Smeg SA520TX90 Brochure & Specs

SA520TX90
finish silverfrost carcase, stainless steel
fascia, clear glass deflector, fascia rail
replaceable for integration
90cm
size
installation built into overhead cabinetry
100 watt single shaded motor with
motor
impellor
two front mounted, right
controls
speeds 3 settings — LOW, MID, HIGH ‑‑
presettable
illumination two x 20 watt halogen lights
37–53dB
noise
capacity 210 cubic metres/hour net, 273 cubic
metres/hour gross
filter one‑piece aluminium mesh (removable)
ducted or recirculated
air extraction
accessory actived charcoal filter (removable/
replaceable)
warranty two years parts and labour
smeg 90cm slideout rangehood
DIRECT RECIRCULATION
No longer is a ducting kit required to be installed in the
cabinetry above the rangehood to redirect the filtered
air back into the kitchen. Simply remove the cover plate
positioned behind the telescopic fascia rail and the air is
efficiently recirculated.
SPACE SAVING
This direct recirculation frees the overhead cabinetry space for
extra kitchen storage.
COST CUTTING
As well as the absence of a recirculation kit and its associated
purchase costs, there is no further carpentry involved with this
single and simple installation requirement.
FULL INTEGRATION
Mounted above the cooktop in cupboard and suspended
from a shelf in the cabinet cavity, the front fascia rail is fully
integrated into the cupboard line when the rangehood is not
in use. This front rail is replaceable by a decor strip of timber
or laminated material.
AUTOMATION
Preset fan speed and/or lights to operate automatically when
rail is pulled forward.
MAINTENANCE
Easy lift-out grease filter is washable; removable light diffuser
for bulb access. All clean lines for wipe-over maintenance.
PERFORMANCE
Highly-efficient air extraction of up to 273 cubic metres an
hour further enhanced by large catchment area when glass
visor is telescoped outwards.
QUIETNESS
37–53 dB. The motor/impellor encasement and flues are all
smooth-walled to minimise air drag and hence noise, welded
metal joints for no vibration.
SAFETY
Thermal overload protector or motor; fire-retardant
hardened metal and mesh. VO self-extinguishing
polycarbonate for motor housing and internal flue.
CHARCOAL FILTER
This accessory is fitted for the effective removal of cooking
odours in the circulation application. These filters are not to
be washed and are replaceable.
DIRECT DUCTING
When the extracted air can be sent straight to atmosphere,
simply replace the front coverplate and the top exit, in
conjunction with a duct pipe.
ID250311
Code SA520TX90
