8. Install the charged 6 or 7 cell battery into the battery slot
(remove foam if using a 7-cell). Re-install the battery strap
onto the Evader BX Pro. Note that there is a channel in the
chassis for the battery strap to rest in. Re-install the body
clip into the battery strap post.
9. Decal the body as desired and install on the chassis,
using two body clips to secure in place.
Before running your new Evader BX Pro, please read
the following instructions for important information on
ESC setup, ball differential break-in and adjustment,
and maintenance.
INTELLISPEED
The following instructions will help you get trouble-free
operation from your electronic speed control (ESC). These
simple steps will allow your ESC to achieve maximum
performance and minimize the chance of problems due to
incorrect installation. Consult the specifications listed below for
limitations for this ESC. You should always ask your hobby
dealer or call our service department before using the ESC for
an application other than what is listed in these instructions.
PLEASE FOLLOW ALL INSTRUCTIONS CAREFULLY!
Features & Specifications
• The IntelliSpeed 12T Modified ESC is designed to be used
with any 12-27 turn motor – great for intermediate or
competition racing applications.
• Customize the model's traction control with three different
built-in acceleration speed settings.
• Anti-Lock Brake System (ABS) enables greater control
while cornering.
• A built-in reverse delay function aids in protecting model
gear-trains when shifting from forward to reverse.
• Reverse lockout meets racing purposes.
• Motor, battery, and radio connectors are pre-installed.
• High frequency operation
control, maximizes battery run time, and reduces
operating temperatures.
• High temperature control automatically shuts down the
ESC to prevent damage from occurring during excessive
current situations.
Input Power:
Operating Frequency:
BEC:
On-Resistance:
Max. Constant Current:
Max. Peak Current:
Motor Turns Limit:
Acceleration Time Delays:
Case Size (with heat sink):
Weight (with heat sink):
5
™ SET UP
provides very smooth
7.2 to 8.4 volts DC (6-7 cells)
1.0 kHz
5.0 volts / 1.0 amp
0.0035 ohms
232 amps
800 amps
no fewer than 12 turns
0.0, 0.1, and 0.2 seconds
1.48 x 1.34 x 0.57"
(42 x 38 x 16mm)
2.44 oz (69g)
