Model:
XLR-N-AU
XLR-PB-AU
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• DO NOT spray aerosols in the vicinity of this
appliance while it is in operation.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
This is a room sealed appliance and no other ventilation is
required than what is provided.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
This is primarily a decorative appliance and it is not certifi ed as
a space heater.
SAI Global
Ref No GSCS20139
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XLR-N-AU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heat & Glo XLR-N-AU

Summary of Contents for Heat & Glo XLR-N-AU

  • Page 1 This is a room sealed appliance and no other ventilation is required than what is provided. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 2 Save this manual for future reference. Heat & Glo, a brand of Hearth & Home Technologies, Inc. 7571 215 Street West, Lakeville, MN 55044 Copyright 2009 • Printed in U.S.A. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 3: Congratulations

    The model information regarding your specifi c fi replace can be found on the rating plate usually located in the control area of the fi replace. Type of Gas SAI Global Certification Nº: DMS (mm) Model Number Serial Number Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 4: Table Of Contents

    E. Junction Box Installation......44 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 5 D. Contact Information ......67 = Contains updated information. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 6: Limited Lifetime Warranty

    B. Limited Lifetime Warranty Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 7 B. Limited Lifetime Warranty (continued) Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 8: Listing And Code Approvals

    Gas Rate .405 .134 .111 Maximum Gas Consumption 26 MJ/h 26.0 MJ/h 22 MJ/h Burner Injector DMS 42 (2.350 mm) DMS .057 (1.450 mm) DMS 55 (1.325) Pilot Injector Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 9: User Guide

    • Install a switch lock or a wall/remote control with child protection lockout feature. DECORATIVE DOORS (NOT SHOWN) SECTION 2.D. FIXED GLASS ASSEMBLY (NOT SHOWN) SECTION 14.E. CLEAR SPACE SECTION 2.C. Figure 2.1 General Operating Parts Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 10: Clear Space

    This appliance ships standard without a decorative media option. For installation and removal of these decorative media options, refer to installation instructions which ship with the media options. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 11: Lighting Instructions (Ipi)

    For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 12: Control Module Operation

    This is required for servicing and/or resetting the control module in the event of a control module LOCK-OUT. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 13: After Fireplace Is Lit

    Wall above appliance feels hot to No action necessary. This appliance ships with a non-combustible material attached. Specifi ca- the touch. tions of the attached non-combustible material are listed in Section 1.E. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 14: Maintenance And Service

    - Heavy deposits: Use commercial fireplace glass cleaner (consult with your dealer) • Refer to Section 14.E for glass removal and replacement instructions. • Reinstall door or decorative front. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 15: Maintenance Tasks-Qualifi Ed Service Technician

    • Gas pressure taps are accessible by removing the deco- rative front and fi xed glass assembly. Refer to section 11.A for information related to the gas valve and gas pressure settings. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 16: Installer Guide

    CEILING FIRESTOP ON FLOOR OF ATTIC (SECTION 8.C) FRAMING HEADED OFF IN CEILING JOISTS (SECTION 8.C) FRAMING/HEADER (SECTION 5) WALL SWITCH GAS LINE (SECTION 11) Figure 4.1 Typical System Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 17: Design And Installation Considerations

    Manometer Flat blade screwdriver Non-corrosive leak check solution 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws One 1/4 in. female connection (for optional fan). Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 18: Framing And Clearances

    254 mm ALCOVE INSTALLATION TOP VENT ONE 90º ELBOW TOP VENT ONE 90° ELBOW See Section D. Millimeters 1350 1220 1910 Figure 5.5 & 5.6 Figure 5.1 Appliance Locations Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 19: Constructing The Appliance Chase

    Sides of Front of Opening Opening Opening Opening to Ceiling Floor Flooring Appliance Appliance Appliance (Vent Pipe) (Height) (Depth) (Width) Millimeters 1070 1270 Figure 5.2. Clearances to Combustibles Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 20: Mantel And Wall Projections

    Figure 5.6 Non-Combustible Mantel Leg or Wall Projections (Acceptable on both sides of opening) Note: AIR SPACE denoted in Figure 5.8 is defi ned by the nailing tabs and metal standoffs. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 21: Termination Locations

    53.1°-56.3° ............2 130 56.3°-59.0° ............2 290 59.0°-60.3° ............2 440 *910 mm minimum in snow regions Figure 6.1 Minimum Height From Roof To Lowest Discharge Opening Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 22 3. All gravity air intakes within 910 mm of a termination cap must be a of the appliance when the venting system does not meet these minimum of 300 mm below the termination cap. requirements. Figure 6.3 Minimum Clearances for Termination Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 23: Vent Information And Diagrams

