- Page 1 Mercedes Bluetooth Upgrade Kit MBU-1000 Installation and Operation Guide...
-
Page 2: Table Of Contents
UHI ................................ 5 Installing the main unit ............6 Microphone volume setting ............6 Understanding your MBU-1000 buttons and LED indicators ....7 Pairing ................7 Phones Pairing Priority ............7 Uploading Your Phonebook Contacts 1: Phonebook Synchronization ..8 Uploading Your Phonebook Contacts 2: Object Push Profile (OPP) .. -
Page 3: Core Components
V. UHI Once you have determined the cradle type you will need to choose the right software for your MBU-1000 so it can work with your original cradle. The software switch is located at back of your main unit. 6150 Cradle... -
Page 4: 6210 Cradle
MBU-1000 Installation and Operation Guide 6210 Cradle Software A Required Software B Required Nokia 6310/6310i Type 1 & 2 Software B Required... -
Page 5: Uhi
MBU-1000 Installation and Operation Guide UHI cradle should contain the following circled item shown in picture below: Software C Required Here is a software summary table below: Software A Software B Software C Cradle 6150 6210 6310/6310i Software Type... -
Page 6: Installing The Main Unit
Locate your cradle and carefully place the main unit inside the cradle until the unit is firmly attached to the cradle. If your cradle is 6150 type you will need to plug the dummy antenna on top of the MBU-1000’s mini USB port before you attach to the cradle. -
Page 7: Understanding Your Mbu-1000 Buttons And Led Indicators
5. Understanding your MBU-1000 buttons and LED indicators 6. Pairing Place MBU-1000 on the original cradle, and turn on audio system to power up the unit. Press on the pairing button on the device (longer than 5 seconds), the white light (pairing indicator) will start flashing, this means the kit is searching for pairing mobile. -
Page 8: Uploading Your Phonebook Contacts 1: Phonebook Synchronization
9. Uploading Your Phonebook Contacts 2: Object Push Profile (OPP) Users may also send the contacts one by one to the MBU-1000 by OPP method. Press the OPP button (longer than 5 seconds) until the blue light of OPP starts flashing to indicate that user has activated... -
Page 9: Independent Phonebook For Each Individual Phone
Select the desired contacts in your phone and send via Bluetooth. As soon as MBU-1000 receives the contacts it will automatically transfer them into the Mercedes original handsfree/audio system. After you have sent all the required contacts please press the Reset button to re-establish the connection between the mobile with upgrade kit. -
Page 10: Disconnect/Reset
14. Clearing Call History (Master Reset) To clear the call history memory in MBU-1000 please hold the Sync button for 5 seconds and click on the reset button, then release both buttons together. Please note this will also cause all pairing... -
Page 11: List Of Compatible Cars
2003-2005 W463 G-class 2003-2005 W163 M-class Software C (UHI Version, UHI 6310i cradle required) All series after 2005~ now *We are currently developing an UHI BT adapter which will allow users to use MBU-1000 without having an UHI 6310i cradle.
