DIGITAL PLAIN PAPER COPIER
OPERATOR'S MANUAL
FOR PRINTER FUNCTION
NETWORK PRINTER BOARD GA-1040
CONFIGURATION GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Toshiba e-studio 45

Summary of Contents for Toshiba e-studio 45

  • Page 1 DIGITAL PLAIN PAPER COPIER OPERATOR'S MANUAL FOR PRINTER FUNCTION NETWORK PRINTER BOARD GA-1040 CONFIGURATION GUIDE...
  • Page 3 TOSHIBA GA-1040 CONFIGURATION GUIDE...
  • Page 5 Copyright © 2001 Electronics For Imaging, Inc. All rights reserved. This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics For Imaging, Inc., except as expressly permitted herein.
  • Page 6 FCC Information WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. Class A Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 7 Proprietary Rights You acknowledge that the Software, Coded Font Programs, Typefaces, and Trademarks are proprietary to Electronics For Imaging and its suppliers and that title and other intellectual property rights therein remain with Electronics For Imaging and its suppliers. Except as stated above, this Agreement does not grant you any right to patents, copyrights, trade secrets, trademarks (whether registered or unregistered), or any other rights, franchises or licenses in respect of the Software, Coded Font Programs, Typefaces, or Trademarks.
  • Page 8 General This Agreement will be governed by the laws of the State of California. This Agreement is the entire agreement held between you and Electronics For Imaging, and supersedes any other communications or advertising with respect to the Software and Coded Font Programs. If any provision of this Agreement is held invalid, the remainder of this Agreement shall continue in full force and effect.

  • Page 9: Table Of Contents

    Contents Introduction About this manual Organization About the documentation Chapter 1: Connecting to the Network GA-1040 on the network Stages of installation on the network Quick path to installation Before you begin 1-10 Ethernet cable connection 1-11 Back view with GA-1040 installed 1-11 Parallel cable connection 1-12...
  • Page 10 viii Contents Port Setup 2-10 Ethernet Setup 2-10 Parallel Setup 2-10 Protocol Setup 2-11 TCP/IP Setup 2-12 IPX/SPX Setup 2-14 NetWare Setup 2-14 AppleTalk Setup 2-16 Emulation 2-16 PCL Setup 2-17 Symbol Set 2-18 Font Setup 2-18 Page Length 2-18 Margin 2-18 PS Setup...
  • Page 11 ix Contents Printer Setup options 3-11 Printer Setup 3-12 PCL Setup 3-12 PS Setup options 3-13 Queue 3-14 Printing GA-1040 system pages 3-14 Changing the GA-1040 password 3-16 Changing the TopAccess weblink 3-17 Resetting the GA-1040 3-18 Restoring the GA-1040 to factory defaults 3-18 Clearing the GA-1040 3-18...
  • Page 12 x Contents Printer Setup 4-18 Printer Setup 4-19 Paper Setup 4-20 Exiting Setup 4-21 Printing the Configuration page 4-22 Chapter 5: Setting up Network Servers GA-1040 on a NetWare 5.x network with NDPS Tips for experts—NetWare 5.x networks Configuring a NetWare 5.x server for printing GA-1040 on a NetWare 3.x or 4.x network Tips for experts—IPX networks Overview of IPX printing to the GA-1040...

  • Page 13: About This Manual

    This manual is intended for anyone who is responsible for integrating the TOSHIBA GA-1040 into a business environment that includes networked personal computers. After you set up the TOSHIBA GA-1040 and client workstations as described in this manual and in Getting Started, individual users can print to the TOSHIBA GA-1040 as a high-performance printer.

  • Page 14: Organization

    xii Introduction Organization The manual is organized as follows: • Chapter 1 illustrates the supported network configurations and shows the network connectors on the GA-1040. • Chapter 2 describes GA-1040 configuration from the Touch Panel Display on the copier. • Chapter 3 describes GA-1040 configuration from TopAccess. •...