    • When penetrating a combustible ceiling, a ceiling fi restop must be installed. Horizontal • Horizontal runs of vent do not require vertical rise; Figure 7.1 horizontal runs may be level. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 24 305 mm 914 mm 610 mm 1.5 m 914 mm 2.1 m 1.2 m 4.3 m H Max. =4.3 m V + H Max. = 12.2 m Figure 7.4 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 25 1.2 m 914 mm 1.8 m 1.2 m 4.6 m H + H Max. =4.6 m V + H + H Max. = 12.2 m INSTALLED HORIZONTALLY Figure 7.5 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 26 fl ame height. If the vent confi guration has a total vertical of 4.6 m - 13.4 m, an exhaust restrictor may be needed. The exhaust restrictor can be located in the ap- pliance manual bag. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 27 + H Max. = 12.2 m * No specifi c restrictions on this value EXCEPT V + H cannot exceed 12.2 m Note: Use SLP Series components only. Figure 7.9 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 28 Max. = 12.2 m * No specifi c restrictions on this value EXCEPT V cannot exceed 12.2 m Note: Use SLP Series components only. INSTALLED HORIZONTALLY Figure 7.10 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 29 Min. Max. Min. Max. Min. Note: Use SLP Series 457 mm 1,2 m 1,2 m 1,2 m 1,0 m components only. Maximum= 40 ft, (12,2 m) Figure 7.11 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 30: Vent Clearances And Framing

    * Shows center of vent framing hole for top venting. The center of the hole is one 254 mm above the center of the horizontal vent pipe. Figure 8.2 Wall Penetration Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 31: Install The Ceiling Firestop

    INSTALL ATTIC INSULATION SHIELDS BEFORE OR AFTER INSTALLATION OF VENT SYSTEM 3 FASTENERS PER SIDE CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 8.5 Installing the Attic Shield Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 32: Install Attic Insulation Shield

    • Bend all tabs inward 90° around the top of the shield. These tabs must be used to prevent blown insulation from getting between the shield and vent pipe, and to maintain air space clearance. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 33: Appliance Preparation

    For all venting applications, ensure that the pipe gasket is in place before attaching any pipe section. This gasket is shipped in place around the starting collar. See Figure 9.2. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 34: Securing And Leveling The Appliance

    Figure 9.3 shows the fireplace installed on the floor. However, this fireplace can be elevated off the floor provided that the fi replace is properly supported by framing materials and the ceiling clearances are maintained. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 35: Installing Vent Pipe (Slp Pipe)

    Use care when removing termination cap from slip pipe. If slip section seals are broken during removal of the termination cap, vent may leak. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 36: Assemble Slip Sections

    • Only outer pipes are sealed, sealing the inner fl ue is not required. • All unit collar, pipe, slip section, elbow and cap outer fl ues shall be sealed. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 37: Disassemble Vent Sections

    3 mm larger than the support box outline. • Lower the support box through the hole in the roof until its bottom is at least 51 mm below the ceiling (Figure 10.9). Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 38: Install Metal Roof Flashing

    • Caulk the perimeter of the fl ashing where it contacts the roof surface. See Figure 10.12. Figure 10.14 Assembling the Storm Collar Around the Pipe Figure 10.14 Assembling the Storm Collar Around the Pipe Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 39: Install Vertical Termination Cap

    • Once the pipe section and the termination cap have been connected, slide the wall thimble up to the interior wall surface and attach with screws provided. See Figure 10.16. Figure 10.16 Wall Thimble Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 40: Install Horizontal Termination Cap

    EXTENDED 3,8 CM MIN. HEAT SHIELD OVERLAP WALL SHIELD FIRESTOP SLIP SECTION CAN BE EXTENDED INNER VENT SHEATHING OUTER VENT INTERIOR EXTERIOR Figure 10.17 Venting through the wall Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 41: Gas Information

    .134 .111 Maximum Gas Consumption 26 MJ/h 26.0 MJ/h 22 MJ/h Burner Injector DMS 42 (2.350 mm) DMS .057 (1.450 mm) DMS 55 (1.325) Pilot Injector Table 11.1 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 42: High Altitude Installations

    4. Lift the valve assembly up and out to make necessary When installing above 610 meters elevation: service or repair. Reduce burner orifi ce 4% for each 305 meters above 610 meters. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 43: Electrical Information

    TO JUNCTION BOX GRAY MODULE RC100 (OPTIONAL REMOTE CONTROL) THERMOSTAT WIRE ASSEMBLY / WALL SWITCH WIRE Figure 12.1 IntelliFire Pilot Ignition (IPI) Wiring Diagram with Wall Switch or Thermostat Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 44: Electrical Service And Repair

    JUNCTION BOX BLUE 6. Reinstall the junction box. 7. Reposition the junction box heat shield such that it is positioned over the junction box. Figure 12.3. Junction Box Installation Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 45: Finishing

    2. Screw each nailing tab to the adjoining framing material. Ensure that the air space clearance is maintained on Figure 13.2 Front Side Finishing Detail the sides of the fi replace. See Figure 13.2. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 46 Overlap Method of fi nishing. Note: Finishing materials are designed to overlap the outer edges of the fi nishing fl anges up to the fi replace opening. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 47 10 mm building material (dry wall, plywood, LOWER FINISH FLANGE wood composites, etc.) can be taped and sealed with combustible drywall tape. BOTTOM COVER PANEL Figure 13.6 Lower Cover Panel Positioned Correctly Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 48: Mantel And Wall Projections

