Oregon Scientific OUTBREAKER RA201 User Manual
  1. Manuals
  2. Brands
  3. Oregon Scientific Manuals
  4. Weather Station
  5. OUTBREAKER RA201
  6. User manual
Oregon Scientific OUTBREAKER RA201 User Manual

Oregon Scientific OUTBREAKER RA201 User Manual

Ra201 is equipped with sailing timer, altimeter, barometer, weather forecast, thermometer, thronometer, calendar clock and el back light
Hide thumbs Also See for OUTBREAKER RA201:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
TABLE OF FIGURES............................................................................................................................................................................ 3
LEGENDS................................................................................................................................................................................................ 4
INTRODUCTION................................................................................................................................................................................... 4
ATTENTION!.......................................................................................................................................................................................... 4
NOTE ON COMPLIANCE.................................................................................................................................................................... 4
SECTION 1: CONTROL BUTTONS & ICONS.................................................................................................................................. 5
CONTROL BUTTONS..................................................................................................................................................................... 5
ICONS................................................................................................................................................................................................ 5
BATTERY INFORMATION........................................................................................................................................................... 6
TO REPLACE THE BATTERY................................................................................................................................................. 6
SECTION 2: GENERAL OPERATION............................................................................................................................................... 7
OPERATING MODES...................................................................................................................................................................... 7
CALENDAR CLOCK MODE, ZONE TIME AND UNIT OF MEASUREMENT..................................................................... 8
INFORMATION SHOWN IN CALENDAR MODE............................................................................................................... 8
HOW TO SET THE CALENDAR CLOCK............................................................................................................................. 8
HOW TO SET THE ZONE TIME............................................................................................................................................. 9
HOW TO SET THE UNIT OF MEASUREMENT................................................................................................................... 9
OUTBREAKER
USER'S MANUAL
MODEL : RA201
CONTENT
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OUTBREAKER RA201 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oregon Scientific OUTBREAKER RA201

Summary of Contents for Oregon Scientific OUTBREAKER RA201

  • Page 1: Table Of Contents

    OUTBREAKER USER’S MANUAL MODEL : RA201 CONTENT TABLE OF FIGURES.................................... 3 LEGENDS........................................ 4 INTRODUCTION....................................4 ATTENTION!......................................4 NOTE ON COMPLIANCE..................................4 SECTION 1: CONTROL BUTTONS & ICONS..........................5 CONTROL BUTTONS..................................5 ICONS........................................ 5 BATTERY INFORMATION................................6 TO REPLACE THE BATTERY..............................6 SECTION 2: GENERAL OPERATION...............................
  • Page 2 HOW TO SET THE DAILY ALARM............................9 CHRONOMETER..................................10 ALTIMETER-BAROMETER MODE............................11 INFORMATION SHOWN IN ALTIMETER........................... 11 HOW TO SET THE ALTITUDE............................... 11 HOW TO SET THE RESOLUTION OF ALTITUDE......................12 HOW TO SET THE ALTIMETER ALARM........................... 12 HOW TO SET THE WEATHER FORECAST ICON......................13 SEA LEVEL PRESSURE DISPLAY............................

  • Page 3: Table Of Figures

    TABLE OF FIGURES Fig. 1 TOGGLE BETWEEN VARIOUS MODE........................7 Fig. 2 TOGGLE INFORMATION IN CALENDAR CLOCK MODE................... 8 Fig. 3 SET CALENDAR CLOCK.............................. 8 Fig. 3a SET ZONE TIME................................8 Fig. 3b SET THE UNIT OF MEASUREMENT.......................... 8 Fig. 3c SET DAILY ALARM................................

  • Page 4: Legends

    • If irregularity exist, press and hold MODE, SELECT, LAP and this advanced Baro-compensation technology the performance of SET key simultaneously for 2 seconds to reset the watch. the RA201 on the altitude reading and weather forecast will be much more reliable. NOTE ON COMPLIANCE Oregon Scientific OUTBREAKER conforms to the required EMC Directive 89/336/EC and carries the respective CE marking.

  • Page 5: Section 1: Control Buttons & Icons

    SECTION 1 : CONTROL BUTTONS CONTROL BUTTONS & ICONS 1. MODE Toggle among clock, altimeter-barometer and sailing timer mode 2. LIGHT/ Turn on the backlight or hold to activate/release the key lock function 3. SELECT/+ Select the information in various modes or increase a value while setting 4.

  • Page 6: Battery Information

    • It is recommended to have the battery replaced by your Oregon Scientific dealer. Non-experienced user should take extreme care a) A status bar shows on the display whether RA201 is in altimeter- in order to maintain water resistance. barometer or sailing timer mode.

  • Page 7: Section 2: General Operation

    SECTION 2 : GENERAL OPERATION Diagram B OPERATING MODES RA201 has three operating modes for calendar clock, altimeter- barometer and sailing timer. Press MODE to toggle between these three operating modes. Refer to Fig. 1 to toggle among the operating modes.

