- Page 1 MIRA EVERCLEAR ANTI-LIMESCALE HANDSET 1616.030 & 1616.031 1616.034 & 1616.035 Accessory Pack Installation and User Guide THESE INSTRUCTIONS ARE TO BE LEFT WITH THE USER...
-
Page 2: System Applications
Introduction The Mira Everclear is a single mode handset. It is suitable for most mixer showers and for electric showers over 9kW. This Handset has been specifically designed for use in hard water areas. The design incorporates an automatic self drain action and pins to resist and clear lime scale build up. -
Page 3: Specification
Specification Minimum maintained pressure: With low capacity spray unit fitted (as supplied): 5 kPa (0.05 bar). With high capacity spray unit fitted: 10 kPa (0.1 bar). Maximum maintained pressure: 500 kPa (5.0 bar). Connections: ½” BSP Male Warning! Exceeding the stated maximum maintained pressure could result in excessive spray force and possible damage to the handset. -
Page 4: Operation
Operation Spray Settings The Everclear handset has three operation modes: The flow of water automatically pushes the spray plate forward, sealing it against the retainer and allowing showering to start. Turning off the flow of water automatically allows the spray plate... -
Page 5: Maintenance
Maintenance To clean or replace the Spray Unit: Unclip and pull off the shroud. Shroud Unscrew the retainer in an anticlockwise direction. Retainer Remove the spray unit. If cleaning remove any debris/scale with a stiff brush and wash out. Spray Plate Ensure that the profile seal and Seal outer spring are located into the... - Page 6 1616.040 Shroud Chrome 1616.041 Retainer White 1616.042 Retainer Light Grey 1616.043 Spray Unit LC White 1616.044 Spray Unit LC Light Grey 1616.045 Spray Unit HC White 1616.046 Spray Unit HC Light Grey 1616.047 Everclear Handset White 1616.048 Everclear Handset Chrome...
- Page 7 Spares 1616.039 1616.040 1616.041 1616.042 1616.043 1616.038 1616.044 1616.047 1616.045 1616.048 1616.046...
-
Page 8: Customer Service
Service Our Service Force is available to provide a quality service at a reasonable cost. You will have the assurance of a Mira trained engineer/agent, genuine Mira spares, and a 12 month guarantee on the repair. Mira Showers Mira is a registered trade mark.
