for EYEZONE B1080P-6

  • Page 1 FCC Notices EYEZONE B1080P-6 It’s herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. User Manual This device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Table Of Contents

    Y.Pb.Pr, VGA (resolution up to 1360 x 768), HDMI (1920 x 1080P) and Audio, you can play media files on any display device. Eyezone B1080P-6 can be installed on the tourist bus, train or taxi to play the local attractions, station information or latest promotion.

  • Page 3: Features

    1920x1080 (1080P) and the maximum bit rate is 12Mbps. Exports the Configuration Value: You can export the configuration value to the CF card. The configuration value can be modified on your PC, and can be applied to the B1080P-6 or others.

  • Page 4: Remote Control

    Status 1: If the “AUTOPLAY (Movie, Picture or All Files)” function is enabled and there are Auto-play function on/ off media files on the CF card, the Eyezone B1080P-6 will auto play media files after power on. Mute sound Status 2: If the “AUTOPLAY” function is disabled, after power on the main menu will appear Volume up/ down as shown in the following figure.

  • Page 5: Setting Up

    IP Assigned by DHCP: If you have a DHCP-enabled router, please select “On”, and then the router will automatically assigns an IP address to the Eyezone B1080P-6. If you don’t have a DHCP –enabled router, select “Off” and type the network information in “Assign IP Address”.

  • Page 6: Ftp Setup

    Canada) (GMT-07:00) Arizona (GMT+04:00) Baku, Tbilisi, Ere van (If you use the Eyezone B1080P-6 server, please disable the DHCP function and input a fixed (GMT-06:00) Mexico city (GMT+04:00) Abu Dhabi, Muscat IP address, Mask, Gateway and DNS of the Eyezone B1080P-6)

  • Page 7: Video Setup

    Aspecl-ratio: Select TV mode 4:3, 16:9 or 16:10. HDMI: Select the HDMI output resolution among 480i / 480p/ 720p / 1080i/ 1080p. Select the “Auto EDID”, the Eyezone B1080P-6 will scan the display device connected and set the correct resolution automatically.

  • Page 8: Using The B1080P-6

    8.1 PLAY MEDIA FILES ON THE CF CARD Step 1: Insert the CF card with media files, then turn on the Eyezone B1080P-6 and press the “ENTER” button on the remote control when “’mnt/CF” is highlighted to take you into the CF card.
  • Page 9 8.1.1 Using the Remote Control When Media File Is Playing PAUSE/STEP: Pause the playback or play frame by frame. SETUP: Press the button to adjust the brightness, contrast or saturation while the video or picture ZOOM: Zoom in/ out on the movie or picture. is playing.

  • Page 10: Download Function

    Time”, then the Eyezone B1080P-6 will download all the files from the FTP server at the designated 8.2.2 Auto Download Function time. If there are more than one Eyezone B1080P-6, you can use ftp tools to divide them into different regional group. NOTE: The filename of the media files in FTP server cannot have any spaces.

  • Page 11: Play The Media Files On The Pc

    Step 3: Click the “Library” tab, and then click “Add to Library”. NOTE: If the network connection is unstable or broken, a pop-up window will appear as shown below. The Eyezone B1080P-6 will attempt to resume downloading in 2 minutes. The user can terminate the download by pressing the “RETURN” button.
  • Page 12 Step 5: Click the “Library” tab, and then click “Media Sharing”. Step 8: Confirm that the Eyezone B1080P-6 is connected to the network. In the list of devices below the “Share my media to” check box, select the device (Eyezone B1080P-6), and click “Allow” to share the media files.

  • Page 13: Download/ Upload Media Files

    IP Address (example. 192.168.1.100), Mask and Gateway for the B1080P-6 (refer to 7.1). Step 6: After logging on, all the media files in the CF card on the Eyezone B1080P-6 will be listed. You can download and upload the media files between CF card and your PC.

  • Page 14: Rs-232 Function

    For example. NOTE. 1.Baud Rates: - If there are multiple B1080P-6, you can use the “CuteFTP” tool to connect and manage files easily. - Firmware Updating: Set up the baud rate as “115200”. - ASCII Command: The available baud rates is 38400.

  • Page 15: Http Command Function

    Confirm the “Local HTTP Server” function has been enabled, and the “Local HTTP Server Setup” set has been completed (refer to 7.2). Set your router or firewall, and open a port 80 for the Eyezone B1080P-6. The following figure is an example, please refer to your user’s manual of router for opening ports.

  • Page 16: Network Setup

    B1080PW). DHCP: Enable/ Disable the DHCP function. IP Address: Enter the fixed IP address, Mask, Gateway and DNS for the Eyezone B1080P-6. FTP Server: Enable/ Disable the FTP Server function. You can also change the User ID, Password and port of the FTP Server.

  • Page 17: Gps Function

    There could be up to 6 digits after the dot. Lonorl: The orientation of the target location’s longitude, W for west and E for east. Step 4: Copy the GPSPos.cfg and associated video files to CF card. Plug the CF card to B1080P-6 and turn on the B1080P-6.

  • Page 18: Troubleshooting

    Check if audio cable has been connected correctly. Check your IP settings on the Network Setup page. (refer to 7.1) Network Not Working If using wired network, make sure the network cable is plugged in on both the Eyezone B1080P-6 and your network hub.