  • Page 8: Calendar Clock Mode, Zone Time And Unit Of Measurement

    2. Press SET to toggle the field in the calendar clock setting mode. CALENDAR CLOCK MODE, ZONE TIME The order of field follows: 12/24hr format, hour, minute, year, AND UNIT OF MEASUREMENT month, date, zone time and unit of measurement. 3.

  • Page 9: How To Set The Zone Time

    Alarm on/off HOW TO SET THE UNIT OF MEASUREMENT RA201 is equipped with two sets of unit of measurement: metric or imperial. It can be set in the sequence of setting the calendar clock. 1. Press and hold the SET for two seconds in either clock-date or clock-second display to enter the calendar clock setting mode.

  • Page 10: Chronometer

    Notes: Refer to Fig. 3d to set the countdown timer. a) The alarm will be activated automatically once the alarm time has been altered. b) The alarm will alert for 1 minute. Press any key to stop the alarm. CHRONOMETER It can be used as a stopwatch as well as a countdown timer.

  • Page 11: Altimeter-Barometer Mode

    ALTIMETER-BAROMETER MODE • There is a bar graph at the bottom of the display showing the RA201 is equipped with an intelligent barometer that determines altitude history. It will be updated every minute. altitude by the built-in sensor with the advanced Baro-compensation...

  • Page 12: How To Set The Resolution Of Altitude

    • Press and hold +/- function is not available for select the resolution of altitude. HOW TO SET THE ALTITUDE ALARM Set altimeter alarm on/off Set altitude RA201 is equipped with an altitude alarm. Either ascending or descending altitude alarm could be selected. The ascending altitude Fig. 4c Fig. 4C Fig.4C...

  • Page 13: How To Set The Weather Forecast Icon

    In the sea level pressure display there are two functions that can be 1. Press and hold SET for two seconds in altitude-local pressure called out from the RA201: sea level pressure history memory and display to enter the weather forecast icon setting mode.

  • Page 14: How To Set The Sea Level Pressure

    No sea level pressure bar graph HOW TO SET THE SEA LEVEL PRESSURE Set sea level pressure FUNC When you first use the RA201, please calibrate the sea level Fig.4f Fig. 4f pressure. Once the sea level pressure is calibrated, the altitude will...

  • Page 15: Sailing Timer Mode

    SAILING TIMER TIMER 1 – Chronometer RA201 is equipped with three sailing timers: TIMER 1 – Timer 1 can be used as a stopwatch with 99 laps memory function chronometer with 99 laps memory; TIMER 2 – 10 minutes pre-set as well as a countdown timer.
  • Page 16 Use as a stopwatch: Notes: 1. Press ST/SP to start the stopwatch. a) When countdown time reaches the last 5 minutes to last minute, short double beeping sound every minute. 2. Press LAP to mark a lap memory. b) At every 10 seconds during the last minute, there will be a short 3.

  • Page 17: Recall Lap Memory For Timer 1

    Recall LAP Memory for TIMER 1 2. Press +/- to select the particular memory group to be deleted. 1. Press SELECT in TIMER 1 mode after it is reset to 00:00:00 to 3. Press and hold FUNC for 2 seconds in that particular group to enter the LAP memory recall mode (recall can only be activated enter the LAP memory delete mode.

  • Page 18: Timer 2 - 10 Min Sailing Timer/Timer 3 - 6 Min Sailing Timer

    SAILING TIMER decreased to the full counting minute. RA201 has two pre-set sailing timers: TIMER 2: 10 min sailing b) When reaching every full minute there will be a short double timer and TIMER 3: 6 min sailing timer. These sailing timers function beeping sound.

  • Page 19: Section 3 : The Thermometer

    • When RA201 is worn on wrist, the temperature measured could be affected by the body heat. To acquire an accurate temperature reading, remove RA201 from the wrist and wait at least for 15 minutes before taking the reading. SECTION 4 : THE BACKLIGHT...

  • Page 20: Section 6 : Maintenance And Disposal

    Press and hold LIGHT/ for two seconds to activate/release SECTION 7 : the key lock function. TROUBLE SHOOTING GUIDE Note: • After key lock function is activated, only LIGHT key can TROUBLE POSSIBLE REMEDY function normally. CAUSE Different altitude was This is caused by the Recalibrate the altitude found for same...

  • Page 21: Section 8 : Technical Specification

    TROUBLE POSSIBLE REMEDY TROUBLE POSSIBLE REMEDY CAUSE CAUSE The sea level pressure Cannot start the The bar graph of the The display range will TIMER 1, TIMER 2 or Stop the running timer Timer in SAILING exceeds the upper limit sea level pressure be readjusted for the and reset the TIMER.
  • Page 22 THERMOMETER TIMER 1 Measuring range : -10.0...60.0 C (14.0...140.0 Chronometer : 99:59:59 (hr:min:sec) Resolution : 0.1 C (0.2 LAP memory : 99 memory groups and 99 LAP memory Accuracy : +/-1 C (+/-2 TIMER 2 ALTIMETER Countdown timer : 00:10:00 (hr:min:sec) Altitude display : 410...9,010m (–1,345...29,553ft)