    37 mm Note: For non-combustible fi replace fi nish material (marble, stone, etc) specifi cations refer to Section 13.C. 10 mm BUILDING MATERIAL Figure 13.9 Front Side Finishing Detail Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 49: Facing Material

    - 25.4 mm Thick Overlap Fit Method (Tonic or Martini Decorative Front) NON-COMBUSTIBLE FINISHING MATERIAL 0 - 25 mm THICK DRYWALL OR EQUIVALENT (10 mm) Figure 13.11 Overlap Fit Method (Tonic or Martini Decorative Front) Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 50 (Tonic Decorative Front Only) 0-102 mm 19 mm 520 mm APPLIANCE OPENING (HEIGHT) 76 mm 0-102 cm DRYWALL OR EQUIVALENT (10 mm) Figure 13.13 Inside Fit Method (Tonic Decorative Front Only) Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 51: Decorative Fronts

    (MT-SLR-**) Figure 13.16 Martini Decorative Front The tinted glass on the Martini Decorative Front meets the tempered glass specifi cations in Section 1.B of this installa- tion manual. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 52: Appliance Setup

    4. Put pressure on the glass as you allow the glass as- sembly to drop into the two lower glass clips. See Figure 14.1. 5. Tilt top of glass towards fi replace and engage both top spring latches Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 53: Air Shutter Setting

    Unit ships without a media option. Available approved media options are: • MEDIA-AMBER • MEDIA-BLACK • MEDIA-CLEAR • MEDIA-COBALT • MEDIA-BK2 • MEDIA-WH2 • MEDIA-GEMS • PORC-BASE • XLR-LOGS • MEDIA-STONES-2 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 54: Troubleshooting

    Verify module is securely grounded to metal chassis of appliance. d. Module voltage output / Valve/Pilot Verify battery voltage is at least 5.7 volts. Replace batteries if volt- solenoid ohms readings. age is below 5.7. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 55 ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is fi ne. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 56: Component Access

    GAS VALVE GAS VALVE SWITCH SWITCH BASE PAN Figure 16.4 Installing Burner Assembly CONTROL CONTROL BATTERY BATTERY DC ADAPTER DC ADAPTER MODULE MODULE PACK PACK Figure 16.2 Valve Components Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 57: Access Through The Valve Assembly

    Figure 16.6 Remove Valve Plate 4. Lift the valve assembly up and out to make necessary service or repair. 5. Replace gasket before reinstalling the valve assem- bly. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 58: Gas Valve Replacement

    GAS BALL VALVE VALVE VALVE VALVE O R I F I C E O R I F I C E FLEX FLEX FLARE FITTING FLARE FITTING Figure 16.9 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 59: Reference Materials

    NON-COMBUSTIBLE ZONE (PROVIDED WITH UNIT) GAS LINE ACCESS ELECTRICAL ACCESS LEFT VIEW FRONT VIEW RIGHT VIEW Location Millimeters Location Millimeters 1218 1092 1006 1060 1195 Figure 17.1 Appliance Dimensions Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 60: Vent Components Diagrams

    146 mm COOL-ADD Cap Shield 352 mm 241 mm 356 mm DRC-RADIUS Cap Shield 127 mm 302 mm 352 mm DVP-BEK2 DVP-HPC Cap Brick Extension Figure 17.2 Vent Components Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 61 51 - 152 SLP-PIPE Extended Heat Shield SLP12A 51 - 305 SLP-FS SLP-WS SLP-HVS Ceiling Firestop Wall Shield Firestop Horizontal Pipe Support Figure 17.5 SLP Series Vent Components Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 62 Support Box-Black Termination Cap SLP-DCF-BK SLP-WT-BK SL-2DVP Ceiling Firestop Wall Thimble-Black Adapter Black 305 mm 178 mm 394 mm DVP-FBHT SLP90 SL-2DVP DVP-FBHT Figure 17.6 SLP Series Vent Components Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 63 146 mm to 213 mm 140 mm 213 mm 3° 87° 381 mm 267 mm 276 mm SLP-HRC-SS SLP-HRC-ZC-SS HORIZONTAL TERMINATION CAP Figure 17.7 SLP Series Vent Components Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 64 XLR-N-AU, XLR-PB-AU C. Service Parts Service Parts Diagram Beginning Manufacturing Date: Nov 2009 Landscape DV Appliance Ending Manufacturing Date: ______ Part number list on following page. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 65: Service Parts List

    Pilot Orifi ce N 593-528 Pilot Orifi ce B 593-529 Pilot Orifi ce P 593-527 Regulator N NGK-DXF-NP Regulator P & B LPK-DXF-NP Additional service part numbers appear on following page. Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...
  • Page 66 Module Wire Assembly 2166-304 Module, Gray 2166-306 Flex Ball Valve Assembly 2098-320A DC Regulator 2166-369 Orifi ce N (#42C) 582-842 Orifi ce B (#55C) 582-855 Orifi ce P (.057C) 582-057 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

  • Page 67: Contact Information

    6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending. Printed in U.S.A. - Copyright 2010 Heat & Glo • XLR-N-AU, XLR-PB-AU • 2198-906 Rev. C • 3/10...

This manual is also suitable for:

Xlr-pb-au
