3. Next slide the vertical legs into the belt loop located in
the middle of the pool liner. The bottom of the leg
should be inside the white restraining rope (6) located
near the liner's bottom edge. Carefully slide the leg into
the belt loop and place the leg's bottom inside the rope
and then insert the top of the leg into the bottom of the
joint. Snap the leg into joint's holes by aligning the
hole and the spring-loaded pin. Attach the leg's end
cap (3) to the bottom of the leg (see drawing 3).
4. • Grab the frame pool's top beams in 2 – 3 locations and "shake" the pool to be sure all
the joints, legs and beams "fit into each other".
• Pull gently, in an outward direction, at the bottom of the leg; making sure the leg is inside
the restraining rope.
5. If pool was purchased with a filter pump, see Krystal Clear™ Filter Pump Manual
first and then go to step #6.
6. • Before filling the pool with water, ensure that the drain plug inside the pool is closed and
that the drain cap on the outside is screwed on tightly. Fill the pool with no more than 1
inch of water. Check to see whether the water is level.
IMPORTANT: If the water in the pool flows to one side, the pool is not completely
level. Setting up the pool on unlevel ground will cause the pool to tilt resulting in
the sidewall material bulging. If the pool is not completely level, you must drain the
pool, level the area or move the pool to a different area that is level, and re-fill the
pool.
• Smooth out the remaining wrinkles (from inside the pool) by pushing out where the pool
floor and pool sides meet. Or, (from outside pool) reach under the side of the pool,
grasp the pool floor and pull it out. If the ground cloth is causing the wrinkles, have 2
adults pull from either side to remove all wrinkles.
7. Fill the pool with water up to just below the
sleeve line (see drawing 4).
Before allowing anyone to use the pool, hold a family meeting. Establish a set of
rules that include, at a minimum, the important safety rules and general
aquatic safety information in this manual. Review these rules on a regular basis
and with all users of the pool, including guests.
SAVE THESE INSTRUCTIONS
(118IO) ULTRA FRAME POOL ENGLISH 7.5" X 10.3" PANTONE 295U 05/22/2009
POOL SETUP (continued)
IMPORTANT
English
3
WATER LEVEL
118
IO
3
4
